Artec Turntable Quick Start Manual

ARTEC
TURNTABLE
QUICK START GUIDE
Thank you for your purchase of Artec Turntable.
If you need assistance with your turntable, contact your local
reseller or the Artec support team: support@artec3d.com.

Product Overview

LED indicator Silicone mat
Constant-rotation mode switch
Power connector
What's in the Box
Turntable Power adapter with
interchangeable plugs
(EU, UK and US)
Specifications
Dimensions
Maximum load
Interface
Turnaround time
Power consumption
Operating temperature
How to Use Artec Turntable
Switch On
Plug in the power cable. The status indicator will start blinking.
Rotary plate
Note! If the turntable immediately starts rotating, it's
probably in the constant-rotation mode. To disable it, press
and hold the
the LED indicator blinks.
Connect
Ensure your computer has a Bluetooth adapter that
1
supports the 4.0 standard.
Locate the Devices menu in your Windows settings.
2
Add a new Bluetooth device.
3
Select Artec Turntable from the list. Wait until the turntable
4
is ready to go.
Silicone mat
Note! Bluetooth 4.0 is required.
250 mm x 250 mm x 45 mm
(10 in × 10 in × 1.7 in)
3 kg (6.6 lbs)
Bluetooth 4.0
13 s
DC 12 V; 4.66 W
0°C to +40°C
MODE button for about two seconds until
Bluetooth & other devices
Add bluetooth or other device
Mouse, keyboard & pen
Simple keyboard
USB mouse
Prepare
Artec Turntable is designed to ease scanning of small
and midsize objects by eliminating the need to rotate them
manually. Both the rotary plate and the mat that comes with
the turntable feature a special pattern to ensure robust
tracking with Artec scanners. The mat is made of silicone,
which prevents objects from sliding off the rotary plate.
The best position for objects is in the middle of the turntable.
When placing them, keep in mind that the maximum load
is 3 kg (6.6 lbs).
Use in Artec Studio
Ensure that a 3D scanner is connected to your computer.
1
Review the documentation (docs.artec-group.com)
as necessary.
Open Artec Studio.
2
Access the Scan panel.
3
Select the Use turntable checkbox.
4
Place the object on the turntable.
5
Click Preview.
6
Click Record to start capturing. The turntable will start
7
rotating.
Click Pause or Stop. The turntable will stop rotating.
9
Recovering Lost Tracking: If you experience a tracking loss,
Artec Studio will pause the turntable. It also turns the rotary
plate back by about 15 degrees. Once the application has
recovered tracking, it resumes rotation.
Warranty and Compliance
To consult the legal documents, follow this link:
docs.artec-group.com/tt/legal.html
