Carlson NR3 Quick Start Manual

Hide thumbs Also See for NR3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
NR3
Quick Start
Guide
Ver 1.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NR3 and is the answer not in the manual?

Questions and answers

Related Manuals for Carlson NR3

Summary of Contents for Carlson NR3

  • Page 1 Quick Start Guide Ver 1.02...

  • Page 2: Shipping Case Contents

    1 Shipping Case Contents The Carlson NR3 system is shipped with the following items: Figure 1: Shipping Case Contents Shipping Contents Item Main Kits Part Number Quantity Carlson Software NR3 Receiver 410222B1775 USB Cable 214100 Internal Batteries 215344 Battery Charger...

  • Page 3: Sd / Sim Card Slots

    2 SD / SIM Card Slots Figure 2: SIM Card Cover Location The Micro SD SIM card is located behind the left battery door. To access, compress the battery door latch an open. Lift the SIM card cover up to remove. Slide the SIM (micro) with the contact facing away from the battery and toward the GNSS antenna of the unit into the slot (shown below).

  • Page 4: Install Battery

    3 Install Battery The NR3 allows two batteries to be installed. When installing the batteries, ensure the correct orientation with the positive end towards the front of the device. Access the battery bay by compressing the battery latch towards the inside of the device and pull up. This will swing the battery latch open.

  • Page 5: Powering On/Off

    5 On-Board Web UI To view the NR3 Web UI, a connection needs to be made the NR3’s Wi-Fi network. In a phone, tablet, PC, or any other Wi-Fi capable device, search for the NR3 Wi-Fi network and connect. The name of the NR3 Wi-Fi network will be the serial number of the device: Shown below using Windows 10.
  • Page 6 Username and Password (if applicable) is entered. When complete, click the ‘Ok’ button to save to current settings. Figure 8: Cell Configuration Once a valid connection is made, the line between the NR3 and the internet will light up green.
  • Page 7 7.3 GNSS Position Mode The next step is to set the NR3 as a rover. Click on the GNSS tab and select ‘Position Mode’. Configure the NR3 as a rover by selecting ‘Rover’. Click ‘Ok’ to save the current settings.

  • Page 8: Nr3 Front Panel

    8 NR3 Front Panel Figure 11: Carlson NR3 Front Panel ICON Description Blinking: Battery not in use Battery Power (Left / Right) On and solid: Battery in use Off: Bluetooth not in use Bluetooth Blinking: Bluetooth is discoverable On and solid: Bluetooth link is active...

  • Page 9: Power Button Functions

    9 Power Button Functions The NR3 Power Button has several functions. • Power the device On / Off • Enable / Disable Data Logging • Enable / Disable Wi-Fi Status • Reset to Factory Default Each of these functions can be selected using the following table:...
