Usage Instructions; Battery Information; Troubleshooting Guide - lmp LinkTemp Manual

L NK
Non-Contact
USING THE THERMOMETER USING THE THERMOMETER
2-color LCD
Audio On/Off
(English/Spanish)
MODE
MEM
ON/SCAN
Surface Temp Mode
Body Temp Mode
Room Temp Mode
Celsius
Temperature
Display Value
Fahrenheit
Audio ON
(English & Spanish) Memory
Low Battery
Indicator
TROUBLESHOOTING
Reasons for Lo message display
Temperature reading is hampered
by hair, perspiration or makeup.
Temperature hampered by an air
draft or dramatic change in ambient
temperature.
Temperature readings are too close
together and the thermometer did
not have time to reboot.
Measuring too far from the forehead.
The ambient temp < 30˚F (0˚C).
Measuring after cold compress,
taking medicine or bathing.
TEMP
Infrared Thermometer
CHANGING TEMPERATURE MODE CHANGING TEMPERATURE MODE
While the thermometer is turned on, press the MODE
button to toggle through the three temperature mode
options - BODY, SURFACE or ROOM.
logo
NOTE: When first using the thermometer, the default is
set to BODY mode.
NOTE: Measurement ranges for each temperature
mode are as follows:
B BODY mode: 89.6˚F to 109˚F (32˚C to 42.9˚C)
SURFACE mode: 32˚F to 140˚F (0˚C to 60˚C)
ROOM mode: 32˚F to 104˚F (0˚C to 40˚C)
NOTE: Once the thermometer is powered on, the last
temperature mode measured will default as the
current temperature mode.
NOTE: Always use the BODY mode to measure internal
human temperature.
CHANGING TEMPERATURE UNIT
While the thermometer is turned on, press the MODE
andthe buttons at the same time for 3 seconds, the
screen will display F-1. Select the
and MODE button for Fahrenheit. Confirm by pressing
MEM button. Then to exit the setting, press MEM
button quickly two times.
LOW BATTERY DETECTION
If the battery voltage is not more than 2.7V, the
LinkTemp Non-contact Infrared Thermometer will
display the flashed symbol
replace both batteries.
Make sure there is no obstruction
or dampness prior to taking
temperature.
Make sure there is no air blowing in
the area of use, this could affect the
infrared reading.
Pause for 3-5 seconds minimum
between two readings; a 5 second
pause is recommended.
Take measurements at the
recommended distance of 1.2" to 2"
(3 to 5 cm) from forehead.
Make sure measuring environment
temperature is higher than 32˚F (0˚C).
If any of these apply, make sure to
wait 30 minutes and test again.
TM
Quick Start Guide
button for Celsius
to remind you to
Advice Reasons for Hi message display
When body temperature is above
109.2˚F (42.9˚C).
F2 value is set higher than desired.
The room/ambient temperature is
above 104˚F (40˚C).
The surface temperature exceeds
140˚F (60˚C).
LMP001
TAKING A MEASUREMENT TAKING A MEASUREMENT
1. Press ON/SCAN button to power on the thermometer.
When the devise is ready, the LCD screen will turn blue.
2. Position the thermometer between 1.2" to 2" (3 to 5 cm)
from the patient's forehead.
3. Press ON/SCAN button to take measurement.
4. A measurement will be displayed on the LCD screen.
• To repeat the process, return to step 2.
• Allow 3 to 5 seconds between measurements.
5. The thermometer automatically turns off after
30 seconds of inactivity.
1.2" - 2"
Note: High temperature
alarm default setting is
100.4˚F (38˚C).
CHANGING THE BATTERIES
The LinkTemp Non-contact Infrared Thermometer
comes with 2 AA alkaline batteries. When the LCD screen
displays , both batteries should be replaced. Open the
lid on the underside of the thermometer and replace the
batteries, taking great care with the correct battery
positioning.
Advice
Temperature reading exceeds
measurement range of 89.6˚F to
109.2˚F (32˚C to 42.9˚C). Make sure
there is no hot air blowing in the area
of use. If necessary, immediately seek
medical attention.
Reset high alarm temperature setting
closer to or at default value of
100.4˚F (38˚C).
Make sure to operate thermometer
between 50˚F to 104˚F (10˚C to 40˚C).
Temperature reading exceeds
measurement range of 32˚F to 140F
(0˚C to 60˚C).
9247 Research Drive
Irvine, CA 92618 USA
888.425.1149
www.linksmed.com
