LED LCD TV
OWNER' S MANUAL
MODEL: L E 3 2 K 6 0 0 0
Please READ this manual carefully
before operating your TV, and retain
it for future reference

Advertisement

loading

  Also See for Haier LE32K6000

  Related Manuals for Haier LE32K6000

  Summary of Contents for Haier LE32K6000

  • Page 1 LED LCD TV OWNER' S MANUAL MODEL: L E 3 2 K 6 0 0 0 Please READ this manual carefully before operating your TV, and retain it for future reference...
  • Page 2: Table Of Contents

    Contents 1、 Safety and warnings......................2-3 2、 Introduction........................4 3、 W all Mount Installation....................5 4、 Installation........................6-9 5、 Remote Controller......................10 6、 TV Operation........................11-14 7、 Trouble shooting......................15...
  • Page 3: 1、 Safety And Warnings

    SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTION 1) Read these instructions. CAUTION 2) Keep these instructions. RISK OF ELECTRIC SHOCK DO NOT OPEN! 3) Heed all warnings. CAUTION 4) Follow all instructions. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO 5) Do not use this apparatus near water. NOT REMOVE COVER (OR BACK).NO USER 6) Clean only with dry cloth.
  • Page 4 SAFETY AND WARNINGS High voltages are used in the operation of this television Never stand on, lean on, or suddenly push the television or receiver. Do not remove the cabinet back from your set. its stand. You should pay special attention to children. Refer servicing to qualified service personnel.
  • Page 5: 2、 Introduction

    INTRODUCTION Accessories Main features ① Used as Television, display terminal, PC display; Infrared Remote Controller.... 1 ② High luminance, wide viewing angle; Battery(AAA).......2 ③ Can store 99 TV programs; User’ s M anual.......1 ④ HDMI interface; ⑤ Multi-Media player (USB); Main parameter Model 32 inch...
  • Page 6: 3、 W All Mount Installation

    WALL MOUNT INSTALLATION Step One: Use the expansion bolts (4*36PWA) to fix the wall mount brackets into the wall. wall Step Two: Fix the wall mount screws (M4x5mm/4pcs) into the rear side of the LCD TV, using the tongue of 8kgf.cm. The TV appearance subject to material object.
  • Page 7: 4、 Installation

    INSTALLATION Front panel 1: Remote control sensor. 2: Indicator LED: STANDBY. 3: Key board ≤8m KEYBOARD The keyboard is located at the bottom left near the right side of signal indicator. Rocker Bottom 1. Middle Button: press longtime for “power” function; press once for “source”...
  • Page 8 INSTALLATION ANTENNA Note: Aerial connections: IEC(female). Input impendance: 75 unbalanced. STEPS: Be sure both the TV and computer are Power off. 1.Connect VGA and audio cable 2.Connect power cord 3.Power on the TV, switch to PC mode 4.Power on the PC This sequence is very important.
  • Page 9 INSTALLATION PRESET MODE (PC) V.Freq.(Hz) H.Freq.(KHz) RESOLUTION 800*600 37.88 1024*768 48.36 47.7 1360*768 NOTE: PC V.Freq.(Hz) not more than 60Hz. PRESET MODE (HDMI) V.Freq.(Hz) H.Freq.(KHz) RESOLUTION 800*600 37.88 1024*768 48.36 1360*768 47.7 1280*768 47.3 1920*1080 67.5...
  • Page 10 INSTALLATION AV EQUIPMENT This TV provides one group of AV, one group of YPbPr for convenient connection to VCR, DVD or other video equipment. Please refer to the owner's manual of the equipment to be connected as well. You can use the input terminals on TV set rear as follows. COAXIAL HDMI VIDEO EQUIPMENT with YPbPr...
  • Page 11: 5、 Remote Controller

    REMOTE CONTROLLER Note: The relevant button doesn't work if TV without teletext, NICAM, MHL function. -10-...
  • Page 12: 6、 Tv Operation

    TV OPERATION 1. CHANNEL MENU Rename Rename The first item of the MENU is CHANNEL MENU ( for Move the cursor to the program, press TV source only). green button to rename the program. You can search channels and edit programs here. Press to choose the character.
  • Page 13 The fourth item of the menu is the TIME MENU You can adjust the clock, power on/off time, sleep time, Auto Sleep etc. Press▼▲to move, press OK button to confirm, Haier Innovation Life and press◀▶to adjust. Clock Channel Picture Off Time...
  • Page 14 TV OPERATION Press ◀▶ to select the function icon, press OK button to Picture confirm the function. Press ▼ or EXIT button to exit the control bar. NOTE: 0021.JPG You can adjust the audio track, subtitle, or program in the Info menu while playing the video file. return Return 1080...
  • Page 15 TV OPERATION Hotel Mode: Please press source key first , and then press number key “1001” to enter into Hotel Mode or press H.LOCK key to enter into Hotel Mode. Hotel Mode Operation Hotel Mode Panel Key Lock Max V olume Start Source Start Channel Setup Menu Display...
  • Page 16: 7、 Trouble Shooting

    TROUBLE SHOOTING Trouble phenomenon Picture Audio Inspection antenna position, direction Snow Noise or connection antenna position, direction Ghost or connection Normal audio electronic equipment,car/ Interfere Noise motorcycle,fluorescent light Volume(inspect wether the mute function on the remote Normal Picture Mute control are started , or audio system are correct or not) Power cord is not inserted Power switch is not opened...
  • Page 17 4031Q325021...
