Aiwa Z-L90 Service Manual

Aiwa Z-L90 Service Manual

Compact disc stereo cassette receiver
Hide thumbs

Advertisement

Quick Links

Download this manual
Z-L90
COMPACT DISC STEREO
CASSETTE RECEIVER
•
:
TYPE
K
SIMPLE MANUAL
• Replace this Service Manual with "Revision Publishing" when it is issued.
.
S/M Code No
09–993–412–2T1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z-L90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa Z-L90

Summary of Contents for Aiwa Z-L90

  • Page 1 Z-L90 COMPACT DISC STEREO CASSETTE RECEIVER • TYPE SIMPLE MANUAL • Replace this Service Manual with "Revision Publishing" when it is issued. S/M Code No 09–993–412–2T1...
  • Page 2 ELECTRICAL PARTS LIST-1/9 NOTE: The characters in the suffix column indicate the part usage. KSTM ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-112-080 CAP, ELECT 100-16V A....87-010-186-080 CAP,CHIP 4700P A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-320-080 CHIP CAP 68P A....87-010-405-040 CAP,E 10-50 A....
  • Page 3 ELECTRICAL PARTS LIST-2/9 87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-322-080 C-CAP,S 100P-50 CH A....87-012-156-080 C-CAP,S 220P-50 CH A....87-012-156-080 C-CAP,S 220P-50 CH A....87-012-156-080 C-CAP,S 220P-50 CH A....87-010-182-080 C-CAP,S 2200P-50 B A....87-010-182-080 C-CAP,S 2200P-50 B A....87-010-197-080 CAP, CHIP 0.01 DM A....
  • Page 4 ELECTRICAL PARTS LIST-3/9 LED 209 87-A40-496-040 LED,SLR-342MCT31 GRN A....LED 213 87-A40-496-040 LED,SLR-342MCT31 GRN A....LED 214 87-A40-496-040 LED,SLR-342MCT31 GRN A....LED 211 87-A40-496-040 LED,SLR-342MCT31 GRN A....LED 210 87-A40-496-040 LED,SLR-342MCT31 GRN A....LED 212 87-A40-496-040 LED,SLR-342MCT31 GRN A....LED 215 87-A40-496-040 LED,SLR-342MCT31 GRN A....
  • Page 5 ELECTRICAL PARTS LIST-4/9 87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....
  • Page 6 ELECTRICAL PARTS LIST-5/9 87-007-342-010 COIL,OSC 85K BIAS A....87-026-610-080 TR,KTC3198GR A....87-026-610-080 TR,KTC3198GR A....87-026-610-080 TR,KTC3198GR A....87-A30-076-080 C-TR,2SC3052F A....87-A30-087-080 C-FET,2SK2158 A....87-A30-087-080 C-FET,2SK2158 A....87-A30-087-080 C-FET,2SK2158 A....87-A30-105-080 C-TR,RT1P 441C A....87-A30-087-080 C-FET,2SK2158 A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....

  • Page 7: Electrical Parts List-6

    ELECTRICAL PARTS LIST-6/9 87-010-263-080 CAP, ELECT 100-10V A....87-010-263-080 CAP, ELECT 100-10V A....87-010-992-080 C-CAP,S 0.047-25 B A....87-010-992-080 C-CAP,S 0.047-25 B A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-314-080 C-CAP,S 22P-50V A....87-010-322-080 C-CAP,S 100P-50 CH A....87-010-322-080 C-CAP,S 100P-50 CH A....
  • Page 8 ELECTRICAL PARTS LIST-7/9 87-010-496-080 CAP,E 3.3-50 5L A....87-010-263-080 CAP, ELECT 100-10V A....87-010-380-080 CAP, ELECT 47-16V A....87-010-401-080 CAP, ELECT 1-50V A....87-A60-739-010 CONN,13P JL-BT A....87-A60-109-010 CONN,2P V S2M-2W A....8Z-MA4-623-010 CONN ASSY,9P 480 VH A....87-020-465-080 DIODE,1SS133 (110MA) A....
  • Page 9 ELECTRICAL PARTS LIST-8/9 87-A10-303-080 CAP,M 0.047-50 J A....87-010-546-080 CAP, ELECT 0.33-50V A....87-010-546-080 CAP, ELECT 0.33-50V A....87-A21-031-040 C-IC,BU4551BF A....87-070-136-080 ZENER,MTZJ5.1B A....87-A30-104-080 C-TR,RT1N 441C A....87-010-544-080 CAP, ELECT 0.1-50V A....87-010-544-080 CAP, ELECT 0.1-50V A....87-010-322-080 C-CAP,S 100P-50 CH A....
  • Page 10 ELECTRICAL PARTS LIST-9/9 87-A30-106-070 C-TR,CMBT5551 A....87-A30-268-040 C-TR,2SA1514K(S) A....87-A30-075-080 C-TR,2SA1235F A....87-A30-075-080 C-TR,2SA1235F A....87-A30-075-080 C-TR,2SA1235F A....87-A30-075-080 C-TR,2SA1235F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-119-040 C-TR,2SC3906K R A....87-A30-119-040 C-TR,2SC3906K R A....

  • Page 11: Electrical Parts List-1

    ELECTRICAL PARTS LIST-1/3 <ZZA-1> NOTE: The characters in the suffix column indicate the part usage. ZRDS ....XX........F....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-381-080 0E CAP, ELECT 330-16V ABCDEFGH.... 87-010-404-080 0E CAP, ELECT 4.7-50V ABCDEFGH.... 87-010-260-080 0E CAP, ELECT 47-25V ABCD.FGH....
  • Page 12 ELECTRICAL PARTS LIST-2/3 <ZZA-1> 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGH.... 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGH.... 87-010-494-080 0E CAP ELECT GAS 1/50 ..E....87-010-494-080 0E CAP ELECT GAS 1/50 ..E....87-012-275-080 0E C-CAP,U 1200P-50 B ABCDEFGH.... 87-012-275-080 0E C-CAP,U 1200P-50 B ABCDEFGH....
  • Page 13 ELECTRICAL PARTS LIST-3/3 <ZZA-1> 87-A50-159-010 0E COIL,10MH K C2B ..E....87-A50-173-010 0E COIL,OSC SW-N(COI) ..E....87-A50-432-010 0E COIL,1MH K CW ..E....87-A50-430-010 0E COIL,ANT MW(3BSW) ..E....87-A50-431-010 0E COIL,OSC MW(3BSW) ..E....87-NF4-650-010 1D COIL,AM PACK 4N(TOK) A....87-NF4-651-010 1C COIL,AM PACK2N(TOM) ....
  • Page 14 MECHANICAL PARTS LIST-1/2 NOTE: The characters in the suffix column indicate the part usage. KSTM ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 82-NE6-067-010 BADGE,AIWA 30N A....8Z-MA1-001-010 CABI,FR LH ....8Z-MA1-002-010 CABI,FR HE ....8Z-MA1-006-010 BOX,CASS L A....8Z-MA1-007-010 BOX,CASS R A....
  • Page 15 MECHANICAL PARTS LIST-2/2 88-906-281-110 FF-CABLE, 6P 1.25 280MM A....88-914-251-110 FF-CABLE,14P 1.25 250 A....87-010-101-080 CAP, ELECT 220-16 A....8Z-MA1-606-010 PT,ZMA-1 LH ....8Z-MA1-608-010 PT,ZMA-1 K A....8Z-MA1-609-010 PT,ZMA-1 HE ....89-213-702-010 TR,2SB1370 (1.8W) A....89-213-702-010 TR,2SB1370 (1.8W) A....87-A30-097-010 TR,FN 1016 A....
  • Page 16 ACCESSORIES / PACKAGE LIST-1/1 NOTE: The characters in the suffix column indicate the part usage. KSTM ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-MA1-901-010 IB,H(ECA)M ....8Z-MA1-902-010 IB,LH(ESP)M ....8Z-MA1-905-010 IB,K(E)M A....87-043-115-010 ANT,FEEDER FM ....87-099-789-010 PLUG,ADPTR IR44 ....87-A90-030-010 ANT,LOOP AM-NC C A....
  • Page 17 SCHEMATIC DIAGRAM _ 1 (MAIN)
  • Page 18 SCHEMATIC DIAGRAM _ 2 (DECK)
  • Page 19 SCHEMATIC DIAGRAM _ 3 (TUNER)
  • Page 20 SCHEMATIC DIAGRAM _ 4 (PRO)
  • Page 21 SCHEMATIC DIAGRAM _ 5 (FRONT)
  • Page 22 SCHEMATIC DIAGRAM _ 6 (CD KEY)
  • Page 23 SCHEMATIC DIAGRAM _ 7 (PT)
  • Page 24 9 3 0 1 9 7 8 Tokyo Japan Printed in Singapore...
