The In-Ex SPRAYER 50 is an entry-level spot sprayer which can be used in a variety
of applications. It is especially suitable for use with small vehicles or anywhere where
there is a flat surface to attach it to and a source of 12VDC power. The Sprayer 50 is
supplied ready to use and includes a sturdy tie down strap and 1.5 metre power
cable.
1025 (pump size 3.8Lpm)
1080 (pump size 7.6Lpm)
1

WARRANTY AND LIABILITY

Use of the equipment
1.1
You must satisfy yourself as to the suitability of the equipment for your intended use(s)
of the equipment.
Your relationship with the retailer
1.2
Where you consider you have a warranty claim (or any other claim) in relation to the
equipment, you must contact the retailer who sold you the equipment, not C-Dax
directly. The retailer is responsible for liaising with C-Dax in respect of your claim.
Warranty
1.3
C-Dax warrants to the original purchaser that the equipment is sold free from defects in
materials and workmanship for a period of 12 months from date of first retail sale (6
months from date of first retail sale if the equipment is sold in the U.K.) subject to the
terms set out below.
1.4
C-Dax will at its option repair or replace the defective equipment (or part of the
equipment) or notify the retailer of the equipment to refund the purchase price for such
defective equipment to you in the event of a breach of this warranty, subject to the
terms set out below.
Liability
1.5
Except for the warranty set out in clause 1.2 above, all warranties and representations
(including those expressed or implied by law) in respect of the equipment or advice
relating to the equipment provided to you by C-Dax are excluded to the extent
permitted by law.
1.6
Notwithstanding anything else in this manual, C-Dax's maximum liability to you (in the
event that such liability exists) in respect of any breach of warranty, any matter set out
in this manual, or for defective equipment or advice relating to the equipment provided
is limited at C-Dax's option to:
Sprayer 50 Pt.No 1025 / 1080
(Leaflet 2400-1400 Issue 6, May 2018)

DESCRIPTION

WARRANTY
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPRAYER 50 and is the answer not in the manual?

Questions and answers

Summary of Contents for In-Ex SPRAYER 50

  • Page 1 It is especially suitable for use with small vehicles or anywhere where there is a flat surface to attach it to and a source of 12VDC power. The Sprayer 50 is supplied ready to use and includes a sturdy tie down strap and 1.5 metre power cable.
  • Page 2 repairing or replacing the equipment (or part of the equipment); or notifying the retailer of the equipment to refund the price for the equipment paid by you. Notwithstanding anything else in this manual, in no event will C-Dax be liable, whether in contract, tort (including negligence) or otherwise: where you have altered or modified the equipment, misused or misapplied the equipment, or the equipment has been subjected to any unusual, excessive or...
  • Page 3 Cable ASY-Battery-2.2M INSTALLATION Place the Sprayer 50 on the vehicle with the switch facing the operator. Secure the tank in place using the ratchet strap. On ATV carriers the long strap should be hooked onto the carrier frame and looped over the tank at the lid end. The short strap with the ratchet is similarly placed at the opposite end.
  • Page 4 MAINTENANCE Cleaning Tank and Spray Gun When spraying is finished rinse the tank with clean water and pump the contents out through the spray gun. A triple rinse is recommended. The tank may also be drained by removing the drain plug at the lid end. Filter Maintenance After each use or when the tank has been emptied (whichever comes first) it is recommended that the suction filter located under the white nut at the tank outlet be...
  • Page 5 EXPLODED PARTS DIAGRAM...
  • Page 6 6200-9400 Pipe-Fitting-Thru Tank-Elbow-10 Shankx11/16UNFM-Nylon 8840-8410 Tube-Transluscent-10MM-100PSI (70LG) 4100-0008 Hose-Spray-Delivery-40 Bar-8.5mm ID-Yellow (110LG) 4100-0008 Hose-Spray-Delivery-40 Bar-8.5mm ID-Yellow (5m) 8410-8450 Strap-Tie Down-Ratchet-Blue 3600-1010 Fuse Link-Electrical-Standard Blow-15 Amp-1"x1/4"-Glass 8427-6000 Sub-Lid & Ring Assembly-D150-In-Ex Vented-Nylon-Black 1500-3700 Cable-Electrical-Loom-Battery Feed-2.2M 1500-6500 Cable-Electrical-Loom-Sprayer 50/100/Sprayon 200/SM50-Flojet 3400-1110 Filter-Basket-D150-Mesh...
  • Page 7 FLOJET SPRAY PUMP RELACEMENT PARTS The following replacement parts available for the 12V Flojet 3.8 L/Min pump are available from any C-Dax dealer:...
  • Page 8 FLOJET SPRAY PUMP RELACEMENT PARTS The following replacement parts for the 12V Flojet 7.6 L/Min pump are available from any C-Dax dealer: NOTE Please select the correct hose connection type for your pump The below pictures show the quadport type (Left hand photo) and threaded type (Right hand photo).
