M-system 73VR2102 Startup Manual

Paperless recorder
Hide thumbs Also See for 73VR2102:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112
STARTUP GUIDE
1.
POINTS OF CAUTION ...................................................................... 2
2.
PACKAGE INCLUDES... .................................................................... 7
3.
ITEMS TO PREPARE........................................................................ 8
4.
COMPONENT IDENTIFICATION ........................................................... 9
5.
EXTERNAL DIMENSIONS ................................................................. 11
6.
INSTALLING THE UNIT .................................................................... 13
7.
PREPARATION & WIRING TO THE UNIT ................................................ 15
8.
SETTING UP THE RECORDER ............................................................ 17
9.
LET'S START RECORDING ............................................................... 23
PAPERLESS RECORDER
- Read Before Installation -
Contents
EM-7395-A Rev.8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 73VR2102 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for M-system 73VR2102

Summary of Contents for M-system 73VR2102

  • Page 1: Table Of Contents

    73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 PAPERLESS RECORDER STARTUP GUIDE – Read Before Installation – Contents POINTS OF CAUTION ..............2 PACKAGE INCLUDES............... 7 ITEMS TO PREPARE................ 8 COMPONENT IDENTIFICATION ............9 EXTERNAL DIMENSIONS ..............11 INSTALLING THE UNIT ..............

  • Page 2: Points Of Caution

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 POINTS OF CAUTION Thank you for choosing M-System. Before use, please read this manual carefully. If you have any problems or questions with the product, please contact M-System’s Sales Office or representatives.
  • Page 3 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 ■ POWER INPUT • Power input rating & operational range: Check the power rating for the unit on the specification label. Rating 100 – 240V AC: 85 – 264V, 47 – 66 Hz, approx.
  • Page 4 - If the screensaver is activated, the screen display does not recover when the screen is touched. • The backlight can be replaced in M-System factory. The LCD must be replaced at the same time. Please consult M-System. – 4 –...
  • Page 5 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 ■ MINIMIZING NOISE INTERFERENCE TO ANALOG SIGNAL CABLES • Noise entering through the analog signal cables may cause irregular measurement values, degradation of overall accuracy, and malfunction of the product.
  • Page 6 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 • Stabilize the temperature around the terminal block. DO NOT expose the terminal block in the direct line of air flow from air conditioners, cooling fans, or ventilation fans. Switching on and off the fans located close to the terminal block affects the ambient temperature.

  • Page 7: Package Includes

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 PACKAGE INCLUDES... Please confirm that all items mentioned below are included in the package. Paperless Recorder Startup guide (this booklet) Cold junction compensationn sensor Software CD (73VRPAC2) (attached to the terminals) Mounting bracket (two pieces) Not included for desktop type.

  • Page 8: Items To Prepare

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 ITEMS TO PREPARE • CF card Prepare one of the following model numbers: 1. Manufacturer: Hagiwara Solutions Model No.: MCF10P-xxxxS (Alternative model: CFI-xxxxDG) Capacity: 128 MB through 1 GB 2. Manufacturer: Apacer Technology Model name: CFC III Model No.: AP-CFxxxxE3ER-ETNDNRK Parts No.: 256 MB...

  • Page 9: Component Identification

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 COMPONENT IDENTIFICATION ■ FRONT VIEW (1) Touch Panel Screen (2) Front Cover (7) USB Connector (3) CF Card Slot (4) Eject Button (6) CF Card Access Indicator LED (5) Reset Button (1) Touch Panel Screen Trend chart and other data views and setup views are displayed.
  • Page 10 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 ■ REAR VIEW • 73VR2102, 2104, 2106 • 73VR2108, 2110, 2112 (8) Maintenance Jack (9) Power Indicator (9) Power Indicator (10) LAN Port (10) LAN Port (11) Alarm Output (11) Alarm Output...

  • Page 11: External Dimensions

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 EXTERNAL DIMENSIONS Unit: mm (inch) ■ 73VR2102, 73VR2104, 73VR2106 · Panel mount type ■ 73VR2102, 73VR2104, 73VR2106 136.5 (5.37) 172 (6.77) 151.5 (5.96) 29.5 2 to 26 panel thickness 144 (5.67) (1.16)
  • Page 12 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 · Desktop type 136.5 (5.37) 172 (6.77) 144 (5.67) 29.5 (1.16) The handle and rubber feet cannot be detached from desktop type unit. – 12 –...
  • Page 13 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 ■ 73VR2108, 73VR2110, 73VR2112 · Panel mount type ■ 73VR2108, 73VR2110, 73VR2112 136.5 (5.37) 195 (7.68) 151.5 (5.96) 29.5 2 to 26 panel thickness 144 (5.67) (1.16) (.08 to 1.02) Attach the mounting bracket either on the top/bottom or on the sides.
  • Page 14 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 · Desktop type 136.5 (5.37) 144 (5.67) 195 (7.68) 29.5 (1.16) The handle and rubber feet cannot be detached from desktop type unit. – 14 –...

  • Page 15: Installing The Unit

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 INSTALLING THE UNIT Mount the 73VR21x on the surface of a panel. ☛ See the 73VR21x Users Manual Section 2 for details. ■ ADAPTABLE PANEL Panel thickness: 2 to 26 mm Material: Steel ■...
  • Page 16 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 ■ PANEL MOUNTING (1) Insert the 73VR21x from the front side of the panel. (2) Remote the sheets covering the mounting bracket holes. Fix two mounting brackets either on the sides or on the top and bottom of the unit. Tighten screws.

  • Page 17: Preparation & Wiring To The Unit

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 PREPARATION & WIRING TO THE UNIT INSERTING CF CARD Insert a CF card to store recorded data and setting of Paperless Recorder. ■ INSERTING THE CF CARD (1) Turn off the power supply to the 73VR21x.
  • Page 18 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 ■ CONNECTING THE POWER SUPPLY • Please confirm rated voltage by spec label. Rated Voltage Operational Voltage Range Power Consumption AC Power 100 – 240V AC 85 – 264V AC Approx.

  • Page 19: Setting Up The Recorder

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 SETTING UP THE RECORDER Basic setup procedure is explained in this section, using an example of thermocouple input at Input 1 to store data in a CF card in 1 second storing interval.
  • Page 20 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 (5) ‘Basic setting’ view is on the screen. Touch [ Next ]. NOTES – Control Key Functions – Cancel : Return to Main setup view without ap- plying changes made in Quick setup.
  • Page 21 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 (9) ‘Tag’ view is on the screen. Touch [ Next ]. (10) Default tag names are on the screen. Touch these names to change. Leave the default ‘INPUT01’ as it is in this exam- ple.
  • Page 22 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 (11) ‘Engineering unit’ view is on the screen. Touch [ Next ]. (12) Default engineering units are on the screen. Touch these units to change. Touch the current unit selection for Input 1 and a keypanel appears on the screen.
  • Page 23 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 (13) ‘ A nalog type’ view is on the screen. Touch [ Next ]. (14) Default analog types are on the screen. Touch these type descriptions to change. Touch the current type selection for Input 1 and a list of available options will appear.
  • Page 24 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 (17) ‘Scaling’ view is on the screen. Touch [ Next ]. (18) Default scaling ranges are on the screen. Touch these values to change. The scaling range is fixed for a temperature input.

  • Page 25: Let's Start Recording

    73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 LET’S START RECORDING Touch [ MENU ] on the recording view to call up a list of functions. Touch [ Start ] to start recording. In order to show real time data on the screen, ‘Trend view’ , ‘Bargraph view’ and ‘Over- view’...
