T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPTION AND MAIN APPLICATIONS
For this machine, the cutting length capacity for the 5011NB
is enlarged by 60 mm and the power-increased motor has
upgraded the chain speed by about 50% to get more working
efficiency.
While the 5011NB is aimed for use in the home application,
this machine is developed for the professional users.
S
pecifications
Voltage(V)
Single-phase 100V
Chain speed(m/mm)
Cutting length(mm)
Weight(kg)
Overall length(mm)
Cord length(m)
S
tandard equipment
Parts name
Oil vessel
- Screw driver 6
Box wrench 9
File
The standard equipment for the tools shown may differ from country to country.
5014B
MAKITA 335mm(13-1/8") Chain saw
Current(A)
14
Quantity
1
For filling oil
1
For adjusting the chain blade tension
1
For fastening the chain cover
1
For grinding the chain blade
Frequency(Hz)
50-60
400
335
5.6
680
5
Applications
External view
Consumed power(W)
1300
New Tool
