- Page 1 KSN55-C SERIES USER MANUAL KSN55-C SERIES USER MANUAL Ver.1.2 Dual Channel AIS Receiver Model: KSN55-C WWW.KSNTEK.COM...
-
Page 2: Safety Warning
KSN55-C SERIES USER MANUAL SAFETY WARNING： IT IS IMPORTANT TO KNOW AS AN ELECTRONIC AUXILIARY EQUIPMENT FOR DATA TRANSMISSION OF SHIP AIS PILOT PLUG, THE PILOT OF SHIP SHOULD ALWAYS BE ALERT TO THE TRAFFIC IN THE SURROUNDING SEA AREAS AND ENSURE THE SAFETY OF NAVIGATION WHILE USING THIS EQUIPMENT. -
Page 3: Specifications
KSN55-C SERIES USER MANUAL ： SPECIFICATIONS Independent AIS Receiver Receiving Channels Dual channels CH-1 87B,CH-2 88B Frequency Range 161.975MHz～162.025MHz Channel Baud Rate 9600bps Channel Bandwidth 25KHz -117dBm @PER≤20% Receive Sensitivity GNSS Navigation Channel 50 Chanel Message GNSS at NMEA 0183... - Page 4 KSN55-C SERIES USER MANUAL ： DIAGRAM Figure 1. WWW.KSNTEK.COM...
-
Page 5: How To Start
KSN55-C SERIES USER MANUAL ： HOW TO START Figure 2. Figure 3. 1. Always place unit horizontal that ROT requested; 2. If using own AIS receiver that “AIS ANT” should lift up then pull out the “AIS ANTENNA BAR” to obtain good AIS signals;... -
Page 6: Basic Operation
Install USB driver for PC or Mac then find COM port No. on device manager Note: For some of App on iOS already fixed connection settings, like in SEAiq just find the “KSNTEK KSN11-C ROT…..” in Standard WiFi Devices then Enable on it. ：... - Page 7 KSN55-C SERIES USER MANUAL ROT CALIBRATIONS： The calibration of ROT on equipment is very important before use it. the value of ROT will be inaccurate if it not calibrated correctly. ROT status should be observed after each boot. unit has the functions of automatic and manual calibration. please follow below steps:...
-
Page 8: Automatic Calibration
Short press once the Power and M button at the same time for manual calibration or open the IE browser or Safari, enter the address “192.168.2.1/ksntek.html” in the address bar (please type all the letters including the end “html” and lowercase letters, pay attention to the direction of the slash) and enter, the page will open as the following and click the CALIBRATE button to manually calibrate the device, if the calibration is completed. - Page 9 KSN55-C SERIES USER MANUAL HDT: heading from KSN55-C,it can be Enabled or Disabled in this page; CAL: the heading in KSN55C need to input value for initial,input a value then tap on SEND,unit must be no movements after the value set.
- Page 10 Bluetooth pair key not requested anymore in this version. Wi-Fi SETINGS： On the latest products from KSNTEK that allow end users to customize on Wi-Fi settings like SSID NAME and Network Password...etc, this will avoid some unexpected connections due to the WiFi allows max 3 clients only.
- Page 11 KSN55-C SERIES USER MANUAL Open Safari or IE Explorer type 192.168.2.1 in address bar then Enter User Name: admin Password: pilot If there something wrong on settings that WiFi can be reloaded by factory default in MENU— CONN—WiFi—Reload. WWW.KSNTEK.COM...
