3 Using Avtek TT-BOARD Pro

Note:
Before the first use of the interactive whiteboard you have to install the software driver
provided on the Software CD included with it.
In order to check if the whiteboard has been connected successfully, please check the
driver icon:
1. means that the whiteboard failed to be recognised correctly.
2. means the PC was able to connect with the whiteboard successfully.

3.1 Calibration

After you have installed the driver, a new icon will appear on the desktop:
run the driver, double click the icon and the software will connect to the whiteboard.
Once the icon appears on the system tray (in the right bottom corner of the screen),
right-click it to open the context menu
bring up the Calibration
Use a pen included with the whiteboard and touch the centre of each crosshair
hold it for a few seconds). As soon as the four registration points have been identified, the
calibration process will be completed.
screen:
19
USER MANUAL
. Next, click "Calibration". This will
. To
(and
