Mini Launcher
Clamp base to side edge of table. Mount
launcher as shown to shoot off table onto
floor at a positive or negative angle.

Launch Positions

Clamp base to table. Mount launcher as
shown to shoot onto table. Ball is launched
from a height above table level.
6
Clamp base to table. Mount launcher as
shown to shoot onto table. The square nut
that the Launcher pivots around should be
slid to the front of the launcher. Ball is
launched at table level. When you change
the angle of the launcher, the launch
position does not change.
Clamp base to a vertical rod.
Place base on a tabletop or floor
and hold it with your hand.
012-09562A
®
