Start Here
Installing your Microtek XT5830 HS, XT5820 HS and
XT5810 HS Scanner

Unpack Contents

Unpack your scanner package and check for
major components.
1. Scanner
2. Hi-Speed USB cable
3. Software CDs/DVDs
4. Power cord

Install Software

Important:
You must install software before
connecting your scanner.
Always close any open programs and turn off Anti-
virus utilities before installing software.
A. Turn on your computer.
B. Place the Microtek Software CD/DVD into a drive, and follow the on-screen
instructions to install the scanner driver and software.
C. Restart your computer at the end of all software installation.
NOTE: If the Microtek Software Installer screen does not come up automatically, double-click the
following in succession: "My Computer"; the CD/DVD-ROM icon; then cdsetup.exe to start the
installer program.
Copyright © 2015 Microtek International, Inc. http://www.microtek.com
I49-005063 A, April 2015
1
3
2
1
5
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT5830 HS and is the answer not in the manual?

Questions and answers

Related Manuals for Microtec XT5830 HS

Summary of Contents for Microtec XT5830 HS

  • Page 1: Install Software

    Start Here Installing your Microtek XT5830 HS, XT5820 HS and XT5810 HS Scanner Unpack Contents Unpack your scanner package and check for major components. 1. Scanner 2. Hi-Speed USB cable 3. Software CDs/DVDs 4. Power cord 5. Power adapter Install Software...

  • Page 2: Connect Scanner

    Connect Scanner To the power adapter A. Connect the power adapter to the back of the scanner. B. Plug one end of the power cord into the power adapter, and plug the other end of the power cord into a wall outlet or other power source. To the Hi-Speed USB cable C.

  • Page 3: Positioning Documents

    Positioning Documents 1. Raise the scanner lid. 2. Place the document to be scanned facing down on the glass surface of the scanner. Position the top end of the document toward the left side of the scanner, with its edge firmly aligned against the vertical ruler of the scanner (shown in the graphic below).

  • Page 4: Scanning Documents

    Scanning Documents 1. Put the document to be scanned facing down on the scanner’s scan bed. 2. Launch ScanWizard DI as a stand-alone program by clicking on the ScanWizard DI icon on the desktop. 3. Click the Scan Setup button in the interface to activate the Scan Setup interface. 4.
  • Page 5 7. Go to the “General” panel by clicking the General tab in the Settings window. Specify the settings for your requirements there. a) Select the image type in the Document Type as your input image type. – Select Photo to scan color prints. –...
  • Page 6 File Location menu box Click on a thumbnail image to enlarge it in the Image View Window at the right side of the interface. AP control panel (Main interface) TWAIN driver control panel (Scan Setup interface)
  • Page 7 Problems? The Multi-color LED on the button indicates the status of the scanner. Off: Scanner is off Green On: Ready to scan Flashing Green: Scanning or sleeping Red On: Error or USB disconnecting when powered up First, make sure that you have followed Steps 1 to 3 as described in this guide (unpack, install, connect).
  • Page 8 Do You Need Assistance? Manuals If you have additional questions and need further instruction or information, we provide electronic manuals for: 1. Using your scanner (scanner’s User’s Manual) 2. Using the ScanWizard DI To access the electronic manuals: Insert the scanner’s software CD/DVD into your computer’s CD/DVD-ROM drive.
