Installation I nstructions f or G reenway T rellis ( item # 8705)
©4/9/14 F eeney I nc.
Parts L ist:
(A) 1 q ty, t op t ube ( 1-­‐1/2"OD x 4 3" l ong x 8 " h igh)
(B) 1 q ty, l eft s ide t ube ( 1-­‐1/2"OD x 7 6" l ong)
(C) 1 q ty, r ight s ide t ube ( 1-­‐1/2"OD x 7 6" l ong)
(D) 1 q ty, b ottom t ube ( 1-­‐1/2"OD x 4 0" l ong)
(E) 2 q ty, s plice s leeves ( 1-­‐1/4"OD x 4 ")
(F) 2 q ty, s plice s leeves ( 1-­‐1/4"OD x 1 ")
(G) 1 0 q ty, s crew ( #8 x 3 /4") ( you'll n eed 6 , s o t here a re 4 e xtra t o u se o r l ose)
(H) 4 q ty, s crew ( #10 x 1 -­‐1/2")
(I) 4 q ty, c ables w ith t hreaded t erminal f itting o n o ne e nd & b utton h ead f itting o n o ther ( 1/8" d iam. x 6 0" l ong)
(J) 4 q ty, n ylon f lat w ashers ( 1/4"ID x 7 /16" O D)
(K) 4 q ty, n ylon f lat w ashers ( 1/4"ID x 3 /4" O D)
(L) 4 q ty, S nug-­‐Grip® w asher n uts ( 1/4-­‐20RH)
(N) 4 q ty, b lack p lastic c aps ( 3/4" O D)
(O) 4 q ty, r ods ( 1/8" d iameter x 3 8" l ong)
(P) 1 6 q ty, c ross-­‐clamps w ith s et s crews
Tools N eeded:
Safety g lasses
Pencil
Measuring t ape
Hammer
Electric d rill
9/64" d rill b it
#2 s quare d rive b it ( included i n k it)
7/16 s ocket w rench o r o ther
Vise-­‐Grip® t ype p liers
Hacksaw o r e lectric g rinder w ith c ut-­‐off d isk
Sharpie f elt p en
3/16" h ex k ey w rench ( included i n k it)
Shovel o r p osthole d igger
Level
Concrete o r c ompacting g ravel ( 3/8" t o d ust)
Please r efer t o t he I nstallation D etails d iagrams d uring i nstallation.
Building T he F rame:
1. Find a s mooth, f lat a rea t o l ayout a ll o f t he c omponents a nd b uild y our f rame. B e s ure t o p rotect t he t ubes f rom s cratches d uring f rame
construction b y l aying d own b lankets, r ags, o r p acking w rappers.
2. Insert a s plice s leeve ( E ) 2 i nches i nto t he t op e nd o f b oth t he l eft s ide t ube ( B) a nd t he r ight s ide t ube ( C). I f t he s plice s leeve i s t oo t ight
to i nsert b y h and, g ently t ap w ith a h ammer. T he t op e nd o f t he s ide t ubes c an b e i dentified b y t he s mall p ilot h ole o n t he s ide. B e s ure
that t he s lot i n t he s plice s leeve i s n ot p ositioned o ver t he p ilot h ole.
3. Lock t he s plice s leeves ( E) i n p osition b y d riving a # 8 s crew ( G) t hrough t he p ilot h ole i n t he s ide t ubes ( B) & ( C) a nd i nto t he s plice s leeve.
Use a n e lectric d rill a nd # 2 s quare d rive b it t o a ttach t he s crews. I f y ou h ave d ifficulty d riving t he s crews, u se a 9 /64" b it t o d rill a p ilot
hole t hrough t he s leeve.
4. Attach a s plice s leeve ( F) t o t he s ide o f e ach s ide t ube ( B) & ( C) u sing t wo # 10 s crews ( H). T he s crews w ill r un t hrough t he c hase h oles i n
the s plice s leeves a nd i nto t he p ilot h oles i n t he s ide t ubes. U se a n e lectric d rill a nd # 2 s quare d rive b it t o a ttach t he s crews.
5. On y our f lat s urface, l ay t he s ide t ubes ( B) & ( C) p arallel t o o ne a nother a nd a bout 4 f eet a part w ith t he s plice s leeves ( F) f acing o ne
another a nd t he p ilot h oles f acing u pward.
6. Carefully s lide t he e nds o f t he b ottom t ube ( D) o ver e ach s plice s leeve ( F). B e s ure t hat t he s mall p ilot h oles i n t he b ottom t ube a re n ot
lined-­‐up o ver t he s lot i n t he s plice s leeves.
7. Secure t he b ottom t ube ( D) i n p osition w ith a # 8 s crew ( G) i nserted t hrough t he p ilot h ole a nd i nto e ach o f t he s plice s leeves ( F). I f y ou
have d ifficulty d riving t he s crews, u se a 9 /64" b it t o d rill a p ilot h ole t hrough t he s leeves.
