Multiplex MULTImate Instructions Manual page 36

6. M 5: RX R
ENU UN
This menu point is used when you wish to set a MULTIPLEX RX-SYNTH IPD receiver to a new frequency channel
using the MULTImate, but the SET button is not accessible.
In the case of M-PCM receivers it is also possible to read out the error memory, and measure the field strength, when
the system is operating.
• Connect the receiver (socket "B/D") to the PC and Data port on one end of the MULTImate using the data lead
supplied in the set.
• Switch the transmitter on; RF transmission must be active.
Action & Display
5 RX run
5-1 IPD Chan.src
5-2 IPD Button
5-3 M-PCM Errors
5-4 M-PCM RF-Pow
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten (Gölshausen) • www.multiplex-rc.de
Operating Instructions - MULTImate – V1.42
5 Go back
...to main menu
Explanation
Main menu display „5 RX Run"
If the receiver is powered by a separate receiver power
supply (battery):
Disconnect the battery, or switch it off!
Sequence
• The screen backlight of the MULTImate starts to
flicker (search)
• If the screen backlight of the MULTImate lights up
constantly, move the transmitter stick four times
( see receiver operating instructions).
The screen backlight of the MULTImate will switch on
and off in time with the stick movements.
• Once the channel has been set successfully, the
MULTImate confirms this with a constantly repeating
flashing pattern: "on / off / on / off – pause"
Note: the set channel is accepted when you leave the
menu.
Displaying the receiver's error memory:
activates the display
Typical display: RF:0 U:0 S:63
Displaying the field strength of the aerial signal:
activates the display: display value range 0 ... 100 %
Seite 13/22
