EDK84VHCE552
.>6v
L−force Drives
Montageanleitung
Mounting Instructions
Instructions de montage
Instrucciones para el montaje
Istruzioni per il montaggio
8400
3.0 ... 15 kW
E84AVHCExxxx HighLine C
Frequenzumrichter
Frequency Inverter
Convertisseur de fréquence
Convertidor de frecuencia
Inverter di frequenza
l
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lenze E84AVHCE HighLine C Series
Summary of Contents for Lenze E84AVHCE HighLine C Series
- Page 1 EDK84VHCE552 L−force Drives .>6v Montageanleitung Mounting Instructions Instructions de montage Instrucciones para el montaje Istruzioni per il montaggio 8400 3.0 ... 15 kW E84AVHCExxxx HighLine C Frequenzumrichter Frequency Inverter Convertisseur de fréquence Convertidor de frecuencia Inverter di frequenza...
- Page 2 Warnings! Operation of this equipment requires detailed installation and operation instructions provided in the Hardware manual intended for use with this product. This information is provided on the CD−ROM included in the container this device was packaged in. It should be retained with this device at all times. A hard copy of this information may be ordered by phone or e−mail, printed on the back of this document.
- Page 3 Danger ! Tension électrique dangereuse Les raccordements de puissance X100 et X105 sont susceptibles de véhiculer une ƒ tension dangereuse jusqu’à 3 minutes après une coupure réseau. Risques encourus : Mort ou blessures graves en cas de contact avec les raccordements de puissance ƒ...
- Page 4 8400HLC042 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 5 8400HLC063 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 6 [mm] [mm] 8400GG065 [kW] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [kg] E84AVHCE3024 E84AVHCE4024 3 ... 5.5 E84AVHCE5524 E84AVHCE7524 E84AVHCE1134 7.5 ... 15 E84AVHCE1534 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 7 X100 (400 V) X100 (400 V) X100 − TN, TT 3/N/PE AC 400 V / 500 V F1 … F3 +UG -UG X100 8400GG054 8400GG007 X100 − IT 3/N/PE AC 400 V / 500 V F1 … F3 +UG -UG X100 8400GG055 8400GG008...
- Page 8 X101 X101 X101 X101 8400GG056 8400GG010 COM, NC, NO [mm] [AWG] E84AVHCE3024 0.2 ... 1.5 E84AVHCE4024 24 ... 16 E84AVHCE5524 E84AVHCE7524 0.2 ... 1.5 E84AVHCE1134 24 ... 16 E84AVHCE1534 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 9 X105 − X106 X105 − X106 8400GG058 X105 X106 84MOTL001_a 84MOTL001_b U, V, W T1, T2 [mm] [Nm] [mm] [Nm] [mm] [AWG] [lb−in] [AWG] [lb−in] [AWG] E84AVHCE3024 1 … 6 2.5 … 16 0.2 ... 1.5 E84AVHCE4024 18 … 10 12 …...
- Page 10 X105 − X106 X105 − TN, TT " X105 J> 8400GG059 8400GG013 X105 − IT " X105 J> 8400GG060 8400GG013 X106 " X106 T1 T2 J> 8400GG061 8400GG017 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 11 8400HLC086 84MOTL001_d min. max. [mm] [mm] [AWG] 0.2 ... 1.5 24 ... 16 " DC 24 V (+19.2... +28.8 V) 8400HLC064 8400HLC045 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 12 X1 − X3 − X4 − X5 − X107 X1 − X3 − X4 − X5 − X107 8400HLC043 X3, X107 X4, X5 84MOTL001_e 84MOTL001_d 84MOTL001_f X107 X4, X5 min. max. min. max. min. max. [mm] [mm] [mm] [mm] [mm] [mm] [AWG] [AWG]...
- Page 13 X1 − X3 − X4 − X5 − X107 GND-A +10 V / 10 mA " 0 ...10 V 1k ... 10k 8400HLC050 8400HLC012 GND-O DC 24 V (+19.2...+28.8 V) 8400HLC046 8400HLC045 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 14 X1 − X3 − X4 − X5 − X107 GND-I 24 V int. DC 24 V (+19.2... +28.8 V) 8400HLC047 8400HLC045 X107 X107 " DC 24 V (+19.2...+28.8 V) 8400HLC044 8400HLC045 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 15 EDK84VHCE552 DE/EN/FR/ES/IT 3.0...
- Page 16 © 04/2009 Lenze Drives GmbH Service Lenze Service GmbH Postfach 10 13 52 Breslauer Straße 3 D−31763 Hameln D−32699 Extertal Germany Germany +49 (0)51 54 / 82−0 00 80 00 / 24 4 68 77 (24 h helpline) Ê Ê...
