- Page 1 C8-1G 8 Ports High Density Copper Tap CUSTOMER SUPPORT INFORMATION To order or for a technical information support: Phone: +33 3 88 10 18 30 or Fax: +33 3 88 10 18 35 Mail order: COMCRAFT 17A, rue des Frères Lumière 67201 Eckbolsheim - France Website: www.profitap.com...
- Page 2 ® PROFITAP is a brand of COMCRAFT, Inc. Our engineers have been developing innovative LAN/ WAN and Datacom Test Equipment for over 25 years. Commitment to Quality and Customer Satisfaction is paramount in everything we do to achieve our first and...
-
Page 3: Table Of Contents
This Package includes : 1x C8-1G Main Unit 2x Power cord Index pages General Information Functional Description 2.1. Interface connectors 2.2. LEDs : Speed/Link/Activity 2.3. Power 2.4. Power Failure Installation Additional information www.profitap.com Page 3... -
Page 4: General Information
It mirrors any packet size, bad CRC, VLAN traffic, sees both ends of full-duplex links. C8-1G has no IP address and is invisible to the network. It is fault tolerant, bypasses data on power failure, the monitor ports are none-intrusive to the network. -
Page 5: Functional Description
2. Functional description 2.1 Interface connectors C8-1G has 8 x 4 RJ45 ports. Network ports A and B are connected to the network, Monitor ports A and B are con- nected to the analyzer. 2.2 LEDs : Speed/Link /Activity LEDs indicate Speed, Activity and Link for each of the 32 ports. -
Page 6: Installation
The Monitor Ports Link LEDs light when link is found. * Activity received into NetworkA and NetworkB will be mirrored on the respective Monitor Ports and blink the ACTIVITY LEDs. The maximum distance between any of the connected devices is 100mtr. www.profitap.com Page 6... -
Page 7: Additional Information
Front plate: 482 x 44 mm Weight : 2200 gr Environmental Specifications: Operating Temperature: 0°C to 40°C Storage Temperature: -22°C to 70°C Humidity: 10 to 90%, non-condensing Certifications: RoHS, CE, FCC class A and IEEE 802.3 compliant www.profitap.com Page 7... - Page 8 Trademarks The trademarks mentioned in this manual are the sole property of their owners. Rev 3.7 COMCRAFT +33 3 88 10 18 30 17A, rue des Frères Lumière 67201 Eckbolsheim +33 3 88 10 18 35 France www.profitap.com...
