ROTARY CONTROL

Please connect the Watch Winder to the mains using the sup-
plied AC adapter or, if the model is suitable, insert the intended
batteries (see page 2 for the type of battery). Equip one or more
winding modules with a watch (see Figure I-IV).
By the simple operation via classic knobs, the following preset
programs can be activated quickly by selecting the program po-
sitions.
1. Please first find out how many revolutions per day (TPD) and
which direction of rotation your watches need. If you do not know
this, contact the watch manufacturer or select the standard pro-
gram 900 TPD, automatic bidirectional
INTERVAL TABLE
TPD
(TURNS
PER DAY)
POSITION 2: 900
POSITION 3: 900
POSITION 4: 1700
POSITION 5: 900
3
rotation (position 5).
DIRECTIONS
IN SECONDS
RIGHT LEFT INTERVAL
265 3335
265 3335
2. Please select the desired program with the rotary control (po-
sition 2-5) switch off the device by selecting the 1. position. With
devices for several watches, a knob is available for each motor.
To prevent the engine from damaging, stop the program while
changing the watch.

PROGRAM SELECTION

Position 1: Off
Position 2: 900 TPD, clockwise
Position 3: 900 TPD, counterclockwise
Position 4: 1700 TPD, automatic bidirectional
Position 5: 900 TPD, automatic bidirectional
CHANGING DIRECTIONS
IN SECONDS
RIGHT INTERVAL
250 1550
398 1402
LEFT INTERVAL
250 1550
398 1402
