Trust SC-5100 Quick Start Manual

SC-5100 5.1 Surround Soundcard
Product information
Adapter
A: Midi port
B: External analogue inputs and outputs
C: Attachment plate

Installation

Before installing the sound card, uninstall the drivers for other sound cards and, if necessary, disable
any onboard sound cards in the BIOS settings menu of the motherboard.
1 Turn off the PC and remove the plug from the plug socket.
2 Open the computer casing.
A: Optional: connect internal devices to the internal analogue inputs (see the diagram in point 19).
3
B: Insert the sound card in the PCI slot and screw the attachment plate to the PC casing.
4 Close the PC casing. Insert the plug into a plug socket and turn on the PC.
5 Click "Cancel".
6 Insert the Trust installation CD-ROM into the CD-ROM drive.
7 Select "Install driver".
8 Wait until the window shown in step 9 is displayed.
A: Select "Yes".
9
B: Click "OK" to restart the PC.
If using Windows 98 SE: insert the Windows 98 SE installation CD-ROM into the CD-ROM drive and
10
specify the folder "WIN98" on the CD-ROM.
Select the desired speaker settings (can also be selected later via steps 20 to 23) :
Setting
2 CH Headphones or stereo speakers.
11
4 CH 5.1 speaker set and audio inputs.*
5.1/6 CH 5.1 speaker set.
* The orange connection is now the audio input (LINE IN). Therefore, sound will not be emitted from the
low tone speaker (subwoofer) or the centre speaker.
12 Select "Install DirectX 9.0c".
A: Select "Accept".
13
B: Click "Next".
14 Click "Finish".
Used for
1
Connection
diagram
Step 16
Step 17
Step 15
UK
