Partner MF-2352 Quick Start Manual

C5/MF-2352 Quick Start Guide
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
( 1 ) This device may not cause harmful interference, and ( 2 ) this device must accept any interference received,
including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Non-modification Statement
Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user
authority to operate the equipment.
SAR notice
The highest SAR value for the device as reported to the FCC is less than 1 . 6 W/kg (limit set by the FCC is 1 . 6 W/kg)
when placed next to the body. The FCC has granted an Equipment Authorization for this device with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines.
Taiwan NCC
一�設� 低功率電波輻射性電機管理辦法第 � 條
( 12 14 )
經型式認證合格之低功率射頻電機 ， 非經國家通訊傳播委員會
•
變更原設計之特性及功能 。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信 ； 經發現有干擾現象時 ， 應立即停用 ， 並改善至無干擾時方得繼續使用 。
•
前項合法通信 ， 指依電信法規定作業之無線電通信 。 低功率射頻電機須忍受合法通信或工業 、 科學及醫療用電波輻射性電機設備之干擾 。
Battery Warning
The system uses a 3 V CR 2450 battery mounted on the mainboard to keep time. There is a risk of explosion if the
wrong battery type is used when replacing. Dispose of used batteries according to local ordinance regulations.
Li-ion batteries can be dangerous. There is a danger of explosion if the battery is incorrectly replaced. Do not expose
to fire or water.
To reduce the risk of fire or burns, do not disassemble, crush, puncture, or short external contacts. Dispose of used
batteries according to state or local hazardous waste requirements.
Safety information
Before installing and using the machine, take note of the following precautions:
• Do not place the unit on an unstable surface, cart, or stand.
• Do not block the slots and opening on the unit, which are provided for ventilation.
• Only use the power source indicated on the marking label. If you are not sure, contact your dealer or the Power
Company.
• When replacing parts, ensure that your service technician uses parts specified by the manufacturer.
• Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic.
許可 ， 公司 、 商號或使用者均不得擅自變更頻率 、 加大功率或
(NCC)

Identifying components

Customer Display
(optional)
Fingerprinter
(optional)
Earphone Jack
Trigger Button
RS 232 , USB Port
DC-IN Jack
'
s
Battery Cover Locker
CE RF Feature
WIFI b/g/n
RF Spec. NFC BT 3 . 0 +HS
HT 20 / 40
Frequency
13 . 56 MHz 2402 ~ 2480 MHz 2402 ~ 2482 MHz
Range
b: 15 . 77 dBM
g: 15 . 59 dBm
Max. Output
NA 10
Power (dBm) n HT 20 : 13 . 97 dBm
n HT 40 : 14 . 75 dBm
Keyboard
Power Button
Speakers
Camera
(optional)
Battery Cover
4 G
(LTE FDD )
Band
1 / 3 / 7 / 8
25
RFID
MSR
Barcode Scanner
(Optional)
