S
IDE-GUARD Stylus Protection System
The
SIDE-GUARD
Figure 6, helps prevent stylus damage if the cartridge
accidentally slides across a record.
The
SIDE-GUARD
side thrusts on the stylus by withdrawing the entire
stylus cantilever and tip safely into the stylus housing
before the cantilever can be damaged.

Specifications

Frequency Response:
Channel Balance:
Channel Separation:
Trackability at 1 gram (10 mN ) Tracking Force (typi-
cal values shown in cm/sec peak velocity):
400 Hz:
1 kHz:
5 kHz:
10 kHz:
Tracking Force:
Optimum
Maximum 1.25 g (12.5 mN)
Output Voltage (typical):
3 mV RMS at 1 kHz at 5 cm/sec peak velocity
Recommended Load:
Resistance (typical):
Inductance (typical):
Cartridge Weight:
Replacement Stylus: VN5xMR, nude Micro-Ridge tip
3.8 x 75 µ (.00015 x .003 in.), burgundy-colored grip
Certification: Conforms to European Union directives,
eligible to bear CE marking; meets European Union
EMC Immunity Requirements: EN 50 082-1, 1992 [ESD
(IEC 801-2)]
stylus protection system, shown in
stylus protection system responds to
Force at the
stylus tip
1.0 g (10 mN)
47 kΩ in parallel with 250 pF
5
10 to 25,000 Hz
Within 1.5 dB
1 kHz - 25 dB or greater
10 kHz -18 dB or greater
Total Tone Arm Force
setting with Dynamic Sta-
bilizer operating
1.5 g (15 mN )
1.75 g (17.5 mN)
425 mH at 1 kHz
30 cm/sec
46 cm/sec
80 cm/sec
60 cm/sec
1000 Ω dc
6.6 grams
