Introducing the CyberSerial Dual PCIe
The CyberSerial Dual PCIe high-speed serial I/O card
provides two additional 9-pin serial ports.
Features and Benefits
•
Compliant with PCI Express Base Specification 1.1a
•
PCI Express 1-lane (x1) serial I/O card works with
PCI Express slots with different lane width
•
Installs into any available PCI Express slot and
provides two 9-pin RS232 serial ports
•
128-byte FIFO buffers dramatically increase data
transmit/receive speed
•
Works as standard RS232 port or with 5V or 12V
power output for devices that require power
System Requirements
•
PCI Express-enabled system with an available PCI
Express slot
•
Windows
/64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32-
/64-bit) / Server 2008 R2 / 2000
Package Contents
•
CyberSerial Dual PCIe adapter
•
2 spare low profile brackets
CyberSerial Dual PCIe
Quick Installation Guide
8 (32-/64-bit) / 7 (32-/64-bit) / Vista (32-
®
1
Advertisement
Table of Contents
Related Manuals for AvLab CyberSerial Dual PCIe
Summary of Contents for AvLab CyberSerial Dual PCIe
- Page 1 CyberSerial Dual PCIe Quick Installation Guide Introducing the CyberSerial Dual PCIe The CyberSerial Dual PCIe high-speed serial I/O card provides two additional 9-pin serial ports. Features and Benefits • Compliant with PCI Express Base Specification 1.1a • PCI Express 1-lane (x1) serial I/O card works with PCI Express slots with different lane width •...
- Page 2 • Y split power cable & power output jumpers • Driver CD • Quick installation guide Layout Serial port 2 Power connector* Pin 1 Serial port 1 Figure 1: Layout *Note: If the serial port requires power output, connect the system power source to board's power connector.
- Page 3 Figure2: Low profile brackets installed Hardware Installation For low profile systems, replace the currently mounted bracket with the 2 spare low profile brackets now. See Figure 2 above. General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed.
- Page 4 Replace the computer cover and reconnect the power cord. Driver Installation This section provides information on how to install the CyberSerial Dual PCIe drivers. Windows 8 (32-/64-bit) / 7 (32-/64-bit) / Server 2008 R2 Right click Computer, click Manage, click Device Manager.
- Page 5 Under Other Devices, starting at the top, right click 16C95X Serial Port, then click Update Driver Software. Click Browse my computer for driver software. Type D:, click Next. (Change D: to match your CD/ DVD-ROM drive letter) At Windows has successfully updated your driver software, click Close.
- Page 6 Select Install from a list or specific location (Advanced), then click Next. Insert the driver CD, check Include this location in the search, uncheck the other box. Click Cancel at the AutoPlay box if prompted. For 32-bit: Type D:\XP-Later\32-bit, and click Next, then click Finish.
- Page 7 Windows 2000 At the Found New Hardware Wizard, click Next. Select Search for a suitable driver for my device (recommended), and click Next. Check Specify a location, uncheck the other boxes, then click Next. Insert the driver CD, type D:\2K, then click OK. (Change D: to match your CD/DVD-ROM drive letter) Click Next and Finish.
- Page 8 Changing COM Port Number Some serial devices need a specific COM port in order to work. If your serial device works properly, do not change this setting. From the Device Manager window double click Ports (COM & LPT), then double click the CyberSerial PCI serial port you want to change.
