Summary of Contents for Aiwa Z-HK75
- Page 1 Z-HK75 COMPACT DISC STEREO CASSETTE RECEIVER • TYPE SIMPLE MANUAL • Replace this Service Manual with ”Revision Publishing” when it is issued. S/M Code No 09–995–414-5T1...
-
Page 2: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST - 1/8 NOTE: The characters in the suffix column indicate the part usage. HR .....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-112-080 CAP, ELECT 100-16V A....87-010-186-080 CAP,CHIP 4700P A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-320-080 CHIP CAP 68P A.... - Page 3 ELECTRICAL MAIN PARTS LIST - 2/8 87-010-405-040 CAP,E 10-50 A....87-012-158-080 C-CAP,S 390P-50 CH A....87-012-145-080 CAP, CHIP S 270P CH A....87-012-145-080 CAP, CHIP S 270P CH A....87-012-145-080 CAP, CHIP S 270P CH A....87-012-145-080 CAP, CHIP S 270P CH A....
- Page 4 ELECTRICAL MAIN PARTS LIST - 3/8 LED 242 87-A40-317-080 LED,SLR-342VCT31 RED A....LED 246 87-A40-317-080 LED,SLR-342VCT31 RED A....LED 241 87-A40-317-080 LED,SLR-342VCT31 RED A....LED 243 87-A40-317-080 LED,SLR-342VCT31 RED A....LED 248 87-A40-317-080 LED,SLR-342VCT31 RED A....LED 251 87-A40-317-080 LED,SLR-342VCT31 RED A....
- Page 5 ELECTRICAL MAIN PARTS LIST - 4/8 87-A21-051-040 C-IC,BU9990-03FS A....87-A50-093-010 COIL,CLOCK 5.76MHZ A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-318-080 C-CAP,S 47P-50 CH A....87-010-318-080 C-CAP,S 47P-50 CH A....87-012-145-080 CAP, CHIP S 270P CH A....87-012-145-080 CAP, CHIP S 270P CH A....
- Page 6 ELECTRICAL MAIN PARTS LIST - 5/8 87-012-145-080 CAP, CHIP S 270P CH A....87-012-154-080 C-CAP,S 150P-50 CH A....87-012-154-080 C-CAP,S 150P-50 CH A....87-A10-060-080 C-CAP,S 0.18-16 K B A....87-A10-060-080 C-CAP,S 0.18-16 K B A....87-010-177-080 C-CAP,S 820P-50 SL A....87-010-177-080 C-CAP,S 820P-50 SL A....
- Page 7 ELECTRICAL MAIN PARTS LIST - 6/8 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM A....87-A60-750-010 JACK,PIN 4P R/W BLUE A....87-003-383-010 COIL,1UH-S A....87-A30-086-070 C-TR,CSD1306E A....87-A30-086-070 C-TR,CSD1306E A....87-A30-073-080 C-TR,RT1N 141C A....87-045-382-010 RELAY,OUAZ-SH-112L A....87-067-579-010 TAPPING SCREW, BVT2+3-8 A....87-012-368-080 C-CAP,S 0.1-50 F A....
- Page 8 ELECTRICAL MAIN PARTS LIST - 7/8 87-A30-076-080 C-TR,2SC3052F A....87-099-201-010 CONN,8P 6216 H A....87-A40-317-080 LED,SLR-342VCT31 RED A....87-A40-317-080 LED,SLR-342VCT31 RED A....87-A40-317-080 LED,SLR-342VCT31 RED A....87-A40-317-080 LED,SLR-342VCT31 RED A....87-A40-317-080 LED,SLR-342VCT31 RED A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....
- Page 9 ELECTRICAL MAIN PARTS LIST - 8/8 87-020-465-080 DIODE,1SS133 (110MA) A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-107-070 C-TR,CMBT5401 A....87-A30-107-070 C-TR,CMBT5401 A....87-A30-107-070 C-TR,CMBT5401 A....87-A30-107-070 C-TR,CMBT5401 A....87-A30-190-080 TR,CC5551 A....87-A30-190-080 TR,CC5551 A....87-A30-076-080 C-TR,2SC3052F A....
-
Page 10: Mechanical Parts List
MECHANICAL PARTS LIST - 1/2 NOTE: The characters in the suffix column indicate the part usage. HR .....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 82-NE6-067-010 BADGE,AIWA 30N A....8Z-MA1-006-010 BOX,CASS L A....8Z-MA1-007-010 BOX,CASS R A....8Z-MA4-028-010 PANEL,SIDE L A.... - Page 11 MECHANICAL PARTS LIST - 2/2 88-MA2-202-010 GUIDE,FL(2) A....87-067-579-010 TAPPING SCREW, BVT2+3-8 A....87-A90-510-010 HLDR,WIRE 2.5-9P A....
-
Page 12: Accessories / Package List
ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. HR .....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-MG3-901-010 IB,H(EC-H)M A....87-043-115-010 ANT,FEEDER FM A....87-050-103-010 CORD,PIN 1PY1.5M A....87-099-789-010 PLUG,ADPTR IR44 A....87-A90-030-010 ANT,LOOP AM-NC C A.... - Page 13 9820572 Tokyo Japan Printed in Singapore...
- Page 14 SCHEMATIC DIAGRAM _ 1 (MAIN:1/3)
- Page 15 SCHEMATIC DIAGRAM _ 2 (MAIN:2/3 DECK)
- Page 16 SCHEMATIC DIAGRAM _ 3 (MAIN:3/3 K-CON)
- Page 17 SCHEMATIC DIAGRAM _ 4 (FRONT)
- Page 18 SCHEMATIC DIAGRAM _ 5 (AMP)
- Page 19 SCHEMATIC DIAGRAM _ 6 (PT)
