Installation Guide
iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications iSG18GFP
Installation Guide
This controlled document is the property of iS5 Communications Inc. This
document contains proprietary information.
Any duplication, reproduction or
transmission to unauthorized parties without prior permission of iS5
Communications Inc is strictly prohibited. All rights will be protected by iS5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IS5 COMMUNICATIONS iSG18GFP
Summary of Contents for IS5 COMMUNICATIONS iSG18GFP
- Page 1 Ver: 1.2 Date: 22.03.2016 iS5 Communications iSG18GFP Installation Guide This controlled document is the property of iS5 Communications Inc. This document contains proprietary information. Any duplication, reproduction or transmission to unauthorized parties without prior permission of iS5 Communications Inc is strictly prohibited. All rights will be protected by iS5...
- Page 2 The information in this document is subject to change without notice and describes only the product defined in the introduction of this document. This document is intended for the use of customers of iS5 Communications only for the purposes of the agreement under which the document is submitted, and no part of it may be reproduced or transmitted in any form or means without the prior written permission of iS5 Communications .
- Page 3 Communications however has made all reasonable efforts to ensure that the instructions contained in this document are adequate and free of material errors and omissions. iS5 Communications will, if necessary, explain issues which may not be covered by the document.
-
Page 4: Table Of Contents
Mounting of iS5 Communications iSG18GFP in explosive atmospheres within TYPE ‘n’, ‘d’, ‘p’, ‘tD’ and ‘pD’ enclosures ·········································································· 16 Cable Glands for Mounting iS5 Communications iSG18GFP within TYPE ‘n’, ‘d’, ‘p’, ‘tD’ and ‘pD’ enclosures ···················································································· 17 Mounting for DIN Rail ····················································································· 18 iS5 Communications Inc. - Page 5 Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Distance kept for natural air flow ···································································· 19 Grounding ······························································································ 20 Connecting to a Power Source ············································································· 21 POE Ports ···································································································· 25 The Switch Led indicators ···················································································· 27 Switch Configuration ························································································ 28 Connecting to the Console Port ······································································...
-
Page 6: Introduction
Ethernet platform with a unique application-aware processing engine. As an Industrial Ethernet switch the iS5 Communications switch provides a strong Ethernet and IP feature-set with a special emphasis on the fit to the mission-critical industrial environment such as harsh environment, high reliability and network resiliency. -
Page 7: Using This Document
Date: 22.03.2016 Using This Document Documentation Purpose This user guide includes the relevant installation and basic management information for the iS5 Communications iSG18GFP. Intended Audience This user guide is intended for network administrators responsible for installing and configuring network equipment. -
Page 8: Conventions Used
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Conventions Used The conventions below are used to inform important information: NOTE Indicating special information to which the user needs to pay special attention. CAUTION Indicating special instructions to avoid possible damage to the product. -
Page 9: Safety Information
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Safety Information Shock Hazard To avoid shock, do not perform any servicing other than those contained in the unpacking instructions. Shock Hazard HIGH VOLTAGE Disconnect the product from the power line before removing the cover. Any adjustment... - Page 10 Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Shock Hazard GROUNDING Before connecting the product to the power line, make sure that the protective ground terminal of the device is connected to the safety ground conductor of the mains power cord.
- Page 11 Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Laser Warning The equipment is designed to be used with Class 1 Laser fiber optic transmitters which may endanger your eyes. Do not look directly into the fiber optic cables or transmitter.
- Page 12 Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Caution The unit is designated to operate in environments of up to 70 degrees ambient temperature. For AC units, under some conditions the housing of the unit might get hot and direct touch should be avoided.
-
Page 13: System Description
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 System Description The iS5 Communications iSG18GFP is a compact switch product family with high L2/L3 switching capability secure servicing industrial protocols. Power Supply Module Available power input versions and their respective current consumption:... -
Page 14: Input Circuit Protection
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Input circuit protection Following are maximum values of upstream fuse / circuit breaker protection Input Voltage Max current [A] 24vDC 48vDC 110vAC 220vAC Main Unit The Main Switch module is responsible for: •... -
Page 15: Installing The Isg18Gfp
Mounting iS5 Communications iSG18GFP – Non Explosive Enviroment The iS5 Communications iSG18GFP is designed as a fixed unit that is connected in its rear side to an industry standard DIN rail and is setup with the DIN-rail mount as the default setup. -
Page 16: Mounting Of Is5 Communications Isg18Gfp In Explosive Atmospheres Within Type 'N', 'D
• The iS5 Communications iSG18GFP is designed as a fixed unit that is connected in its rear side to an industry standard DIN rail and is setup with the DIN-rail mount as the default setup within the enclosure. -
Page 17: Cable Glands For Mounting Is5 Communications Isg18Gfp Within Type 'N', 'D', 'P', 'Td
R3.5 Ver: 1.2 Date: 22.03.2016 Cable Glands for Mounting iS5 Communications iSG18GFP within TYPE ‘n’, ‘d’, ‘p’, ‘tD’ and ‘pD’ enclosures The iS5 Communications iSG18GFP, when installed within explosion- protected enclosures, its interface cables must be sealed with cable glands suitable for the relevant type of protection installed according to IEC 60079-14. -
Page 18: Mounting For Din Rail
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Mounting for DIN Rail These mounting instructions assume that a standard DIN rail has been previously installed. If one has not then use the installation instructions that come with the DIN rail to mount the DIN rail on the wall. -
Page 19: Distance Kept For Natural Air Flow
Ver: 1.2 Date: 22.03.2016 Distance kept for natural air flow Proper installation requires keeping 10cm distance from top and bottom between the iS5 Communications switch to any other neighbor device for proper cooling using natural air flow. above below kept clear... -
Page 20: Grounding
Ver: 1.2 Date: 22.03.2016 Grounding The iSG18GFP chassis ground connection uses a #6-32 Screw. We recommend terminating the ground connection using a #6 ring lug, and a torque setting of 15 in.lbs (1.7Nm). The red outline indicates the location of the chassis ground. -
Page 21: Connecting To A Power Source
R3.5 Ver: 1.2 Date: 22.03.2016 Connecting to a Power Source The iSG18GFP router supports dual redundant power supplies (PWR1 and PWR2). There are 3 options for each power supply: 1. LV: Dual Input 18-32VDC 2. MV: Dual Input 36-60VDC 3. - Page 22 Insert the Live or Positive (+) wire into the position that aligns with the ‘L’ on the iSG18GFP and tighten the screw. Insert the Ground wire into the position that aligns with the ‘G’...
- Page 23 Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Insert the HV Power Input connector into the iSG18GFP. Secure it with the 2 screws on each side. CAUTION • 100-240VAC rated equipment: A 250VAC appropriately rated circuit breaker must be installed.
- Page 24 Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 CAUTION • A circuit breaker is not required for DC power supply voltages of 18- 48VDC. • For Dual DC power supplies, separate circuit breakers must be installed and separately identified. •...
-
Page 25: Poe Ports
Depending on your hardware variant POE ports might be applicable. Hardware supporting POE is named: • iS5-iSG18GFP-<P>-<T>/<E>/8PE30/<R>/<C> - hardware includes 8 POE support on the FE Ethernet ports 1-8. All POE ports are wired as Alternative-A (PoE runs on the FE twisted pairs) •... - Page 26 Power Management of POE 1. The 8 POE ports supports in total maximum power output of: a. For 12Vdc powered units (iS5-iSG18GFP-24../PE) : 60w b. For 24Vdc powered units (iS5-iSG18GFP-24../PE) : 80w c. For 48Vdc powered units (is5-iSG18GFP-48../PE) : 120w d.
-
Page 27: The Switch Led Indicators
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 The Switch Led indicators Interface status meaning No power Green Power on Port administratively Eth 1-8 Disable link Link led Green connected to it Enable and link up Port administratively Disable link... -
Page 28: Switch Configuration
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Switch Configuration Connecting to the Console Port Connecting the device to a PC using the Console Port: Connect the RJ-45 connector of the console cable to the device's Console Port (CON). The console cable is colored white and is supplied with the device. -
Page 29: Using The Command Line Interface (Cli)
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Using the Command Line Interface (CLI) The CLI is a network management application operated through an ASCII terminal. Using the CLI commands, users can configure the device parameters and maintain them, receiving text output on the terminal monitor. These system... -
Page 30: Committing Configuration Commands
These commands are applied to a copy of the active configuration. The configuration made by the user can be saved in the Flash and can be restored when the switch is started. iSG18GFP# write startup-cfg iS5 Communications Inc. Page: 30 of 33... -
Page 31: Using The Cli
In this format represents the prompt displayed by the device. This iSG18GFP[(config ...)]# prompt includes: • the user-defined iSG18GFP • the current CLI mode • the command keywords and arguments typed by the user Minimum Abbreviation The CLI accepts a minimum number of characters that uniquely identify a command;... -
Page 32: Default Ip Address
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 Getting Help To get specific help on a command mode, keyword, or argument, use one of the following commands or characters: Command Purpose help Provides a brief description of the help system in any command mode. -
Page 33: Setting Static Route As Default Gateway
Installation Guide iSG18GFP R3.5 Ver: 1.2 Date: 22.03.2016 write startup-cfg iSG18GFP# show ip interface Setting static route as default gateway 1. Create static route (default gateway to your next hop aa.bb.cc.dd) Config ip route 0.0.0.0 0.0.0.0 aa.bb.cc.dd Activating telnet Config...
