OPERATING INSTRUCTIONS AND REPLACEMENT PARTS
Models: SVF-10E and SVF-10AC50
WArninG
this manual must be read carefully and followed by all persons who have or will have the responsibility
for using or servicing this equipment. this equipment will perform as designed only if used according
to the instructions. otherwise it could fail to perform as designed, causing personal injury or death.
Air SyStEMS intErnAtionAl, inC.
829 Juniper Crescent, Chesapeake, Va, 23320
Telephone (757) 424-3967
Toll Free 1-800-866-8100
Fax No. (757) 424-5348
www.airsystems.com.
e-mail: sales@airsystems.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AIR SYSTEMS SVF-10E
Summary of Contents for AIR SYSTEMS SVF-10E
- Page 1 OPERATING INSTRUCTIONS AND REPLACEMENT PARTS Models: SVF-10E and SVF-10AC50 WArninG this manual must be read carefully and followed by all persons who have or will have the responsibility for using or servicing this equipment. this equipment will perform as designed only if used according to the instructions.
- Page 2 Attach all grounding wires and assure a complete circuit to the blower or fan in order to remove static charges. The Saddle Vent® is a registered trademark of Air Systems International, Inc. The Conductive Saddle Vent® is covered by U.S. and Foreign Patents...
-
Page 3: Safety Precautions
Model SVB-A8. Note: For confi ned space ventilation in non-hazardous locations, use Air Systems’ confi ned space ventilation kit, Model SV-CUP. For hazardous locations use ventilation kit, Model SV-CUPCND along with one of the above explosion proof blowers or fans. -
Page 4: Setup And Operation
StEP 3) Connect power cord to a 115 VAC/60 Hz receptacle for model SVF-10E or to a 220 VAC/50 Hz receptacle for model SVF- 10AC50. notE: if an extension cord is to be used, the minimum recommended size is 14 AWG up to 25 ft. For longer cords, refer to the national Electric Cord tables, Article 400. -
Page 5: System Components
System Components itEM # DESCriPtion SVF-10E SVF-10AC50 8” TO 10” DUCT TRANSITION SVF-108ADP SVF-108ADP FAN GUARD MGDAXFAN1 MGDAXFAN1 M8 X 1.25 RETAINING NUT FOR FAN FNM8X1.25E FNM8X1.25E SVF-FAN SVF-FAN INLET/OUTLET GASKET ILF-G ILF-G HANDLE SVF-10HNDL SVF-10HNDL ELECTRIC MOTOR AND CAPACITOR... - Page 6 notes:...
-
Page 7: Warranty
Air Systems’ manufactured equipment is warranted to the original user against defects in workmanship or materials under normal use for one year from the date of purchase. Any part which is determined by Air Systems to be defective in mate- rial or workmanship will be, as the exclusive remedy, repaired or replaced at Air Systems’... - Page 8 Rev. 6 July 2019 Air SyStEMS intErnAtionAl, inC. 829 Juniper Crescent, Chesapeake, Va, 23320 Telephone (757) 424-3967 Toll Free 1-800-866-8100 Fax No. (757) 424-5348 http://www.airsystems.com e-mail: sales@airsystems.com Printed in the U.S.A. Copyright© Air Systems International, Inc. 2019 All Rights Reserved...
