MODEL # LPT75CA
120VAC-240VAC 75 AMPS/POLE
90 AMP NEUTRAL
AUTOMATIC TRANSFER SWITCH
AUTOMATICALLY SWITCHES FROM POWER CORD TO GENERATOR
HEAVY DUTY RELAY ASSEMBLY WILL HANDLE 50 AMP POWER CORD
AND UP TO 18KW GENERATOR
TRANSFERS TWO HOT POLES AND NEUTRAL SIMULTANEOUSLY
RELIABLE TIME DELAY TO ALLOW GENERATOR TO GET UP TO SPEED
BEFORE SWITCHING AUTOMATICALLY FROM SHORELINE TO
GENERATOR POWER
UTILIZES AN AUXILLARY SWITCH IN COMBINATION WITH A ME-
CHANICAL INTERLOCK TO ENSURE POWER CORD IS OFF BEFORE
GENERATOR POWER IS ENGAGED
QUICK AND EASY INSTALLATION
DESIGNED FOR OEM AND AFTERMARKET APPLICATIONS
4016 Quartz Drive
Santa Rosa, CA 95405
Phone: 707 539-9003
Fax:
707 539-5212
Email: sales@generatorjoe.NET
Web
www.generatorjoe.NET
Advertisement
Related Manuals for Esco LPT75CA
Summary of Contents for Esco LPT75CA
- Page 1 MODEL # LPT75CA 120VAC-240VAC 75 AMPS/POLE 90 AMP NEUTRAL AUTOMATIC TRANSFER SWITCH AUTOMATICALLY SWITCHES FROM POWER CORD TO GENERATOR HEAVY DUTY RELAY ASSEMBLY WILL HANDLE 50 AMP POWER CORD AND UP TO 18KW GENERATOR TRANSFERS TWO HOT POLES AND NEUTRAL SIMULTANEOUSLY...
- Page 2 ** CONSULT FACTORY BEFORE DRILLING METAL CASE. ** KEEP COVERED EXCEPT DURING WIRING AS CONTACTORS ARE SENSITIVE TO DEBRIS. ** HI-POT WITH LPT75CA DISCONNECTED OR HI-POT ON LOAD SIDE OF SWITCH. WARRANTY: The manufacturer warrants that this product shall be free from defects in material and workmanship for one year (twelve months) from date of purchase or eighteen months after date of manufacture, whichever is less.
