Prudential Bionic 4 Installation Instructions

I n s ta l l at I o n I n s t r u c t I o n s
Bionic 4 — PERIMETER, CONTINUOUS RUN X1, X2, X6
™
6˝
Flush
PARTS ShIPPEd SEPARATEly
WALL RAIL
Wall Rail Trim & Wall Trim
Aligner Splines Adjustable Hanger
Brackets
X3/X7 Start/End Unit
Lens Removal Tool 8-32 x 3/8˝ Self-tapping
Machine Screws
Notes:
1. Housing ships separated from gear tray, reflectors and lens.
for easy installation (gear tray for STG only).
2. Remove specular reflector protective coating (if required).
3. Install lamps (by others).
5- 1 / ˝
2
1) Identify housing:
Lens
T-bar Brackets
Overhead Mounting
Bracket
Intermediate Unit
1774 East 21st Street, Los Angeles, CA 90058 • 213-746-0360 • www.prulite.com
6˝
Regressed
Start/End units are capped on one end.
Intermediate units are not capped.
Individual units are capped on both ends.
X3/X7 Start/End Unit
X1/X2/X6
X1/X2/X6 Start/
Start/End Unit
End/Individual
