UM-7GP0A-000-00
SHIMANO STEPS special battery and
Lithium-ion battery
BT-E6000
BT-E6001
BT-E6010
BT-E8010
BT-E8014
BT-E8020
BT-E8035
Battery charger
EC-E6000
EC-E6002
EC-E8004
Battery mount
BM-E6010
BM-E8010
BM-E8020
BM-E8030
BM-E8031
SHIMANO Total Electric Power System
parts user's manual
Satellite power button
EW-SW100
Satellite charging port
EW-CP100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT-E6000 and is the answer not in the manual?

Questions and answers

Related Manuals for Shimano Steps BT-E6000

Summary of Contents for Shimano Steps BT-E6000

  • Page 1 UM-7GP0A-000-00 SHIMANO Total Electric Power System SHIMANO STEPS special battery and parts user's manual Lithium-ion battery Satellite power button BT-E6000 EW-SW100 BT-E6001 BT-E6010 Satellite charging port BT-E8010 EW-CP100 BT-E8014 BT-E8020 BT-E8035 Battery charger EC-E6000 EC-E6002 EC-E8004 Battery mount BM-E6010 BM-E8010...

  • Page 3: Table Of Contents

    CONTENTS IMPORTANT NOTICE ..................2 GENERAL SAFETY INFORMATION ..............2 TO ENSURE SAFETY ..................2 Introduction ....................5 Items for regular inspection before riding the bicycle ........5 Handling method ..................5 Charging time ........................5 Battery storage method ......................5 Battery life .........................5 Used batteries ........................5 Names of parts .....................7 Main specifications ..................8 Charging method ..................9 When charging the battery alone ...................9...

  • Page 4: Important Notice

    • Also, read the SHIMANO STEPS user's manual. • Do not use it while it is wet, and do not touch or hold it with For safety, be sure to read this user’s wet hands.
  • Page 5 • If the battery does not become fully charged after • Do not use the battery charger with commercially-available two hours of charging, immediately unplug the electrical transformers designed for overseas use (travel battery from the electrical outlet and contact the converters).
  • Page 6 • Use the product under the supervision of someone • Do not bundle the cables. responsible for safety and upon receiving usage • Do not hold the battery charger by the cables when carrying instructions. Do not allow physically, sensory, or mentally impaired persons, inexperienced persons, •...

  • Page 7: Introduction

    • When there is dirt on the terminals of the battery mount and Handling method battery charger, remove the battery, remove the power plug from the electrical outlet, and then clean them with a waste cloth or cotton bud dampened with ethanol, etc. If you „...
  • Page 8 FCC compliance information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 9: Names Of Parts

    Names of parts EC-E6000 Charging plug LED lamp Battery charger EC-E6002 Power cord connector Charging plug LED lamp SM-BCC1 (sold separately) Battery charger SM-BCC1 Insert into the connector * Insert it fully EC-E8004 Charging plug LED lamp Battery charger Adapter (sold separately) SM-BTE60 SM-BTE80...

  • Page 10: Main Specifications

    EC-E6000: 100 - 240 V AC, 2.5 A, 50/60 Hz Input EC-E6002: 100 - 240 V AC, 1.5 A, 50/60 Hz EC-E6000: 40 V DC, 4.4 A/42 V DC, 4.0 A Output EC-E6002: 42 V DC, 1.8 A SHIMANO BT-E6000, BT-E6001, BT-E6010, BT-E8010, BT-E8014, Compatible batteries BT-E8020, BT-E8035...

  • Page 11: Charging Method

    When charging, orient the battery and the battery charger as indicated in the figure. * The orientation of the socket differs according to the battery specifications. BT-E6000/BT-E6001/BT-E6010/BT-E8035 Attach the adapter to the battery charger’s charging plug. Connect the battery charger’s power plug to the electrical outlet.
  • Page 12 BT-E8010/BT-E8014/BT-E8020 BT-E8010/BT-E8014 Connect the battery charger’s power plug to the electrical outlet. Battery Charging port Insert the charging plug into the battery's charging port. * Charge the battery on a flat surface indoors. Charging plug BT-E8020 Battery Charging plug Charging port...

  • Page 13: When Charging The Battery While It Is Mounted On The Bicycle

    * Charge the battery on a flat surface indoors. * Place the battery charger main body on a steady surface such as the floor before charging. * Stabilize the bicycle when charging so that it does not fall over. BT-E8020 BT-E6000/BT-E6001 Battery mount Charging port Charging plug...
  • Page 14 Firmly close the charging port cap after charging. Charging port Charging port Charging port BM-E6000 BM-E6010 EW-CP100...

  • Page 15: Charger Led Lamp

    For information on the charging time, refer to the following. Designated charging time Charging time from a battery level of 0% Battery EC-E6000 EC-E6002 EC-E8004 BT-E6000, BT-E6010, BT-E8014 About 4 hours About 6.5 hours About 3.5 hours BT-E6001, BT-E8010, BT-E8020, BT-E8035 About 5 hours About 7.5 hours...

  • Page 16: Battery Led Lamp

    „ Battery LED lamp Regarding the battery LED lamp The current charge status can be checked via the LED lamp on the battery. Battery LED lamp Battery LED lamp Charging Battery LED lamp x 5 Lighting pattern*1 Charging status 0 - 20% 21 - 40% 41 - 60% 61 - 80%...
  • Page 17 Battery level indicator You can press the power switch to check the current battery level. Battery LED lamp x 5 Lighting pattern*1 Battery level 100 - 81% 80 - 61% 60 - 41% 40 - 21% 20 - 1% (if the battery is not attached to the bicycle) 0% (if the battery is attached to the bicycle) : Does not light up : Lights up...

  • Page 18: Installing The Battery

    - That the key has not been left in the battery NOTICE Confirm that the cap of the charging port is closed before riding. BT-E6000/BT-E6001 Insert the battery into the rail from the rear of the bicycle. • Slide the battery to the front and push it in firmly.
  • Page 19 BT-E8010/BT-E8014 Insert the battery from its base. • Align the indentation in the bottom of the battery with the convex section on the mount and insert the battery. Slide the battery. • Insert the battery until you hear a click. Remove the key.

  • Page 20: Removing The Battery

    • Firmly hold the battery when removing or carrying it to make sure that you do not drop it. BT-E6000/BT-E6001 The position of the key does not affect battery insertion. The battery can be inserted regardless of the key position.
  • Page 21 Carefully remove the battery. The battery can only be removed when the key is in the unlock position. BT-E8010/BT-E8014 BT-E6010 Insert the key. Power switch Turn the power OFF, and then insert the key into the key cylinder of the battery mount. BT-E8010/BT-E8014 Power switch Key cylinder...
  • Page 22 Remove the battery. • Slide the battery to the left to remove it, while taking care not to drop it. • Only put the key in the unlock position when removing the battery. BT-E8020 • This section describes an example of a frame design where the battery is removed/installed from the bottom. •...
  • Page 23 Release the battery lock. (1) Insert the key into the key cylinder of the battery mount. (2) Turn the key. (3) Push the key in. The battery is unlocked. The spring on the plate retains the battery in the designated position and prevents it from falling out.
  • Page 24 BT-E8035 • This section describes an example of a frame design where the battery is removed/installed from the bottom. • When using a battery cover from another manufacturer, remove the battery cover before removing the battery. Turn the power OFF. If there is a keyhole cap, open it.
  • Page 25 Remove the battery. Carefully remove the battery while supporting it with your Double latch plate hand and pushing the double latch plate.

  • Page 26: Power On/Off

    „ Power ON/OFF • The power cannot be turned ON while charging. • When the bicycle has been stopped for 10 minutes, the auto power OFF function automatically switches the power OFF. NOTICE • Do not step on the pedal when turning the power ON/OFF. Doing so may cause a system error. •...
  • Page 27 Power ON from battery when the battery is installed With the BT-E8010/BT-E8020/BT-E8035, press and hold the power switch for 6 seconds to force the power OFF. Press the battery power switch. The LED lamp turns on and the battery level is indicated. BT-E6000/BT-E6001 BT-E8010/BT-E8014 Power switch...

  • Page 28: Troubleshooting

    TROUBLESHOOTING „ TROUBLESHOOTING Symptoms Causes/possibilities Remedies Has the battery level been left at 0% for an Charge the battery. If the LED does not light up The battery LED does not light extended period of time? Or, have you not after charging the battery, contact the place of charged the battery after purchase? purchase.
  • Page 29 Symptoms Causes/possibilities Remedies Check whether any foreign material is attached Is the charging plug of the battery charger to the connection area, and remove and securely inserted into the battery? reconnect the charging plug. If the problem is not resolved, contact the place of purchase. The battery charger LED does The LED turns off when the battery is fully not light up.

  • Page 30: Battery Led Lamp Error Indication

    Symptoms Causes/possibilities Remedies Is the (main) battery level too low? Charge the (main) battery. If you press the satellite power button, the LED lights up for a Check that the (main) battery is securely short period of time, but it Is the (main) battery properly connected? connected.
  • Page 31 Lighting pattern*1 Indication conditions Recovery Error code*2 Make sure that the cable is not loose or Communication error with the improperly connected. E024 bicycle system If the situation does not improve, contact the place of purchase. Remove the battery charger from the (Repeatedly flashes red 4 times) This is displayed if an error battery and press the power switch.
  • Page 32 One Holland, Irvine, California 92618, U.S.A. Phone: +1-949-951-5003 High Tech Campus 92, 5656 AG Eindhoven, The Netherlands Phone: +31-402-612222 3-77 Oimatsu-cho, Sakai-ku, Sakai City, Osaka 590-8577, Japan Please note: specifications are subject to change for improvement without notice. (English) © Apr. 2019 by SHIMANO INC. ITP...
