SG Security Communications SKYROUTE Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation
Manual
Version 1.O

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKYROUTE and is the answer not in the manual?

Questions and answers

Related Manuals for SG Security Communications SKYROUTE

Summary of Contents for SG Security Communications SKYROUTE

  • Page 1 Installation Manual Version 1.O...
  • Page 2 FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Sur-Gard Security Systems Ltd. could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 and Part 22 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Table Of Contents

    Zone Definition - Sections [01]to[05] ......3 Skyroute Transceiver Glossary of Terms ... Inside front cover Configuration Options - Section [06] ......3 Skyroute Transceiver SID (System ID) - Section [07] ..4 Introducing the Skyroute Transceiver Skyroute Test Time - Section [10] ........ 4 Specifications ...............

  • Page 4: Important Information

    Cellemetry gateway. Skyroute Transceiver Glossary of Terms Clearing House The following is a description of various terms used with The Clearinghouse is a routing center that automatically regards to cellemetry technology. forwards data between Skyroute transmitters and central stations.

  • Page 5: Introducing The Skyroute Transceiver

    • Extension Kits available: transceiver via the Cellemetry network to the Clearing House LAE – 3 The 3 Foot Antenna Kit for Skyroute Transceiver and then to the Central Station in a fast, reliable manner. LAE – 15 The 15 Foot Antenna Kit for Skyroute Transceiver Skyroute has been designed for simple and straightforward LAE –...

  • Page 6: Installation

    KEYBUS (red, black, yellow and green). Mounting the Skyroute Transceiver The Skyroute Transceiver can be mounted in the upper right Bell IN Terminal hand corner of the panel’s cabinet through the knock out.

  • Page 7: Relocating The Antenna

    Relocating the Skyroute Transceiver The Skyroute transceiver being a keybus accessory, it is possible to relocate the module up to 1000 feet from the main control panel when it is not located in a good cellemetry coverage. (A control panel installed in a vault for example). When relocating the module, follow theses rules: •...

  • Page 8: Skyroute Transceiver Sid (System Id) - Section [07]

    Individual Event - Transmission Toggle…………………..Sections [30] to [78] These sections are used to determine if an event will be transmitted by the Skyroute transceiver. If ’00’ is entered, then that event will not be transmitted. If ‘FF’ is programmed, then the event will be transmitted. ‘FF’ is the default value.

  • Page 9: Activating The Skyroute Transceiver

    Before activating the Skyroute transceiver, ensure that the control panel is wired, programmed and operating properly. Make sure that the Skyroute transmitter is properly connected to the keybus and to the bell positive circuit. When power is applied to the system, the Skyroute will perform self-diagnostics for a few seconds, before giving visual feedback by indicating signal strength on LED1, LED2 and LED3.

  • Page 10: Skyroute Programming (Pc5010/580/1555/5015)

    [803] Skyroute Programming (PC5010/580/1555/5015) Zone Definitions 00 Null Zone (No Alarm) 09 24 Hour Supervisory (LINKS) 18 24 Hour Sprinkler 01 Delay 1 10 24 Hour Supervisory Buzzer 19 24 Hour Water 02 Delay 2 11 24 Hour Burglary 20 24 Hour Freeze...
  • Page 11 I_____I Option 6 Test on Friday Disabled I_____I Option 7 Test on Saturday Disabled I_____I Option 8 For Future Use [13] Skyroute Test Rates I_____I Option 1 Industrial Disabled I_____I Option 2 Commercial and Business Disabled I_____I Option 3 Residential and Retail...
  • Page 12 [33] Alarm Reporting Codes, Zones 25-32 I_____I_____I I_____I_____I Zone 25 Alarm Zone 29 Alarm I_____I_____I Zone 26 Alarm I_____I_____I Zone 30 Alarm I_____I_____I I_____I_____I Zone 27 Alarm Zone 31 Alarm I_____I_____I Zone 28 Alarm I_____I_____I Zone 32 Alarm [34] Alarm Reporting Codes, Zones 1-8 I_____I_____I Zone 1 Alarm Restoral I_____I_____I...
  • Page 13 [43] Tamper Reporting Codes, Zones 25-32 I_____I_____I Zone 25 Tamper I_____I_____I Zone 29 Tamper I_____I_____I I_____I_____I Zone 26 Tamper Zone 30 Tamper I_____I_____I Zone 27 Tamper I_____I_____I Zone 31 Tamper I_____I_____I Zone 28 Tamper I_____I_____I Zone 32 Tamper [44] Tamper Restoral Reporting Codes, Zones 1-8 I_____I_____I Zone 1 Tamper Restoral I_____I_____I...
  • Page 14 [53] Supervisory Restoral Reporting Codes, Zones 1-8 I_____I_____I Zone 1 Supervisory Restoral I_____I_____I Zone 5 Supervisory Restoral I_____I_____I Zone 2 Supervisory Restoral I_____I_____I Zone 6 Supervisory Restoral I_____I_____I I_____I_____I Zone 3 Supervisory Restoral Zone 7 Supervisory Restoral I_____I_____I Zone 4 Supervisory Restoral I_____I_____I Zone 8 Supervisory Restoral [54] Supervisory Restoral Reporting Codes, Zones 9-16...
  • Page 15 [63] Low Battery Restoral Reporting Codes, Zones 17-24 I_____I_____I Zone 17 Low Battery Restoral I_____I_____I Zone 21 Low Battery Restoral I_____I_____I I_____I_____I Zone 18 Low Battery Restoral Zone 22 Low Battery Restoral I_____I_____I Zone 19 Low Battery Restoral I_____I_____I Zone 23 Low Battery Restoral I_____I_____I Zone 20 Low Battery Restoral I_____I_____I...
  • Page 16 [99] Section [99] is for software defaulting of the Skyroute I_____I_____I Entering 00 will cause a software default of the Skyroute. Entering 01-FF will cause restart of the Skyroute Transceiver. Entering any other value will not cause a default or a restart.

  • Page 17: For Your Records

    For Your Records Location ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ Skyroute MIN Number ________________________________________________ Rate Plan ________________________________________________ Central Station ________________________________________________ Account Number ________________________________________________ Test Time and Day ________________________________________________ Additional Notes ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________...

  • Page 19: Appendix A - Sia Reporting Codes

    Appendix A - SIA Reporting codes SIA Communication Format: The SIA communication format used in this product follows the Level 2 specifications of the SIA Digital Communication Standard - February 1993. This format will send the Account Code along with a its data transmission. Below are the Zone Alarms & Alarm Restores (Zones 01-32) as well as any additional codes that can be transmitted;...
  • Page 20 AC Failure Trouble AT00/AR00 Bell Circuit Trouble UT99/UJ99 Fire Trouble FT00/FJ00 Auxiliary Power Supply Trouble YP00/YQ00 TLM Trouble Code (via Skyroute) LT00 General System Supervisory / Restore ET00/ER00 General System Trouble / Restore YX00/YZ00 TLM Restoral LR00 FTC Fail / FTC Restoral...

  • Page 21: Antenna Relocation Diagram

    • Move the antenna and bracket around until you get good signal strength. • Mount the antenna extension bracket at that location. • Reapply the AC and DC power to the Skyroute unit. No reprogramming is necessary.

  • Page 22: Supervised Power Supply Connection

    The keybus from the panel is connected to both the PC5204 and the Skyroute. A wire is connected from the AUX terminal on the PC5204 to the BELL IN of the Skyroute. A jumper or a normally closed switch is required between the TAM and the COM on the Skyroute.

  • Page 23: Standard Connection With Dsc Control

    • Call Connect 24's VRU to activate your Skyroute account. NOTE: If a Bell/Siren is not going to be used, wire the Bell/Siren terminals on the panel with a 1KW resistor, and then only wire the BELL (+) to the BELL IN of the Skyroute unit.
  • Page 24 Limited Warranty Sur-Gard Ltd. warrants that for a period of sixty months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use and that in fulfillment of any breach of such warranty, Sur-Gard Ltd. shall, at its option, repair or replace the defective equipment upon return of the equipment to its repair depot.
