- Page 1 Service Documentation Market Release 11/97 Braun flex integral 6550 ultra speed 5704 5704...
- Page 2 Service Documentation BINC Rev: 11/97 Exploded Drawing 5704 BAG Rev: 8/97 5704 - 2...
- Page 3 Service Documentation BINC Rev: 11/97 Spare Parts List 5704 BAG Rev: 8/97 Pos. No. Part Description Part Number Protective cap 5503074 Shaving foil frame 5505765 Cutter block 5504766 Swivel frame 5504630 Sealing plate 5503014 Bearing screw 5504046 Screw 5504099 Head carrier 5504631 Lower frame 5505032...
-
Page 4: Service Documentation
Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Description of shaver Principle Battery power supply with eco-friendly nickel-hydride batteries. Oscillating head with triple shaving system. Long hair trimmer can be additionally switched on. Charging and battery display. Housing Plastic material, chromium-plated. - Page 5 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Maintenance of the The device is provided with automatic battery maintenance, battery i.e. it discharges automatically once a year in order to regain the full battery capacity. This process takes approx. 7 hours.
- Page 6 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Dismantling The dismantling procedure is described in a logical order. For individual repairs, the order of the description can be altered. • Shaving foil frame (2) - to be unlocked by pushing button "A"; - to be removed.
- Page 7 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Reassembly The reassembly has to be performed in reversed order. However, attention has to be paid to the following points: Sliding plate (21) - Before inserting the sliding plate (21) please ensure that the transmission lever (25) and leg spring (24) are assembled correctly.
- Page 8 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 - With your thumb, position switch "G" of the sliding plate (21) as shown in dia. (extension "H"). At the same time, with your middle finger, secure the transmission lever (25) on the backside of the sliding plate to prevent unhinging or slipping away (see dia.
- Page 9 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 • Attention! Do not check the function of the long hair trimmer after inser- ting the sliding plate otherwise the transmission lever will unhinge and the sliding plate will have to be attached again! •...
- Page 10 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Before starting selftest: after approx. 0.25 sec after approx. 0.5 sec after approx. 0.5 sec after approx. 0.5 sec red and green LED illuminated This is a 5 as version control The red LED illuminates only, when pad 9 No display, provided that the mains power and motor are still switched on.
- Page 11 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Lubricating Schedule When exchanging the sliding plate (21), some Vaseline has to be applied to the slip planes and levers marked on the lower side. 5704 - 11...
- Page 12 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Possible Malfunctions Malfunction Possible Cause Action Bad shaving quality. - Resonating shaving foil - Exchange shaving foil frame. frame. - Jammed cutting heads. - Exchange cutting heads. - Loose foils. - Exchange shaving foil frame.
- Page 13 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Cutting head does - Bearing axis 2 is too rough. - Exchange cutting heads. not snap in. - Not orderly snapped in after - Instruct customer. (Attach cleaning 90°) Hair dust is falling - Dust catcher is overloaded.
- Page 14 Service Documentation BINC Rev: 11/97 Service Information 5704 BAG Rev: 8/97 Display Super AT Jumping display. - Motor current too high. - Exchange swivel frame, shaving foil frame, cutting head and motor. - Damaged motor contacts. - Exchange motor, clean and grease contacts on PCB - Not completely charged.
