- Page 1 Rack Mount Panel PC 17”/ 19”/ 24” Touchscreen Intel® Core™ i7 4650U 3.30 GHz Military Grade R17IH3S-MLA1-89 Model No: R19IH3S-MLA3-89 W24IH3S-MLS1-89 User Manual Version 1.0 Document Part No. 9152111I100U...
-
Page 2: Table Of Contents
USER MANUAL PREFACE CONTENTS PREFACE ..........................- 4 - ABOUT THIS USER MANUAL ....................- 11 - CHAPTER 1: INTRODUCTION ....................- 13 - 1.1 Product Features ......................- 13 - 1.2 Hardware Specifications ....................- 14 - 1.4 Package Contents ......................- 15 - 1.5 Appearance ........................ - Page 3 6.3 Using Recovery Wizard to Restore Computer ............... - 84 - CHAPTER 7: TECHNICAL SUPPORT ................... - 87 - 7.1 Introduction ........................- 87 - 7.1.1 Winmate Download Center ................. - 88 - 7.1.2 Winmate File Share ..................... - 88 - 7.2 Problem Report Form ....................- 89 - APPENDIX A: MIL-STD-810F/G COMPLIANCE ................
-
Page 4: Preface
USER MANUAL PREFACE PREFACE Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 5 USER MANUAL PREFACE Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
- Page 6 USER MANUAL PREFACE Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
- Page 7 USER MANUAL PREFACE Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
- Page 8 USER MANUAL PREFACE Safety Precautions For your safety carefully read all the safety instructions before using the device. All cautions and warnings on the equipment should be noted. Keep this user manual for future reference. CAUTION/ATTENTION Do not cover the openings! Ne pas couvrir les ouvertures! *Let service personnel to check the equipment in case any of the following problems appear:...
- Page 9 USER MANUAL PREFACE Important Information Countries/ Symbol This equipment complies with essential requirements of: Area European Electromagnetic Compatibility Directive(2014/30/EU) Union Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules.
- Page 10 USER MANUAL PREFACE European Union This equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010 EN 55022: 2010 Class B o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012...
-
Page 11: About This User Manual
USER MANUAL CONTENTS ABOUT THIS USER MANUAL This User Manual provides information about using the Winmate® Military Grade Panel PC (IH32). The documentation set for the Military Grade Panel PC (IH32) provides information for specific user needs, and includes: Military Grade Panel PC (IH32) User Manual – contains detailed description on how to use the device, its components and features. -
Page 12: Chapter 1: Introduction
USER MANUAL CHAPTER 1 INTRODUCTION INTRODUCTION This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the Panel PC in the packing list. - 12 -... -
Page 13: Product Features
CHAPTER 1 INTRODUCTION CHAPTER 1: INTRODUCTION Thank you for choosing Winmate® Military Grade Panel PC. This series feature low power high performance CPU with fanless design. Anti-corrosive coating with aluminum alloy housing withstands the harshest military environments. Armored connectors MIL- DTL-38999 (type I and III) initially developed for aerospace industry perfectly fit in our Military grade product line. -
Page 14: Hardware Specifications
USER MANUAL CHAPTER 1 INTRODUCTION 1.2 Hardware Specifications Model Name R17IH3S-MLA1-89 R19IH3S-MLA3-89 W24IH3S-MLS1-89 Display Size 17” 19” 24” Resolution 1280 x 1024 1280 x 1024 1920 x 1200 Brightness 350 cd/ (typ.) 350 cd/ (typ.) 300 cd/ (typ.) Contrast Ratio 1000:1 (typ.) -
Page 15: Package Contents
USER MANUAL CHAPTER 1 INTRODUCTION 1.4 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: CD-ROM with Driver Panel PC... -
Page 16: Appearance
USER MANUAL CHAPTER 1 INTRODUCTION 1.5 Appearance This section includes appearance and input/ output connectors’ layout. 1.5.1 Appearance - 16 -... -
Page 17: On-Screen Display Control
USER MANUAL CHAPTER 1 INTRODUCTION 1.5.2 On-Screen Display Control On-Screen Display (OSD) is a user-friendly interface to remote the display function and to adjust the display’s image properties. It also supports special Hot Keys for easy control, such as auto-adjustment and brightness control for backlight. 1.5.2.1 Control Keys Icon Button... - Page 18 USER MANUAL CHAPTER 1 INTRODUCTION 1.5.2.2 LED Indicators Indi Color Definition cato PWR Green Power is ON and the device functions normally Orange Panel PC is suspended HDD Green HDD is active HDD is inactive The function of OSD buttons is locked Lock function disabled - 18 -...
-
Page 19: Dimensions 17
USER MANUAL CHAPTER 1 INTRODUCTION 1.6 Dimensions This section includes mechanical drawing and dimensions of Panel PCs. 1.6.1 Dimensions 17” Unit: mm *Tolerance of all dimensions is shown as follow 0~30 mm ± 0.1 mm, 30~50 mm ± 0.15 mm, 50~120 mm ± 0.2 mm, above 120 mm ± 0.25 mm. - 19 -... -
Page 20: Dimensions 24
USER MANUAL CHAPTER 1 INTRODUCTION 1.6.2 Dimensions 19” Unit: mm *Tolerance of all dimensions is shown as follow 0~30 mm ± 0.1 mm, 30~50 mm ± 0.15 mm, 50~120 mm ± 0.2 mm, above 120 mm ± 0.25 mm. - 20 -... - Page 21 USER MANUAL CHAPTER 1 INTRODUCTION 1.6.3 Dimensions 24” Unit: mm **Tolerance of all dimensions is shown as follow 0~30 mm ± 0.1 mm, 30~50 mm ± 0.15 mm, 50~120 mm ± 0.2 mm, above 120 mm ± 0.25 mm. - 21 -...
- Page 22 USER MANUAL CHAPTER 2 GETTING STARTED GETTINGS STARTED This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. - 22 -...
-
Page 23: Chapter 2: Getting Started
USER MANUAL CHAPTER 2 GETTING STARTED CHAPTER 2: GETTING STARTED This chapter provides information on how to connect the device to the source of power, connector pinouts and the guideline to turn on/off the Panel PC. 2.1 Powering On 2.1.1 Power Considerations The device operates on external DC power. -
Page 24: Connecting The Power
USER MANUAL CHAPTER 2 GETTING STARTED 2.1.2 Connecting the Power 2.1.2.1 Connecting to AC Input Power Source (Default) 1. Connect one end of the Military Grade power connector MIL-DTL-38999/1 to the Panel PC. 2. Plug the other end of the power connector in to a working AC outlet. AC Power Requirements: AC Input 115~230V AC 50-60Hz... - Page 25 USER MANUAL CHAPTER 2 GETTING STARTED 2.1.2.2 Connecting to DC Input Power Source (Optional) 1. Insert the exposed wires of the DC Power Cable to the appropriate connectors on the terminal block plug. 2. Plug the terminal block plug firmly to the DC IN Jack. 3.
-
Page 26: Connecting Other Devices
USER MANUAL CHAPTER 2 GETTING STARTED 2.2 Connecting Other Devices Note that all the connectors are military grade and comply with military standard. AC IN RS-232 USB 2.0 LAN WARNING!/ AVERTISSEMENT! Make sure the power is off when connecting and disconnecting the connectors. -
Page 27: Vga Connector
USER MANUAL CHAPTER 2 GETTING STARTED 2.2.2 VGA Connector Plug one end of the 15-pin D-Sub signal cable (CN1) to the video signal MIL-DTL-38999/3 connector at the rear of the PC system and the other end (CN2) to the display. Pin №... -
Page 28: Rs-232 Connector
USER MANUAL CHAPTER 2 GETTING STARTED 2.2.3 RS-232 Connector Connect one side of the serial port cable to the MIL-DTL-38999/3 RS-232 connector on the Panel PC (CN1) and the other side to Serial COM interface (CN2). Pin № Symbol Color Pin №... -
Page 29: Usb 2.0 A Type Connector
Military Grade Rack Mount Panel PC has a USB 2.0 is a MIL-DTL-38999/3 connector. Use military grade USB 2.0 cable (not supplied by Winmate) to connect the panel PC to the external USB 2.0 compatible device, for example mouse or keyboard. -
Page 30: Turning On /Off
USER MANUAL CHAPTER 2 GETTING STARTED 2.4 Turning ON /OFF To Turn ON the Panel PC: 1. Tap the power button to turn the Panel PC on. 2. Press “DEL” to enter the CMOS setting and check the BIOS setup. The Power Switch is located on the front side OSD panel. -
Page 31: Chapter 3: Mounting
USER MANUAL CHAPTER 3 MOUNTING MOUNTING This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. -
Page 32: Cable Mounting Considerations
USER MANUAL CHAPTER 3 MOUNTING CHAPTER 3: MOUNTING This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. Suivez les instructions de montage et d'utilisation recommandé... -
Page 33: Safety Precautions
USER MANUAL CHAPTER 3 MOUNTING 3.2 Safety Precautions Observe the following common safety precautions before installing any electronic device: •Use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must be crossed make sure the wires are perpendicular at the intersection point. - Page 34 USER MANUAL CHAPTER 3 MOUNTING Mounting Steps: 1. Prepare a fixture for the specific dimensions of the device. 2. Cut a hole on a sub frame or panel according to the cutout dimensions. 3. Install the device properly onto the cutout area of the sub frame or panel with the sides of the front bezel.
-
Page 35: Vesa Mounting
USER MANUAL CHAPTER 3 MOUNTING 3.3.2 VESA Mounting Military Rack Mount Panel PC supports VESA Mount installation. Notice that VESA Plate is not included in Winmate’s standard accessories package. Tools Needed VESA Plate 100 x 100 mm *with customer’s bracket Mounting Steps: 1. -
Page 36: Chapter 4: Maintenance
USER MANUAL CHAPTER 3 MOUNTING MAINTENANCE This chapter provides information on regular cleaning and maintenance procedures. Follow all the recommendations included in this chapter in order to ensure long product lifecycle. - 36 -... -
Page 37: Cleaning The Display Screen
USER MANUAL CHAPTER 4 MAINTENANCE CHAPTER 4: MAINTENANCE This chapter includes regular cleaning and maintenance procedures. Follow all the recommendations in this chapter in order to ensure long product lifecycle. This equipment is extremely rugged and does not require a lot of maintenance. Remember that electrical equipment should be handled with care and used accordingly to its specifications. -
Page 38: Chapter 5: Driver Installation
USER MANUAL CHAPTER 4 MAINTENANCE DRIVER INSTALLATION This chapter describes how to install all necessary drivers. - 38 -... -
Page 39: Chipset Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION CHAPTER 5: DRIVER INSTALLATION This chapter provides guideline to driver installation. 5.1 Chipset Driver The Intel Chipset Drivers should be installed first before the software drivers enable Plug & Play INF support for Intel chipset components. Follow the instructions below to complete the installation. - Page 40 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 2 Click “Next” to start the installation. Step 3 Click “Next” to continue the installation. - 40 -...
- Page 41 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 4 Click “Yes, I want to restart this computer now” to finish installation. - 41 -...
-
Page 42: Graphics Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.2 Graphics Driver You need to install the Graphic driver to enable the function. Intel Graphic supports versatile display options and 32-bit 3D graphics engine. Triple independent display, enhanced display modes for widescreen flat panels for extend, twin, and clone display mode. - Page 43 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 2 Click “Next” to install the driver. Step 3 Click “Yes” to agree with the license terms. - 43 -...
- Page 44 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 4 Click “Next” to install the driver. Step 5 Click “Yes, I want to restart this computer now” to finish installation. - 44 -...
-
Page 45: Audio Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.3 Audio Driver The ALC886 series are high-performance 7.1+2 Channel High Definition Audio Codecs providing ten DAC channels that simultaneously support 7.1 sound playbacks, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. - Page 46 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 3 Click “Yes, I want to restart my computer now” to finish the installation. - 46 -...
-
Page 47: Ethernet Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.4 Ethernet Driver You must confirm which operating system is used on the IH32 Motherboard before installing the Ethernet drivers. Follow the steps below to complete the installation of the Intel® I210IT Gigabit-LAN Controller + I218LM Gigabit-LAN drivers. You will quickly complete the installation. - Page 48 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 2 Extract the “PROWinX64_19.0” file and click “Next” to install the driver. Step 3 Click “Next” to agree with the license terms. - 48 -...
- Page 49 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 4 Click “Next” to install the driver. Step 5 Click “Finish” to complete the driver installation. - 49 -...
-
Page 50: Intel® Management Engine Software
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.5 Intel® Management Engine Software This installation program installs the Intel® ME software components required for the platform on which you are installing, and installs only those components that match your platform’s capabilities. Step 1 Insert the driver CD and select the “Intel ME 10.0” folder and click “Setup.exe” - 50 -... - Page 51 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 2 Click “Next” to continue the installation. Step 3 Click “Yes” to agree with the License terms. - 51 -...
- Page 52 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 4 Choose “I accept the terms of the license agreement”, and click “Next” to continue. Step 5 Click “Finish” to complete the software installation. - 52 -...
-
Page 53: Usb 3.0 Driver Installation (Windows 7)
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.6 USB 3.0 Driver Installation (Windows 7) NOTE: If the operating system of your device is Windows 10 IoT, Windows Embedded 8.1 Industry, Windows Embedded 8 Standard, users can skip this installation. Step 1 Locate the hard drive directory where the driver files are stored with the browser or the explore feature of Windows*. - Page 54 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 4 Read the License Agreement and click “Yes” to proceed. Step 5 Review Readme File Information and click “Next” to proceed - 54 -...
- Page 55 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 6 When the Setup Progress is complete click “Next” to proceed. - 55 -...
- Page 56 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 7 Click “Yes, I want to restart this computer now” to finish and then restart your computer. - 56 -...
-
Page 57: Chapter 6: Bios Setup
USER MANUAL CHAPTER 6 BIOS SETUP BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the Panel PC for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. - 57 -... -
Page 58: How And When To Use Bios Setup
USER MANUAL CHAPTER 6 BIOS SETUP CHAPTER 6: BIOS SETUP 6.1 How and When to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press Del key when the prompt appears on the screen during start up. The prompt screen shows only few seconds so need press Del key quickly. -
Page 59: Bios Functions
USER MANUAL CHAPTER 6 BIOS SETUP 6.2 BIOS Functions The IH32 motherboard has AMI BIOS built-in and a CMOS SETUP utility that allow users to configure required settings or to activate certain system features. The follwoing sections describe the configuration options found in the menu items. 6.2.1 Main Menu The Main menu displays the basic information about yoursystem including BIOS version, processor RC version, system language, time, and date. -
Page 60: Advanced Settings
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2 Advanced Settings Select the Advanced Tab from the IH32 setup menu to enter the advanced BIOS setup screen. You can select any of the items on the left frame of the screen to go to the sub menu for the item, such as CPU Configuration. - Page 61 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI Enter Opens submenu settings RTC Wake Configures RTC Enter Opens submenu Settings Wake parameters Trusted Configures Trusted Enter Opens submenu Computing Computing parameters Configures CPU Enter Opens submenu Configuration...
- Page 62 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.1 ACPI Settings BIOS Setting Description Setting Option Effect Enable ACPI Auto BIOS ACPI Auto Enable/ Disable Enables or Configuration Configuration Disables this function Enable Control Enable/ Disable Enables or Hibernation hibernation Disables this function - 62 -...
- Page 63 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.2 RTC Wake BIOS Setting Description Setting Option Effect Wake system with System awake on Enabled/ System will awake Fixed Time alarm events. Disabled at the hr: min: sec specified Wake system with S set the system to Enabled/ System will awake Dynamic Time...
- Page 64 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.3 Trusted Computing BIOS Setting Description Setting Option Effect Security Device Enable or disable Enabled/Disabled Set desirable Support BIOS support for configuration security device TPM State Enable or disable Enabled/Disabled Set desirable TPM state. configuration - 64 -...
- Page 65 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.4 CPU Configuration CPU Configuration allows you to change CPU settings. Use key arrows to navigate through the menu. - 65 -...
- Page 66 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.5 SATA Configuration BIOS Setting Description Setting Option Effect SATA Controller (s) Allows users to Enabled/ Set desirable enable or disable Disabled configuration the SATA controller (s) SATA Mode Allows users to Enabled/ Set desirable Selection select mode of Disabled...
- Page 67 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.6 Intel® Rapid Start Technology Allows users to enable or disable Intel rapid start technology. 6.2.2.7 PCH (FW) Configuration - 67 -...
- Page 68 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.8 USB Configuration - 68 -...
- Page 69 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect Legacy USB User can enable or Disabled Will keep USB Support disable USB port. devices available only for EFI applications. Enabled Enable all the USB devices XHCI Hand‐off This is a Disabled Disables this...
- Page 70 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.9 F81866 H/W Monitor BIOS Setting Description Setting Option Effect Smart Fan Set parameters of Enable or disable Enabled/ Disabled Function smart fan function this function Smart Fan Mode Configuration Configure smart fan mode settings - 70 -...
- Page 71 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.10 F81866 Super IO Configuration BIOS Setting Description Setting Option Effect Setting Serial Port User can Enable/Disable Enable or Disable Parameters Enable/Disable the Serial Port (COM). serial port and Default: Enable select optimal settings for the Super IO Device.
- Page 72 USER MANUAL CHAPTER 6 BIOS SETUP Pin 3~ Pin 10 Control Settings. - 72 -...
- Page 73 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.11 Serial Port RS232/RS422/RS485 Settings BIOS Setting Description Setting Option Effect Serial Port Select Serial Port RS232 / RS422 Choose Serial Port RS485 (Rx)/ Settings RS485(Tx) Change Settings Allow Change [AUTO] Serial Port Settings UART Mode Show which serial port is used - 73 -...
-
Page 74: Chipset Menu
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.3 Chipset Menu - 74 -... - Page 75 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.3.1 PCH- IO Configuration BIOS Setting Description Setting Option Effect PCI Express Detail of PCI Set desirable Configuration Express items. parameters Details of USB Set desirable USB Configuration items parameters Enables or PCH LAN Enabled/ Set desirable disables the...
- Page 76 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.3.2 PCI Express Configuration BIOS Setting Description Setting Option Effect DMI Link ASPM Allows users to Enabled/ Set desirable Control enable or disable Disabled parameters the DMI Link ASPM Control DMI Link Extended Allows users to Enabled/ Set desirable Synch Control...
- Page 77 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.3.4 USB Configuration BIOS Setting Description Setting Option Effect USB Precondition Allows user to Enabled/ Set desirable enable or disable Disabled parameters USB precondition XHCI Mode Allows user to [Smart Auto] Set desirable enable or disable parameters XHCI mode.
- Page 78 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.3.5 System Agent (SA) Configuration Allows users to enable or disable VT-d. - 78 -...
- Page 79 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.3.6 Graphics Configuration BIOS Setting Description Graphics Turbo IMON Current Allows users to select which Graphics Turbo IMON Current Internal Graphics Allows users to enable or disable IGD Aperture Size This item allows users to select aperture size DVMT Pre-Allocated Allows users to select DVMT pre-...
-
Page 80: Boot Menu
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.4 Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS use to look for a boot device from which to load the operating system. -
Page 81: Security Menu
USER MANUAL CHAPTER 6 BIOS SETUP Fast Boot Enables or Disabled Disables this disables Fast Boot function to shorten the OS Enabled Enables this boot process. function (Default: Disabled). Boot Option Specifies the Ex: Boot Option#1 Hard drive as the Priorities overall boot order (hard drive) -
Page 82: Save & Exit
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.6 Save & Exit BIOS Setting Description Setting Option Effect Save Changes and This saves the Enter <YES> Save changes Exit changes to the CMOS and exits the BIOS Setup program. Discard Changes This exits the BIOS Enter <YES>... - Page 83 USER MANUAL CHAPTER 6 BIOS SETUP Save Changes Save changes done Enter <YES> Saves the changes so far to any of the setup options. Enter <NO> Return to the BIOS Setup Main Menu Discard Changes Discard changes Enter <YES> Saves the changes done so far to any of the setup Enter <NO>...
-
Page 84: Using Recovery Wizard To Restore Computer
USER MANUAL CHAPTER 6 BIOS SETUP 6.3 Using Recovery Wizard to Restore Computer IH32 motherboard has a dedicate recovery partition stored on the hard drive of the PC to enable quick one-key recovery process. This partition occupies about 11GB of the storage space, and comes built-in to each IH32 series PC. - Page 85 USER MANUAL CHAPTER 6 BIOS SETUP - 85 -...
-
Page 86: Chapter 7: Technical Support
USER MANUAL CHAPTER 6 BIOS SETUP Technical Support This chapter includes directory for technical support and Software Development Kit (SDK). - 86 -... -
Page 87: Introduction
1_Chipset 2_Graphics 3_Audio 4_Network Connections 5_ME 6_USB3.0 Winmate provide the following SDK for Military Grade Rack Mount Panel PC with Intel® Core i7 4650U 3.30GHz processor: Item File Type Description Watchdog SDK To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. -
Page 88: Winmate Download Center
USER MANUAL CHAPTER 7 TECHNICAL SUPPORT 7.1.1 Winmate Download Center Go to http://www.winmate.com/ > Support > Download Center > Military Panel PC (IH32) Or follow the link: http://www.winmate.com/DownCenter/DownLoadCenter.asp?DownType=2302 7.1.2 Winmate File Share Go to http://www.winmate.com/ > Support > File Share > Public Documents > Panel PC>... -
Page 89: Problem Report Form
USER MANUAL CHAPTER 7 TECHNICAL SUPPORT 7.2 Problem Report Form Military Grade Rack Mount Panel PC Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: _____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible. -
Page 90: Appendix A: Mil-Std-810F/G Compliance
USER MANUAL CHAPTER 7 TECHNICAL SUPPORT MIL-STD-810F/G COMPLIANCE This section includes information on testing methods and procedures in compliance with military standard MIL-STD-810 F/G. Appendix - 90 -... - Page 91 USER MANUAL APPENDIX A MIL-STD-810F/G COMPLIANCE APPENDIX A: MIL-STD-810F/G COMPLIANCE This section includes information on testing methods and procedures in compliance with military standard MIL-STD-810 F/G. MIL-STD-810F/G Compliance Test Reference Condition * Humidity Method 507.5 30 to 60℃ ± 2℃, 95% RH ± 3% Method 514.6, 5 ~ 500 Hz, 1.48/1.90/2.24 Grms, * Vibration...
-
Page 92: Appendix B: Mil-Std-461E/F Compliance
USER MANUAL APPENDIX A MIL-STD-810F/G COMPLIANCE MIL-STD-461E/F COMPLIANCE This section includes information on testing methods and procedures in compliance with military standard MIL-STD-461E/F Appendix - 92 -... - Page 93 USER MANUAL APPENDIX B MIL-STD-810E/F COMPLIANCE APPENDIX B: MIL-STD-461E/F COMPLIANCE This section includes information on testing methods and procedures in compliance with military standard MIL-STD-461 E/F. MIL-STD-461E/F Compliance Test Description Type Frequency Range CE101 Power Leads Conducted Emission 30 Hz ~ 10 kHz *CE102 Power Leads Conducted Emission 10 kHz ~ 10...
- Page 94 USER MANUAL APPENDIX B MIL-STD-810E/F COMPLIANCE Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, Taipei 241, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
