BUILT-IN INPUT MODULES
PAPERLESS RECORDER
Models:
73VR2102 / 73VR2104 / 73VR2106
73VR2108 / 73VR2110 / 73VR2112
Users Manual
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Tel: +81-6-6659-8201
Fax: +81-6-6659-8510
http://www.m-system.co.jp/
E-mail: info@m-system.co.jp
1
73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 73VR2102 and is the answer not in the manual?

Questions and answers

Related Manuals for M-system 73VR2102

Summary of Contents for M-system 73VR2102

  • Page 1 73VR2102 / 73VR2104 / 73VR2106 73VR2108 / 73VR2110 / 73VR2112 Users Manual 5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN Tel: +81-6-6659-8201 Fax: +81-6-6659-8510 http://www.m-system.co.jp/ E-mail: info@m-system.co.jp 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 2: Introductions

    * Not included for desktop type. The product embeds Fugue Flash File System Solution provided by Kyoto Software Research, Inc. Fugue Copyright (c)1999-2008 Kyoto Software Research, Inc. All rights reserved. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 3: Table Of Contents

    5.3.6 DISPLAY PEN NUMBER ....................37 5.3.7 DISPLAY PEN NUMBER (OV) ..................38 5.3.8 AUTO PEN SWITCHING ....................38 5.3.9 CHART COLOR .......................38 5.4 ERROR OUTPUT ....................... 39 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 4 9.2.3 MENU CONTROL KEYS ....................78 9.3 BARGRAPH ........................ 78 9.3.1 PAGE & TIME INDICATOR ....................78 9.3.2 BARGRAPH ........................79 9.3.3 DIGITAL DISPLAY ......................80 9.3.4 MENU CONTROL KEYS ....................80 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 5 APPENDIX – 2. REPLACING TAG LABEL ............93 APPENDIX – 3. HOW TO SHOW TEMPERATURE UNIT ON THE 73VR21x SCREEN ......................93 APPENDIX – 4. FIRMWARE UPDATE HISTORY ..........94 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 6: General Descriptions

    When a part of the screen for a specific time index is touched, digital indicators appear on the screen indicating the data at the specified time. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 7 73VR21BLD. Modbus: Communicates with the host PC using Modbus/TCP protocol. Detailed information is pro- vided in 73VR21x Modbus/TCP Reference Guide. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 8 Zero and span adjustments are available by each channel. NOTE Please refer to the MSR128, 73VR21BLD and the 73VRWV Users Manuals for more information about respective software features. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 9: Before Getting Started

    • Desktop type cannot be mounted on a panel surface. • The handle and rubber feet cannot be detached from desktop type unit. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 10 2 and ch 3 are not connected, the accuracy of ch 4 measurement is affected by potential difference between the C terminals of ch 1 and ch 4. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 11 • The module is designed to function as soon as power is supplied, however, a warm up for 10 minutes is required for satisfying complete performance described in the data sheet. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 12: 73Vr21X Component Identifications

    (10) LAN Port Connects the LAN cable (10BASE-T or 100BASE-TX) (11) Alarm Output Terminal (12) Power Input Terminal (13) Trigger Input Terminal (14) Signal Input terminal Block 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 13: Installing The 73Vr21X

    Attach the mounting bracket either on the top/bottom or on the sides. 136.5 (5.37) • DESKTOP TYPE 172 (6.77) 144 (5.67) 29.5 (1.16) The handle and rubber feet cannot be detached from desktop type unit. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 14 Attach the mounting bracket either on the top/bottom or on the sides. • DESKTOP TYPE 136.5 (5.37) 144 (5.67) 195 (7.68) 29.5 (1.16) The handle and rubber feet cannot be detached from desktop type unit. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 15 (114 × n) – 6 Notes 1. Dimensional tolerance ±3% unless otherwise specified. (±0.3 mm for <10 mm) 2. Desktop type cannot be mounted on a panel surface. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 16 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 17: Terminal Wiring

    FRONT side of the sensor visible on top side of the terminal 1C. FRONT Side CJC Sensor REAR Side 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 18 1. Confirm that the power supply is turned off and open the power input terminal cover. 2. Connect the wires to the terminal. 3. Close the cover. n POWER INPUT TERMINAL ASSIGNMENT – (–) – Power Input Terminals 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 19: Cf Card

    CF CARD M-System will not guarantee the product’s described performance if a CF Card other than purchased from M-System, or specified below, is used. CF card can be purchased from M-System. Consult M-System. 1. Manufacturer: Hagiwara Solutions Model No.: MCF10P-xxxxS (Alternative model: CFI-xxxxDG) Capacity: 128 MB through 1 GB 2.

  • Page 20: Sd Card

    SD card may be lost. • When formatting SD card, use a dedicated software “SD Card Formatter” . “SD Card Formatter” is downloadable at SD Association’s web site. https://www.sdcard.org 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 21: Hardware Configurations

    0.54 0.27 50/60 Hz 0.37 0.50 0.25 0.095 60 Hz 0.34 0.46 0.23 Multiplied by two (2) for RTD and potentiometer input. *1. Standard setting 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 22: Vr21X Views & Basic Operations

    You can copy the setting stored in the unit to a card using the Builder Software or the reading/writing operation of the unit via USB Flash Memory. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 23: Setting Up The 73Vr21X

    Digital display Data file used volume Display pen number Display pen number (Overview) Auto pen switching Chart color Error output Enable / Disable Output ch. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 24 Group color Comment Comment Comment direct input Group name Group color Comment (Group 7 comment can be modified during recording) Write setting file Read setting file 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 25 Important ! In order to apply new setting, touch Record key to save and return to one of the Display views (Trend, Overview or Bargraph). 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 26: System Setting

    Cold Start At a restart, the 73VR21x stands by showing the initial view. Hot Start At a restart, the 73VR21x automatically starts recording. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 27: Data Storing Form

    Touching the current selection of the Touch panel beep shows selectable options at the bottom of the screen. The setting can be modified even while recording is in progress. Beep sound is off. Beep sound is on. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 28: Date And Time

    In order to apply new IP address setting, the 73VR21x must be restarted. Be sure to return to one of the Display views to save the new setting. All new setting will be lost otherwise. Consult your network administrator for IP address. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 29: Subnet Mask

    Touching the current selection of the linger time replaces the screen with a numeric keypad. Enter a desired value on the keypad and touch OK. Linger time 0.0 to 3000.0 seconds (100 msec. increments) 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 30: Data Storing Method

    0.54 0.27 0.37 0.50 0.25 0.095 50/60 Hz* 60 Hz 0.34 0.46 0.23 Multiplied by two (2) for RTD and potentiometer input. *1. Standard setting 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 31: Storing Setting

    (See “5.2.4 EVENT RECORDING”) Time specified Store at defined time mode Recording is automatically initiated and stopped at predefined time. (See “5.2.5 STORE AT A DEFINED TIME MODE”) 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 32: Remote Trigger Recording

    ‘e’ can be used to input an exponential value such as ‘1e9.’ Entering ‘e’ in any other way (e.g. ‘1ee’) will not be recognized as a numeral. 4. Condition: Choose among the abovementioned options. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 33: Event Recording

    Data recording is initiated at a sinking edge of the trigger input pulse. CAUTION ! If you touch Record button while the trigger condition is true, no recording starts until it turns true for a next time. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 34: Store At A Defined Time Mode

    CAUTION ! If you touch Record button while in the specified time, no recording starts until a next specified time. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 35: Display Setting

    The chart speed options may be limited when certain storing intervals are selected. Refer to the table below. CHART SPEED 1/32 1/160 1/480 1/960 STORING INTERVAL 100 msec. ≥500 msec. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 36: Graph Direction

    The momentary value and the tag name of the data displayed on the screen. The tag name of the data displayed on the screen. Value The momentary value of the data displayed on the screen. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 37: Digital Display

    Touching the current selection of the Display Pen Number shows selectable options at the bottom of the screen. The setting can be modified even while recording is in progress. Choose among the following options: 2 pens 4 pens 6 pens 8 pens 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 38: Display Pen Number (Ov)

    Touching the current selection of the Chart Color shows selectable options at the bottom of the screen. The setting can be modified even while recording is in progress. Choose among the following options: Gradation 1 Gradation 2 Plain (Light) Plain (Dark) Plain (White) 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 39: Error Output

    11A, 11B, 11C Input 11 6A, 6B, 6C Input 6 12A, 12B, 12C Input 12 TRIG +, TRIG – Input 7 TRIG +, TRIG – Input 13 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 40: Pen Setting (Input)

    Touching the current selection of the Tag name opens an alphanumeric keypad. Tag name Max. 8 characters Unit Touching the current selection of the Unit opens an alphanumeric keypad. Unit Max. 4 characters 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 41 (0% and 100%) within the measurable range. For temperature input, the input range is equal to the measurable range, thus fixed. Input range Max. 6 digits including a decimal point and minus sign 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 42 Pt 500 -200 – 850 -328 – 1562 Pt 1000 -200 – 850 -328 – 1562 Cu 10 @25°C -50 – 250 -58 – 482 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 43 Plot positions can be shifted in parallel on the trend chart. This function is useful when multiple graphs are overlap- ping. You can separate the plot positions while no other data is changed. Scale shift Selectable within -100 to 100% 20% shift 10% shift 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 44 With RTD input, the signal may go transiently to the opposite direction from the burnout setting. With DC input, the burnout setting is ignored and the burnout sensing current is cancelled. None No burnout Upscale Upscale burnout Downscale Downscale burnout 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 45: Pen Setting (Alarm)

    Corresponding parameters are marked with the same numbers. These options can be changed while recording. 73VR21BLD Alarm Setting Dialog Box 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 46 For example, Down message (0-1) is sent when the signal goes below the Limit 1. Message contents up to 10 characters respectively for Up and Down. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 47 Set Enable to the status for which Messages are to be displayed on the Overview and Alarm History. OFF Message, ON Message These messages is used for Overview and Alarm History. Message contents up to 10 characters respectively for Up and Down. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 48: Pen Setting (Function)

    2 decimal places 1 decimal place No decimal point Overview Color Specify the bargraph color for the pen in the Overview. Use the color palette. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 49 Initial value is used in the function operation cycle as default data sample when ‘last’ data is specified in an equation. If you do not need, leave the field blank. Initial value Max. 6 digits including a decimal point and minus sign 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 50 Specify a time constant and an input channel. Touching Inp.1 opens the Tag name selector view. Select an input signal used for the operating function. Time constant Specify between 0.00 and 100.00 seconds. Max. 2 decimal places. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 51 Down Reset when the trigger input turns from ON to OFF. Reset while the trigger input is ON. Reset while the trigger input if OFF. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 52 (2) The power function results in overrange when the results exceeds the range from ‘-1x10 ’ to ‘1x10 .’ No data is displayed on the screen, and CSV data cells are blank. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 53 Touching the number next to Drop out opens a numeric keypad. Enter appropriate values. Drop out Max. 6 digits positive number including a decimal point. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 54 ‘e’ can be used to input an exponential value such as ‘1e9.’ Entering ‘e’ in any other way (e.g. ‘1ee’) will not be recognized as a numeral. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 55: Hardware Configuration

    When the line noise filter setting is changed, measured values immediately after the change may contain errors by the AD conversion cycle change. Wait for 10 seconds before resuming data record- ing after it has been changed. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 56: Zero/Span Calibration

    Input signal : Measured value : Calibrated value (Zero) : Measured value : Calibrated value (Span +) 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24 : Measured value : Calibrated value (Span –)
  • Page 57 3. In order to eliminate noise interference during the calibration procedure, set the AD conversion mode to Low setting. 4. Choose the channel number indicated to the right of Zero/span calibration. For Input 7 through 12, go to next page. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 58: Confirming Changes

    In order to apply a new setting stored in the CF Card using the 73VR21BLD, restart the 73VR21x. For detailed infor- mation about the 73VR21BLD, please refer to the users manual for the model. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 59: Quick Startup

    STORING INTERVAL Touch the dark blue area (default selection) to call up a list of selectable intervals, choose one and touch [Next]. Help view (Storing interval) 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 60 Max. 8 alphanumeric characters. Help view (Tag) The screen example to the right is applied for the 73VR2106. Touch Next to show more input selections. Touch [Next]. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 61 [Next]. Help view (Analog type) The screen example to the right is applied for the 73VR2106. Touch Next to show more input selections. Touch [Next]. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 62 Help view (Scaling) The screen example to the right is applied for the 73VR2106. Touch Next to show more input selections. Touch [Next]. Lower range Upper range 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 63 When the 73VR21x is setup using the Quick Setup, the plot positions on the screen is automatically set to the same range as the scaled range (full measurable range for temperature). 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 64: Entering Comments

    1. Touch Comment Setting on the Main view. 2. Touch Group key. 3. Choose a group. 4. Enter the group name and choose a color. Group Max. 10 characters 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 65: Setting Comments

    The comment is written in when the subject pen signal turns from ON to OFF. Pen number Choose the pen number for the trigger signal. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 66: Operating Functions

    (K1X1+A1) / (K2X2+A2) + A3 Specify measured data or function data for X1 and X2 (analog signal only), gains (K1 and K2) and biases (A1, A2 and A3). 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 67: Logic Functions

    ∑ (input or function data) x (3600/GAIN) ∑ (input or function data) x (60/GAIN) Hour ∑ (input or function data) x (1/GAIN) ∑ (input or function data) x (0.04166/GAIN) 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 68: Filter

    With 1 sec. or longer storing rate, function results displayed on the screen maintain the last value periodically, because the function is executed the sampling rate and displayed on the screen. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 69: Peak Hold

    Y = X1 Reset When Reset condition is true: Y = X1 Time Y : Function data X1 : Measured input data : Hold value 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 70: F Value Calculation

    In the Retrieve view, input value is displayed, not direction. Recorded data is input value, not direction. Display in the 73VR Data Viewer (73VRWV) and converted CSV data is not direction. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 71: Display Views

    When more than 5 characters (including sign and decimal point) are to be shown on the scale, only those at 0%, 50% and 100% are indicated. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 72: Chart

    When it is higher than the data range limit 1 x 10 , the pen pointer remains at the extreme right of the chart. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 73: Digital Display

    In order to reduce the display size to the original state, touch the large display once again. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 74: Writing Comments

    (2) when the 73VR21x is recording in the CF Card. No comment can be written in while you are hot-swapping the CF Card. While the automatic comment entry is on, DO NOT execute a FTP data transfer. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 75 If the condition comes to be true and then untrue between data storing cycles, no comment writing is executed. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 76: Menu Control Keys

    100%, the 73VR21x overwrites the oldest data with a new one. There will be no update on this indicator after 100%. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 77: Data Indicators

    Analog data is added with a momentary value in engineering unit. Alarm history is also indicated if the alarm setting has been enabled. When the alarm is disabled, time index shows --/--/-- --:--:--. Discrete data is also added with ON/OFF history data. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 78: Menu Control Keys

    Refer to Section “9.2.1 PAGE & TIME INDICATOR” 1 for detailed explanations. Date / Time Date and time is shown in black characters when the recorder is stopped, in green while recording. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 79: Bargraph

    When more than 5 characters (including sign and decimal point) are to be shown on the scale, only those at 0%, 50% and 100% are indicated. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 80: Digital Display

    In order to show Menu key in the Retrieve view, touch on the screen. The digital display with Menu and Hide keys appear on the lower part of the screen. Basic Retrieve view. Retrieve view with digital display (Menu and Hide keys). 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 81: Data Display

    When an input (or function data) is in error, it waveform is no plotted on the screen. ‘ERR’ is indicated on the digital display. For a 2-byte integer function data, ‘0’ is indicated on the digital display. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 82: Menu Control Keys

    Comment history Touching Comment history key switches the screen to the Comment history view. Record Touching Record key switches the screen back to the Display view. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 83: Long Span View

    It may need time to refresh the display to show the data with the new time setting when the data volume is very large or the time span is very long. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...
  • Page 84 The control keys on a horizontal chart are always present. Keys other than shown above are available when you touch Menu key. Horizontal chart, 2nd control panel. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 85: Data Search

    Alarm History view. When you touch the top part of the screen (enclosed in the frame), control keys appears. Alarm history. Alarm history control keys. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 86: Data Display

    Oldest Touching Oldest key moves the screen to the oldest alarm event. Newest Touching Newest key moves the screen to the newest alarm event. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 87: Comment History

    Touching Jump key when a specific comment is selected switches the screen to the Retrieve view where the data at the moment of comment entry is indicated. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 88: Menu Control Keys

    Oldest Touching Oldest key moves the screen to the oldest comment row. Newest Touching Newest key moves the screen to the newest comment row. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 89: Data & Files

    PARAMETER FILE The parameter file contains information about the 73VR21x’s system and pen configurations. The 73VR21x reads this file at the startup to apply the parameters. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 90: Data Storage Time

    **1KB-CF card’s memory size is calculated as 1024 bytes. This calculated result is only for approximate estimation since the data file must be smaller than the full capacity of a CF Card. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 91: Writing/Reading Setting File In An Usb Flash-Memory

    (3) Choose a file and touch OK. If you do not want to save a file, touch Cancel. Figure: File read view. Figure: File list. Figure: File selected. CAUTION ! Touch Back to Record key to apply the new setting. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 92: Hot Swapping The Cf Card

    To use this function, choose Enable in the Display Setting. NOTE While the automatic comment entry is on, DO NOT execute a FTP data transfer. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

  • Page 93: Appendix - 1. Backlight Failure

    • The screen becomes dark after the screen saver is activated, and then it does not recover even when the screen is touched. The backlight can be replaced at M-System Factory. Stop recording, turn off the power supply and consult M-System. The 73VR21x operation can be remotely stopped using the 73VR21BLD software. Refer to the 73VR21BLD users manual for detail.

  • Page 94: Appendix - 4. Firmware Update History

    Major firmware update history (version 5 or later) is following. Ver. 5.00F “Drop out” function to “Analog accumulation” function added. Ver. 5.02.xx “Anemoscope” function added. Ver. 5.03.xx SD card availability added. 73VR2102 / 73VR2104 / 73VR2106 / 73VR2108 / 73VR2110 / 73VR2112 USERS MANUAL EM-7395-B Rev.24...

This manual is also suitable for:

73vr210473vr210873vr211073vr211273vr2106
