Page 1 EOWAVE...
Page 2: Safety Instructions
Swarm, always check for the correct voltage. Before using Quadrantid Swarm in a foreign country,check whether the mains voltage is compatible with the unit. QUADRANTID SWARM • When Quadrantid Swarm is not in use, disconnect the power supply from the power outlet. This will save energy (and keep your electric bill within reason). Paraphonic synthesiser •...
Page 3 freq mod. Spread : this function only works in monophonic mode. It controls the frequency ratio between the 8 VCOs.Depending on the model this ratio can be harmonic (organ and string) or inharmonic (the others).Character : this parameter has different functions depending on the VCO model Organ, String, Drone, Reed : it determines the amount of signal passing thru a wavefolder.
Page 4: Midi Implementation
The LFO section is pre-patched to cutoff pole 2 and features seven selectable waveforms : triangle , sine, ramp down , ramp up , and 3 different random modes. the 8th selection which is the sequencer CV out (allowing the sequencer to be patched to other compatible devices). Speed is set using the ‘speed’ knob.
Page 5 Patchnotes ........................
Page 6 Patchnotes ........................
