Summary of Contents for Syscom Video CVM2154L
- Page 1 Instruction Manual 21 - INCH COLO(U)R MONITOR...
-
Page 2: Explanation Of Graphical Symbols
WARNING: TOREDUCE THERISK OF FIRE OR ELECTRIC SHOCK, DONOT EXPOSE THIS PRODUCT TORAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS READ INSTRUCTIONS -- All the safety and operating POWER CORDS -- Do not allow anything to rest on the instructions should be read before the appliance is operated. power cord. Do not locate video monitor or equipment where the cord will be abused by persons walking on it. -
Page 4: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT INFORMATION TO THE USER : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS B DIGITAL DEVICE, PURSUANT TO PART 15OFTHEFCCRULES.THESELIMITSAREDESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE IN A RESIDENTIAL INSTALLATION. THIS EQUIPMENT GENERATES, USES AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTIONS, MAY CAUSE HARMFUL INTERFERENCE TO RADIO... -
Page 5: Front Panel
FEATURES - Attractively styled cabinet Convenient front controls Crisp picture Video A input/output looping with automatic 75 ohm termination Recessed carrying handle OPERATING INSTRUCTIONS Front Panel 1. CONTRAST control 5. POWER switch 2. BRIGHT control 3. COLO(U)R control 4. TINT control . - Page 6 . COLO(U)R control Adjust the COLO(U)R control to set the colo(u)r (saturation) level. When turned counterclockwise, the colo(u)r seems pale (low colo(u)r). When turned clockwise, the colo(u)r seems saturated (high colo(u)r). . TINT control (NTSC only) Adjust the TINT control for the proper colo(u)r phase or flesh tone. When turned counterclockwise, the skin tone become greenish.
-
Page 7: Rear Panel
Rear Panel 6. AC/IN 7. VIDEO A(IN/OUT) connector 6. AC/IN Input for power cord connected to electrical outlet.(100V - 240V) 7. VIDEO A connector There are four BNC connectors for the composite VIDEO A input and output. Note : The impedance is automatically set to 75 ohm by the input of a signal on the input connector while operating in a single connection mode. -
Page 8: Troubleshooting
TROUBLESHOOTING PROBLEM CHECK No Video 1. Verify power to all pieces of equipment. 2. Verify that the power switches are in the ON position. 3. Verify that the lens caps have been removed from the lens or that the iris of the lens is open. VIDEO, 1. -
Page 9: Single Connection
CONNECTION SINGLE CONNECTION Video camera from Video output MULTIPLE CONNECTION Video camera from Video output Up to 3 monitors can be connected using the loop-through feature of this unit. When this monitor is connected to additional monitors, the same picture can be obtained on all the connected monitors. -
Page 10: Specifications
SPECIFICATIONS 21-inch Diagonal, 90 Deflection Angle (useful screen size: 20.3") AC 90V - 132V ~ 50Hz/60Hz AC198V - 254V ~ 50Hz/60Hz CAUTION : Confirm the model number and the power source on the cover page before use. 80 Watts NTSC or PAL standard 450 TV lines at center NTSC/PAL 1.0 Vp-p, 75 Ohms, negative sync(BNC) - Page 11 21 - INCH COLO(U)R MONITOR 50301008A Printed In Korea...
