- Page 33 SECTION 6 DIAGRAMS 6-2. CIRCUIT BOARDS LOCATION 6-3. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS Note: Reference information • All capacitors are in µF unless otherwise noted. RESISTOR : RN METAL FILM • All electrolytic capacitors are rated at 50V unless otherwise noted. : RC SOLID •...
- Page 34 TUNER, IF, Y/C, JUNGLE, SECAM DECODER, H/V OUT, MEMORY, SYSTEM CONTROLER, AUDIO/VIDEO IN/OUT, POWER SUPPLY A BOARD WAVEFORMS A BOARD IC300 TDA8375A DIODE IC001 D-11 D001 IC002 E-10 D002 C-12 IC003 E-10 D003 C-10 IC004 I-13 D005 IC100 D008 H-13 IC203 B-10 D103...
- Page 35 J1201 J1202 A BOARD＊MARK LIST CN103 CN101 KV-G14L2J KV-G21M2J KV-G14L2J KV-G21M2J :S-MICRO J251 CN251 :S-MICRO C003 100p 50V : CHIP Q412 2SD601A TO C BOARD CN703 C012 100p 50V : CHIP Q413 UN2216-TX 3 54 JW099 C032 0.01 50V F : CHIP Q415 UN2216-TX 15MM...
- Page 36 [RGB OUT] (2) Schematic Diagram of C Board CAT24C04P PC123F2 TA8248K CXP85220A-060S TDA4665DT-T TDA8374A TDA8395 C BOARD＊MARK LIST KV-G20M2J KV-G14L2J CN704 KV-G21M2 KV-G21Q2 A34JBU70X C702 RV701 L701 R702 1000V R701 2.2M 680k 22µH C714 560p 560p :MINI 1/2W :EL0607 1000V 21"...
