Summary of Contents for Black Box LG9230CTX-32
- Page 1 © Copyright 2004. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
- Page 2 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
- Page 4 FCC AND IC RFI STATEMENTS FEDERAL COMMUNICATIONS COMMISSION and INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS Class B Digital Device. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 5 PURE NETWORKING 10/100/1000-MBPS PCI ADAPTER • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult an experienced radio/TV technician for help. CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 6 CE NOTICE EUROPEAN UNION DECLARATION OF CONFORMITY This equipment complies with the requirements of the European EMC Directive 89/336/EEC.
- Page 7 PURE NETWORKING 10/100/1000-MBPS PCI ADAPTER Normas Oficiales Mexicanas (NOM) Electrical Safety Statement INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
- Page 8 NOM STATEMENT 10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros aparatos (incluyendo amplificadores) que producen calor. 11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como se indique en el aparato.
- Page 9 PURE NETWORKING 10/100/1000-MBPS PCI ADAPTER TRADEMARKS USED IN THIS MANUAL IBM is a registered trademark of International Business Machines Corporation. Linux is a registered trademark of Linus Torvalds. Microsoft, Windows, and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
-
Page 10: Table Of Contents
4.1 Indicators ......13 4.2 Calling Black Box....14... -
Page 11: Specifications
PURE NETWORKING 10/100/1000-MBPS PCI ADAPTER 1. Specifications Standards: IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, IEEE 802.3x Topology: Star Speed: 10-Mbps half-duplex/20-Mbps full-duplex; 100-Mbps half-duplex/200-Mbps full-duplex; 1000-Mbps full-duplex Hardware Required: IBM ® compatible PC with available PC slot (PCI 2.2), 32-bit, 66/33-MHz 98/98 SE/Me/XP, Drivers Included: Windows ®... - Page 12 CHAPTER 1: Specifications Temperature Tolerance: 32 to 131°F (0 to 55°C) Relative Humidity: Up to 95%, noncondensing Power: From the interface Size: 4.7"H x 1.6"W (11.9 x 4.1 cm)
-
Page 13: Overview
PURE NETWORKING 10/100/1000-MBPS PCI ADAPTER 2. Overview The Pure Networking 10/100/1000-Mbps PCI Bus Network Adapter connects an IBM compatible PC to an Ethernet network. (It fits in a PCI slot of your computer.) The adapter complies with the 32-bit PCI specification and supports half-/full-duplex operation, which can double network speed. - Page 14 CHAPTER 2: Overview The adapter supports 32-bit operation. It complies with the 66-/33-MHz PCI Local Bus Master Version 2.2 and the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and IEEE 802.3x standards. The adapter features IEEE 802.3x full-duplex flow control and IEEE 802.1Q VLAN tagging. It also offers Wake On LAN power management and Jumbo Frame, as well as plug-and-play installation, auto-setup IRQ, and I/O address.
-
Page 15: Installation
PURE NETWORKING 10/100/1000-MBPS PCI ADAPTER 3. Installation 3.1 Installing the Hardware To install the adapter in your PC, follow these steps: 1. Power off the computer and remove its cover. 2. Insert the adapter into a PCI slot. 3. Secure the adapter to the rear of the computer chassis and replace the computer cover. -
Page 16: Troubleshooting
CHAPTER 4: Troubleshooting 4. Troubleshooting 4.1 Indicators If you experience any problems with the adapter, please make sure the appropriate driver is loaded, the proper cable is connected to the adapter port, and the hub/switch complies with the adapter specification (such as 10-Mbps 10BASE-T, 100-Mbps 100BASE-TX, and 1000-Mbps 1000BASE-T), then check the LEDs. -
Page 17: Calling Black Box
4.2 Calling Black Box If you determine that your adapter is malfunctioning, do not attempt to alter or repair the unit. It contains no user-serviceable parts. Contact Black Box at 724-746- 5500. Before you do, make a record of the history of the problem. -
Page 18: Shipping And Packaging
CHAPTER 4: Troubleshooting 4.3 Shipping and Packaging If you need to transport or ship your adapter: • Package it carefully. We recommend that you use the original container. • If you are shipping the adapter for repair, make sure you include everything that came in the original package.
