BOOTY BUILDER 5.0 Assembly Instruction Manual page 4

Advertisement

Step 2
1. Screw upholstery to the support.
2. Connect gas spring and pad plate to the support as shown by figure (hardwares are on
the support).
#20.9: Washer M8
#20.4: IMB M8*15
ASSEMBLY INSTRUCTION
Page 4
