- Page 1 www.ghibliwirbel.com Professional Cleaning Machines Since 1968 Use and Maintenance 49 0219 00 ed. 10-2018...
- Page 2 www.ghibliwirbel.com Professional Cleaning Machines Since 1968 Scrubber Dryer Mod: ......- ..V Art.: ....W ../..Hz Nr....... IPX4 GVW ..Kg MADE IN ITALY Year: ..........
- Page 3 www.ghibliwirbel.com Professional Cleaning Machines Since 1968...
- Page 5 www.ghibliwirbel.com Professional Cleaning Machines Since 1968 English ....................ENGLISH - 1 (Translation of original instructions)
- Page 7 www.ghibliwirbel.com Professional Cleaning Machines Since 1968 Dear Customer, Thank you for choosing one of our cleaning products. The floor scrubber dryer that you have purchased has been designed to satisfy the user in terms of ease of use and reliability over time. We are aware that in order for a good product to stay that way, over time, it requires continuous updates aimed at meeting the expectations of those who use it on a daily basis.
-
Page 8: Table Of Contents
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 Indice Technical data....................EN-3 1.1 Introduction ....................EN-5 2.1 Getting to know the machine ..............EN-5 3.1 Unpacking ....................EN-5 3.1.a - Standard machine equipment ............EN-5 4.1 Assembling the components ..............EN-5 4.1.a - Wiper assembly ................EN-5 4.1.b - Brush assembly ................EN-5 5.1 Control panel ....................EN-6 6.1 Filling the tank ....................EN-6 7.1 Operation ....................EN-6... -
Page 9: Technical Data
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 Technical data Type of use Operator on ground Characteristics Power supply voltage See technical data plate Installed load 850 W Forward movement Manual Washing width * 430 mm Drying width 650 mm Brushes / Pad Diameter / Number 430mm/17”x1 Motor power / number... - Page 10 www.ghibliwirbel.com Professional Cleaning Machines Since 1968 Accessories 0.9 ø PPL brush 40.0002.00 Brush spray guard 24.0237.00 Front rubber wiper element 39.0129.00 Rear rubber wiper element 39.0130.00 Optional accessories 0.7 ø PPL strong brush 40.0102.00 1.2 ø grit 80 tynex brush 40.0202.00 Drive mechanism 40.1007.00...
-
Page 11: Introduction
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 1.1 INTRODUCTION Lift the wiper support (25) by lifting the handle (3 Fig. 1) (see relative paragraph). Position a chute and unload the machine DANGER: from the bench. Before using the machine, carefully read the attached “SAFETY WARNINGS FOR THE FLOOR SCRUBBER DRYER”... -
Page 12: Control Panel
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 5.1 CONTROL PANEL 4) Water quantity adjustment tap Turn the tap (4) counter-clockwise to (Fig. 9) increase the quantity of water or turn it clockwise to decrease it. 20) Sensor for starting brush/es rotation 6.1 FILLING THE TANK •... -
Page 13: B - Electrical Connection
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 7.1.b - Electrical connection Washing, brushing cycle: Press the switch (38) to enable brush Introduce the cable (42) of an extension rotation, press the switch (39) to enable in the tear-proff hook (28) locking it as water dispensing. -
Page 14: F - Maximum Recovery Tank Water Level Alarm
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 turn off the aspirator by pressing the Remove the cap (43) from the hose (12) switch (35 Fig. 6). and drain all the water contained in the Lift the squeegee (11 Fig. 10) by lifting tank. -
Page 15: B - Cleaning The Recovery Water Tank
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 OPERATIONS TO To completely drain the water from the tank (5) disconnect the tube (44) from the PERFORM WHEN quick connector (45) then turn the con- NECESSARY nector downwards, letting the water drain completely; or remove the filter cover 9.1.d - Cleaning the clean water filter (46). -
Page 16: F - Replacing The Squeegee Rubber Blades
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 9.1.f - Replacing the squeegee 9.1.h - Replacing the fuses rubber blades (Fig. 17) (Figg. 8-19) When it becomes clear that drying the floor is difficult or traces of water remain on the WARNING: floor, it is necessary to check the wear on the Replace the blown fuse with one with the squeegee rubber blades (47):... - Page 17 www.ghibliwirbel.com Professional Cleaning Machines Since 1968 ENGLISH - 11...
-
Page 18: Troubleshooting
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 TROUBLESHOOTING PROBLEM CAUSE SOLUTION Pressing the switch (34), the Circuit switch to position “0”. Press the power switch. machine will not turn on. Power cable disconnected. Connect the cable. The brush does not rotate. Function card damaged. -
Page 19: Warranty
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 PROBLEM CAUSE SOLUTION No water comes out. Tank empty. Fill the tank. Solenoid valve enabling Press the switch. switch not pressed. Tap turned off. Open the tap Filter blocked. Clean the filter. Solenoid valve does not Call the technical support work. -
Page 20: Wiring Diagram
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 WIRING DIAGRAM FR 30 - FR 45 TOUCH 115 VAC LIVELLO MANIGLIONE 115 VAC IN SCHEDA 115 VAC AL CONDENSATORE DI SPUNTO 98 mf. CO ...........Hour counter P1 ............Switch CN 1 .......Sensor board connector P2 ..........EV Switch CN 2 ...... -
Page 21: 30 - Fr 45 Touch 230 Vac
www.ghibliwirbel.com Professional Cleaning Machines Since 1968 FR 30 - FR 45 TOUCH 230 VAC LIVELLO MANIGLIONE CO ...........Hour counter P1 ............Switch CN 1 .......Sensor board connector P2 ..........EV Switch CN 2 ......switch board connector P3 ..........Brush switch CN 3 ....EV switch board connector P4 ......... - Page 24 Professional Cleaning Machines Since 1968 DEALER Ghibli & Wirbel S.p.A. Via Circonvallazione, 5 - 27020 Dorno PV - Italia P. +39 0382 848811 - F. +39 0382 84668 - M. info@ghibliwirbel.com www.ghibliwirbel.com 100% MADE IN ITALY A COMPANY GROUP OF RIELLO INDUSTRIES...
