ELECTRIC
QUIET
SHREDDER
SDS2810
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your shredder, ensuring it is assembled
correctly and safely. If you need help or have damaged or
missing parts, call the Customer Helpline on 0345 605 2068
ORIGINAL
INSTRUCTION
MANUAL
AFTER SALES SUPPORT
0345 605 2068
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spear & Jackson SDS2810
Summary of Contents for Spear & Jackson SDS2810
- Page 1 ORIGINAL INSTRUCTION MANUAL ELECTRIC QUIET SHREDDER SDS2810 Important - Please read these instructions fully before starting assembly AFTER SALES SUPPORT 0345 605 2068 These instructions contain important information that will help you get the best from your shredder, ensuring it is assembled correctly and safely.
- Page 2 SPEAR & JACKSON SINCE 1760 For more than 250 years gardeners have enjoyed high quality performance and great results using Spear & Jackson tools. Our garden power tools combine continuous innovation and the latest in manufacturing technologies with a proud heritage. Each product is carefully designed with performance,comfort and durability firmly in mind,which has earned Spear &...
-
Page 3: Table Of Contents
CONTENTS Safety Information ........................4 Intended Purpose ..........................4 Description Of Symbols ........................4 General Safety Safety ........................5 Electrical Safety ..........................6 Personal Safety ..........................6 Operational Safety ..........................7 Maintenance and Storage Safety ...................... 8 Operating Safety ..........................9 In the Box ............................ -
Page 4: Safety Information
SAFETY INFORMATION INTENDED PURPOSE The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembly and operating the Shredder. DESCRIPTION OF SYMBOL Warning! Beware of Warning! Danger from hazards. Take special thrown objects. -
Page 5: General Safety Safety
SAFETY INFORMATION GENERAL SAFETY and solid foreign bodies with Ø > 12 mm as well IMPORTANT! Read as protection against carefully before use splashed water from all and keep for future directions. reference. Machine operated • The device must not be intermittently each cycle used by people (including comprising a period... -
Page 6: Electrical Safety
SAFETY INFORMATION ELECTRICAL SAFETY resistant to splash water. The core diameter for CAUTION! The following extension cables measuring states how to avoid up to 25 m must be at accidents and injuries least 1.5 mm², and 2.5 due to electric shock: mm²... -
Page 7: Operational Safety
SAFETY INFORMATION • Only use the shredder in • When servicing the cutting the open (that is, away means be aware that, from walls or other rigid even though the power structures) on a firm, level source will not start due surface. -
Page 8: Maintenance And Storage Safety
SAFETY INFORMATION • Make sure that the material making unfamiliar noises inserted into the shredder or vibrations (check the does not contain hard shredder for damage before objects made of metal, starting it up again) stone, glass or similar. • Do not allow shredded •... -
Page 9: Operating Safety
SAFETY INFORMATION • Store the appliance in a dry location and out of reach of children. • Handle the appliance with care. Keep the appliance clean for save and more efficient working. Follow the maintenance directions. OPERATING SAFETY • The silent shredder is equipped with a powerful motor and motor brake, overload protection with... -
Page 10: In The Box
IN THE BOX PARTS Wheels Mains cable Operating mode Feet Spanner selection switch Collection box Transport handle Screw*4 (for Allen key Pusher body fix on the Reset switch Collection box CHASSIS) safety switch Cutting blade Hopper funnel adjustor knob Screw*2 (for feed inlet Shredder unit wheels) -
Page 11: Assemble
ASSEMBLE Unpacking i. Unpack all parts and lay them on a flat, stable surface. ii. Remove all packing materials and shipping devices if applicable. iii. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact the aftersales helpline within 28 days of purchase. -
Page 12: Prepare
ASSEMBLE Insert the collection box i. insert the collection box when the safety switch in “unlock” position. ii. Lock the collection box by rotating the safety switch to “lock” Position. Note: The box must be locked firmly, otherwise the shredder can not power on. -
Page 13: Operate
OPERATE Switch on/off i. To switch on, push the safety lock forward and turn the switch to the right. ii. To switch off, turn the switch to the “OFF”position.. Freeing jams Depending on the degree different measurement must be taken to free a jam. Light jams can be freed by using the reversed mode while bigger jams require opening the roller housing. -
Page 14: Maintenance
MAINTENANCE Cleaning Make sure the product is switched off, cooled down and disconnected from power supply. i. Clean the product with a dry cloth. Use a brush for areas that are hard to reach. ii. In particular clean after every use with a cloth and brush. iii. - Page 15 MAINTENANCE The max. branch thickness that can be shredded is dependent on the type of wood and the quality of the goods being cut. For hard wood (e.g. oak/beech branches), the max. branch thickness that can be shredded is less than for soft wood (e.g. pine/spruce wood).
-
Page 16: Technical Data
Max 42 mm Collection box content Approx 60 L Weight 22 kg Sound power level Measured (LWA) 96.3 dB(A); KwA = 2.4 dB(A) Guaranteed 99 dB(A) Part numbe: 7501935(SDS2810) ACCESSORIES 181005116. Blade 181005134 Pressure Plate AFTER SALES HELPLINE 03456 052 068... - Page 17 TECHNICAL DATA Recycling and Disposal The product comes in a package that protects it against damage during shipping. Keep the packaging untill you are sure that all parts have been delivered and the product is functioning properly. Recycle the packaging afrerwards. Old products are potentlally recyclable and do not, therefore, belong in your household rubbish.
-
Page 18: Troubleshooting
TROUBLESHOOTING Fault Possible Cause Solution Motor will not start Collection box not fitted Push the collection box firmly correctly to its correct position, and place the safety switch on the box to the ON position. Overload protection To switch back on, start by turning the operating mode selection switch to the “OFF”... -
Page 19: Warranty
WARRANTY If your device develops a fault, please don’t hesitate to contact our customer service department on 03456 052 068, the majority of problems can be solved directly on the phone. 1. These warranty terms cover additional warranty rights and do not affect your statutory warranty rights.
