Page 2
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation.
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury.
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord.
These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials.
Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual...
Monitor introduction 1.3.1. Front.view Main Menu Exit Power Off Main Menu Exit Input Select Power Off Input Select Blue Light Filter Blue Light Filter Power button/5-way button (on the back of the monitor) • Turns the monitor on. Power indicator •...
HDMI.ports. This ports are for connection with an HDMI compatible device. VGA.port. This 15-pin port is for PC VGA connection. Audio-in.port. This port connects PC audio source by the bundled audio cable. Kensington.lock.slot. Rating label is stuck on the bottom of the LCD monitor. ASUS VL278 Series LCD Monitor...
• Hold the stand to prevent the monitor from falling when you change its angle. • The recommended adjusting angle is +21.5 to -8.5˚. -8.5° ~ +21.5° ASUS VL278 Series LCD Monitor...
Detaching the arm (for wall mount) The detachable arm/base of this monitor is specially designed for wall mount. To detach the arm/base: Have the front of the monitor face down on a table. Remove the back cover from the monitor. (Figure 1) Use a screwdriver to remove the screws on the hinge (Figure 2), then remove the stand.
Input Select item in the OSD menu. Turning on the monitor Press the power button . See page 1-2 for the location of the power button. The power indicator lights up in white to show that the monitor is ON. ASUS VL278 Series LCD Monitor...
Da r k r o o m M o d e M O V E /E N T E R B A C K /E X I T •. Scenery.Mode:.Best choice for scenery photo display with SplendidPlus Video Enhancement. ASUS VL278 Series LCD Monitor...
Page 18
In the Reading mode, the following function(s) are not user-configurable: Contrast, Saturation, Color Temp., Skin Tone, Sharpness, ASCR. Blue.Light.Filter In this function, you can adjust the blue light filter level. ASUS VL278 Blue Light Filter Standard Mode HDMI 1920 x 1080 @ 60Hz L e v e l 0...
Page 19
Saturation: The adjusting range is from 0 to 100. •. Color.Temp.: Contains 4 modes including Cool, Normal, Warm and User Mode. •. Skin.Tone: Contains three color modes including Reddish, Natural, and Yellowish. •. Smart.View: Provides better display quality under big viewing angle. ASUS VL278 Series LCD Monitor...
Page 20
VividPixel: Enhances the outline of the displayed picture and generates high-quality images on screen. •. ASCR: Turns on/off the ASCR (ASUS Smart Contrast Ratio) function. •. Position.(Only.available.for.VGA.input): adjusts the horizontal position (H-Position) and the vertical position (V-Position) of the image. The adjusting range is from 0 to 100.
Page 21
M o r e M O V E /E N T E R B A C K /E X I T •. Splendid.Demo.Mode: Splits the screen into two for Splendid modes comparison. (Scenery mode only) ASUS VL278 Series LCD Monitor...
Page 22
•. GamePlus: The GamePlus function provides a toolkit and creates a better gaming environment for users when playing different types of games. The crosshair overlay with different crosshair options lets you choose the one that best suits the game you’re playing. There’s also an onscreen timer you can position on the left of the display so you can keep track of the elapsed gaming time.
Page 23
Amsler Grid: While focusing at the center point, check that all the lines are straight. Photo size: Provides photographers and other users to accurately view and edit their photos in real size on the screen. ASUS VL278 Series LCD Monitor...
Page 24
•. ECO.Mode: Reduces power consumption. •. OSD.Setup: • Adjusts the OSD timeout from 10 to 120 seconds. • Enables or disables the DDC/CI function. • Adjusts the OSD background from opaque to transparent. •. Language: There are 21 languages for your selection, including English, French, German, Italian, Spanish, Dutch, Portuguese, Russian, Czech, Croatian, Polish, Romanian, Hungarian, Turkish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesian, Persian.
Dimension (W x H x D) with 614 mm x 438 mm x 208 mm (machine), stand 684 mm x 508 mm x 167 mm (package) Weight (Esti.) 5.4 kg (Net); 4.6 kg (without stand); 7.3 kg (Gross) ASUS VL278 Series LCD Monitor...
Troubleshooting (FAQ) Problem Possible.Solution Power LED is not ON • Press the button to check if the monitor is in the ON mode. • Check if the power cord is properly connected to the monitor and the power outlet. • Check if the power switch is ON. The power LED lights amber and there is •...
