- Page 1 www.roswellmarine. co m Area 53 Bimini Installation & Usage Instructions Part # C910-1740 & C910-1741 Information: info@roswellglobal.com Warranty: warranty@roswellglobal.com If you have any questions please call : 1-321-638-1331 REV 11-Apr-17...
- Page 2 Area 53 Bimini Installation Instructions ww w.roswellmarine.com Prepare your workspace: Clear an area near the boat. Make sure there is an unobstructed path from the boat to the setup area. We suggest assembling the bimini on a dropcloth to prevent damaging or scratching the nish of the parts. Make sure there are no overhead obstructions (rafters, garage door, hanging light xtures, etc.) Unpack the bimini: Be careful to avoid marking or scratching when removing the bimini from its...
- Page 3 Area 53 Bimini Installation Instructions ww w.roswellmarine.com After unwrapping all of the bimini components from the packaging, lay out the 2 front bows and a center tube them on a drop cloth. Arrange the front bows such that the middle bow hinge is facing upward on both sides. Align the 2 front bows with the center bow using the appropriate set of holes on the front bows.
- Page 4 Area 53 Bimini Installation Instructions ww w.roswellmarine.com 1. Slide the middle bow through the center pocket on the canvas. 2. Insert the middle bow pivot balls into the taco ttings. 3. Secure the middle bow in place using the retaining pin. Assemble the 2 stainless arms to the frame and fabric assembly as shown.
- Page 5 Area 53 Bimini Installation Instructions ww w.roswellmarine.com Two people are required for this step With one person on each side of the frame and canvas, slide the stainless arms into the anchor tubes on each side. This is where you may have to adjust the angle of the anchor tubes that were left loose in the previous step. Make sure the stainless arms are bottomed out in the Anchor tubes.
- Page 6 Area 53 Bimini Installation Instructions ww w.roswellmarine.com Tips to ensure that your bimini quick release pins function properly. This process is not necessary for all biminis. It is possible that once your bimini is installed your frame Occasionally this problem can be solved by merely and stainless arms are not parallel where they pivot.
- Page 7 Area 53 Bimini Usage Instructions ww w.roswellmarine.com Use these instructions to properly use, operate and care for your Area 53 Bimini. Bimini Stowage Undo all 12 velcro straps securing the fabric to the tower Remove the quick release pins and allow the frame to and frame.
- Page 8 Area 53 Bimini Usage Instructions ww w.roswellmarine.com Towing & Trailering Illustrated is the ONLY acceptable way to safely fold your Area 53 tower or trailer your boat with the Soft Top Bimini on IMPORTANT: Quick release pins must be inserted into the frame tting or the stainless tting for trailering to avoid damage to parts.
