Technical Data

The Digital to Analog Audio Converter, DTC-1D, supports optical digital audio signal

input and conversion into analog audio signal L/R output:

• Supports digital LPCM stereo or Dolby Digital 5.1CH audio inputs

• Supports LPCM 2CH audio sampling rates from 32 to 96 kHz (32, 44.1, 48, 88.2 and

96 kHz)

• Supports Dolby Digital 5.1CH audio sampling rates of 48 kHz

• Supports Dolby Digital audio downmixing to 2-channel audio

• Supports S/PDIF bit stream 24-bit of data for the left and right channels

Note: It may be necessary to configure the TV so that the proper audio output is

available at the optical output.

2017-07. 9 502 4594 001 #01

Widex and DEX are trademarks of Widex A/S.

Widex A/S, Nymoellevej 6, DK-3540 Lynge

WWW.WIDEX.COM

HOW TO CONNECT

WIDEX TV-DEX TO A TV

WITH DIGITAL AUDIO OUTPUT

Do you have a question about the TV-DEX and is the answer not in the manual?

Page 1: How To Connect
Note: It may be necessary to configure the TV so that the proper audio output is available at the optical output. HOW TO CONNECT WIDEX TV-DEX TO A TV WITH DIGITAL AUDIO OUTPUT 2017-07. 9 502 4594 001 #01 Widex and DEX are trademarks of Widex A/S. Widex A/S, Nymoellevej 6, DK-3540 Lynge WWW.WIDEX.COM...
Page 2 HOW TO CONNECT WIDEX TV-DEX TO A TV WITH DIGITAL AUDIO OUTPUT Some TVs only have a Digital Audio Output and cannot connect directly to a Widex TV- Connecting the Digital to Analog Audio Converter to the TV DEX. In this case a Digital to Analog Converter has to be connected between the TV and 1.
