INSTEON 2421-222 Owner's Manual

Open/close wireless sensor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Open/Close Sensor
®
INSTEON
Wireless Sensor
Model :
2843-222/2421

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2421-222 and is the answer not in the manual?

Questions and answers

Related Manuals for INSTEON 2421-222

Summary of Contents for INSTEON 2421-222

  • Page 1 Open/Close Sensor ® INSTEON Wireless Sensor Model : 2843-222/2421...

  • Page 2: Table Of Contents

    Resetting Open/Close Sensor to its Factory Default Settings..............10 ABOUT INSTEON ............................10 Using Dual-Band INSTEON Devices to Upgrade Your Network ............. 10 Important Note about INSTEON Networks; Split Single-Phase vs. 3-Phase Installation......11 Further Enhancing Reliability ........................11 Specifications, Certification and Warranty..................... 11 Specifications ............................

  • Page 3: About Open/Close Sensor

    Open/Close Sensor can wirelessly control lights or appliances throughout your home. Program any INSTEON device to react when the magnetic contact is broken and re-established on Open/Close Sensor: doors, windows, drawers, cabinets or anything else that opens. You can optionally connect an external contact closure sensor of any type (e.g., hidden contacts or doorbell button).

  • Page 4: What Is Insteon

    Reliable, because every INSTEON device works as a network repeater, ensuring your commands will not be lost. Affordable, because INSTEON can be integrated into any number of devices easily and at a very low cost. An INSTEON home grows in value with each added INSTEON device, making life more convenient, safe, and fun.

  • Page 5: Installation

    Jumper When the jumper is installed (default), Open/Close Sensor will send an INSTEON ON command when it opens and an OFF command when it closes. When the jumper is uninstalled (as in Multi-Scene Mode), Open/Close Sensor will activate scene 1 when it opens and activate scene 2 when it closes.

  • Page 6: Install Open/Close Sensor

    Open/Close Sensor Owner’s Manual Install Open/Close Sensor 1) RF-only devices require at least one dual-band INSTEON device, such as an Access Point (#2443), for communication. For the best INSTEON network performance, be sure you have properly installed at least two dual-band INSTEON devices.

  • Page 7: Using Open/Close Sensor As An Insteon Controller

    Remove Open/Close Sensor as a Controller If you are no longer going to use an INSTEON Responder that has been Linked to Open/Close Sensor, it is very important that you Unlink it. Otherwise, Open/Close Sensor will retry any commands repetitively, thus slowing down the system.

  • Page 8: Using Open/Close Sensor's Multi-Scene Mode

    2) Move the Open/Close Sensor magnet away from the main case, putting it in the open state If Open/Close Sensor was closed, its status LED will flash once 3) Unlink the desired responders from scene 1. See Unlinking an INSTEON Responder from Open/Close Sensor.

  • Page 9: Scenes

    INSTEON scenes are very easy to set up – just link more than one responder to the same on/off or scene button on a controller. Then, when you tap any of the linked buttons on the controller, all of the INSTEON devices linked in the scene will respond as a group.

  • Page 10: Restoring Power To Open/Close Sensor

    Resetting Open/Close Sensor to its Factory Default Settings The factory reset procedure can be used to clear the Open/Close Sensor memory of all INSTEON Links, etc. 1) If you are using Open/Close Sensor to control any responders, unlink them from Open/Close Sensor.

  • Page 11: Important Note About Insteon Networks; Split Single-Phase Vs. 3-Phase Installation

    It is possible that some audio-video devices, computers, power strips, or other electrical equipment may attenuate INSTEON signals on the power line. You can temporarily unplug suspected devices to test whether the INSTEON signal improves. If it does, then you can plug in filters that will permanently fix the problem.

  • Page 12: Limited Warranty

    For repair or replacement during the warranty period, call the INSTEON Support Line at 800-762-7845 with the Model # and Revision # of the device to receive an RMA# and send the product, along with all other required materials to: INSTEON ATTN: Receiving Dept.
