Page 7: Introduction
BEETLE /iSCAN EASY User Manual Introduction The BEETLE /iSCAN EASY is a terminal that offers a customer to handle the purchase by scanning, bagging and paying the items on his own. In case of problems an attendant is available for quick support.
Page 8: Important Notes
After maintenance and repair work on the cash module the module must be completely pushed into the BEETLE /iSCAN EASY and the front door must be closed before switching on the device.  Keep this manual safe and at hand for ready reference.
Page 9  BEETLE /iSCAN EASY is the result of state-of-the-art technology. Therefore, please also ensure that the BEETLE /iSCAN EASY is operated under modern building and technical conditions in order to ensure flawless and efficient operation. The appliance and other information technology hardware should only be connected to electrical supply networks with a separate protective earth wire (PE).
Page 10: Note On Laser
BEETLE /iSCAN EASY User Manual Note on Laser The barcode readers contain a light-emitting diode (LED), classified according to LASER CLASS 3R: CAUTION – CLASS 3R LASER RADIATION WHEN OPEN. AVOID DIRECT EYE EXPOSURE. ESD (Electrostatic Sensitive Devices) Electrostatic sensitive devices (ESD) may be marked with this sticker.
Page 11: Warranty
BEETLE /iSCAN EASY User Manual Warranty Diebold Nixdorf generally guarantees a warranty engagement for 12 months beginning with the date of delivery. This warranty engagement covers all damages which occur despite a normal use of the product. Damages because of ...
Page 12: Connecting The System
Power Connection and LAN Support The BEETLE /iSCAN EASY supports Ethernet 10/100 BASE-T local area network (LAN) communication protocol. The BEETLE /iSCAN EASY terminal provides a female RJ-45 connection port for the LAN. A 6-foot LAN cable is provided with the system.
Page 13 BEETLE /iSCAN EASY User Manual Plug in the power und the LAN cable. Unlock and open the front door of the BEETLE /iSCAN EASY.
Page 14: Disconnecting The System From The Mains
BEETLE /iSCAN EASY User Manual Pull out the cash module at the left side. Check if all power plugs are well installed in the power distributor. Start up the system by pressing the button to position 1 (see arrow). Disconnecting the System from the Mains ...
Page 15: Components
BEETLE /iSCAN EASY User Manual Components BEETLE /iSCAN EASY with Cash Components...
Page 16: Beetle /Iscan Easy Without Cash Components
BEETLE /iSCAN EASY User Manual BEETLE /iSCAN EASY without Cash Components...
Page 17: Opening The Beetle /Iscan Easy
BEETLE /iSCAN EASY User Manual Opening the BEETLE /iSCAN EASY Unlock and open the front door of the BEETLE /iSCAN EASY.
Page 18: Cash Module Icash 10
10 also has a collection cassette with a maximum capacity of 450 banknotes. The collection cassette accommodates those banknotes which cannot be deposited in a drum module. Switch off the device. Unlock the BEETLE /iSCAN EASY and open the front door. Grasp the iCASH 10 and pull it out completely.
Page 19: Overall View
BEETLE /iSCAN EASY User Manual Overall view Upper cover Gripping edge of front door Operator display Handle Banknote input Transport path cover Banknote removal area Lock of transport path cover Front door...
Page 20: Front Door Open
BEETLE /iSCAN EASY User Manual Front door open Collection cassette cover Lock of drum module cover Lock of collection cassette cover Power switch Drum module cover...
Page 21: Rear View
BEETLE /iSCAN EASY User Manual Rear view 1 Vents Power supply 2 Handle Fuses 3 Drum module cover Data communication connector 4 Lock of drum module cover...
Page 22: Drum Module Cover Open
BEETLE /iSCAN EASY User Manual Drum module cover open Drum module no. 1 Drum module no. 2 Basic Operation Switch the device off before you work at the drum modules or the transport paths. Switching the device on / off...
Page 23: Removing / Mounting The Transport Path Cover
BEETLE /iSCAN EASY User Manual Removing / mounting the transport path cover The key for the transport path cover is marked yellow (1). Removing it: Insert the key into the lock (1) of the transport path cover and turn it to the right as far as possible.
Page 24: Removing / Inserting The Collection Cassette
BEETLE /iSCAN EASY User Manual Removing / inserting the collection cassette Removing it: The key for the collection cassette cover is marked blue (1). Insert the key into the lock (1) of the collection cassette cover and turn it to the right as far as possible.
Page 25: Inserting It
BEETLE /iSCAN EASY User Manual Inserting it Open the front door (see section "Opening / closing the front door"). The key for the collection cassette cover is marked blue (1). Insert the key into the lock (1) of the collection cassette cover and turn it to the right as far as possible.
Page 26: Opening / Closing The Drum Module Cover
BEETLE /iSCAN EASY User Manual Opening / closing the drum module cover The key for the drum module cover is marked red (1). Front drum module Open the front door (see section "Opening / closing the front door"). Opening it:...
Page 27: Putting Drum Modules In Service Position
BEETLE /iSCAN EASY User Manual Putting drum modules in service position Switch the device off at the power switch before you work at the drum module (see section "Switching the device on / off"). Front drum module Open the front door (see section "Opening / closing the front door") and remove the panel covering the transport path (see section "Removing / mounting the transport path cover").
Page 28: Pushing It In
BEETLE /iSCAN EASY User Manual Pushing it in Push the drum module (1) in the direction of the arrow in the device as far as possible. When pushing it in make sure that your hand or fingers are not between the drum module (1) and the mount (2).
Page 29 BEETLE /iSCAN EASY User Manual Insert the key into the lock (1) of the rear drum module cover and turn it to the right as far as possible. Swing the cover (2) of the drum module open as far as possible.
Page 30: Deposit
BEETLE /iSCAN EASY User Manual When pushing it in make sure that your hand or fingers are not between the drum module (1) and the mount (2). Danger of injury! Push the drum module (1) in the device as far as possible, lock the drum module and transport path covers.
Page 31 BEETLE /iSCAN EASY User Manual ... that they touch the side panel on the right side (4) and that their front edges are right on top of each other (5). You should also read the recommendations in the section "Rules for the quality of deposited banknotes".
Page 32: Rejected Banknotes
BEETLE /iSCAN EASY User Manual Rejected banknotes Notes that show irregularities during feed and notes that are not recognized (potential forgeries) are routed to the reject/cash output tray (1) without the deposit process being interrupted. From there the banknotes can be retrieved.
Page 33: Dispensing
BEETLE /iSCAN EASY User Manual Dispensing Banknotes totaling the required amount are stored in the reject / output tray (1). The notes must be removed from the reject / output tray, since the next dispensing process can only be performed if the tray is empty.
Page 34: Cash Paths
BEETLE /iSCAN EASY User Manual Cash Paths Overview Deposit process Banknotes are transported from the cash input tray through the banknote validator. If they are found to be genuine, their are either stored on a drum module (1) or in the collection cassette (2) or they can be dispensed again upon customer request (3).
Page 35: Dispensing Process
BEETLE /iSCAN EASY User Manual Notes that show irregularities during transport and banknotes that are not recognized (potential counterfeits) are routed to the reject / cash output tray (1). Dispensing process Banknotes are transported from the drum module to the reject/cash output tray (1).
Page 36: Emptying The Drum Modules
BEETLE /iSCAN EASY User Manual Emptying the drum modules Banknotes that are suspected of being double or multiple dispenses are transported to the collection cassette (1). The drum modules can also be emptied into the collection cassette (1) via the device application.
Page 37: Function Elements And Controls
BEETLE /iSCAN EASY User Manual Function elements and controls Collection cassette closed 1 Collection cassette Safety precautions 2 Lock of collection cassette removal area Note input 3 Flap in front of banknote...
Page 38: Collection Cassette Open
BEETLE /iSCAN EASY User Manual Collection cassette open Flap in front of banknote removal area 3 Banknote rest Collecting compartment Handling the collection cassette Opening the collection cassette Remove the collection cassette from the device (see chapter "Basic Operation", section "Removing / inserting the collection cassette").
Page 39 BEETLE /iSCAN EASY User Manual Put the key for the cassette in the cassette lock (1) > and turn it to the right as far as possible. Swing the flap in front of the banknote removal area down by the gripping edge (1).
Page 40 BEETLE /iSCAN EASY User Manual Then turn the key (1) to the left as far as possible and pull it from the cassette lock. Insert the collection cassette in the device (see chapter "Basic Operation", section "Removing / inserting the collection cassette").
Page 41: Malfunctions
BEETLE /iSCAN EASY User Manual Malfunctions General Indication of errors Any malfunctions are signaled to the application by the controller and displayed on the operator display (1). The following errors may occur:  Missing banknotes  Cash-in errors  Errors in the cash paths ...
Page 42: Troubleshooting
BEETLE /iSCAN EASY User Manual Troubleshooting Jammed banknotes must not be removed from the transport paths, but must be transported to one of the marked removal points (4) to (12) using the green transport wheels (1) to (3). Here they can be removed (see following sections).
Page 43 BEETLE /iSCAN EASY User Manual Jam in the input unit Open the transport path cover (see chapter "Basic Operation", section "Removing / mounting the transport path cover"). Swing the cover (1) up in the direction of the arrow. Turn the green handwheel (1) to the left or to the...
Page 44 BEETLE /iSCAN EASY User Manual Jam in the banknote reader Clear any banknote jam in the input unit (see section "Jam in the input unit"). The bent lever closures (1) and (2) are opened in the same way. Therefore, how to open them is described only for the bent-lever closure (2) as an example.
Page 45: Jam In The Rear Transport Unit
BEETLE /iSCAN EASY User Manual Jam in the rear transport unit Clear any banknote jam in the banknote reader (see section "Jam in the banknote reader"). To reach the banknotes more easily you can turn the green handwheel (1) in the direction of the arrow.
Page 46 BEETLE /iSCAN EASY User Manual Jam in the lower transport unit Clear any banknote jam in the rear transport unit (see section "Jam in the rear transport unit"). To reach the banknotes more easily you can turn the green handwheels (1) and (2). This will transport any jammed notes in the lower transport unit.
Page 47: Jam In The Drum Module
BEETLE /iSCAN EASY User Manual Jam in the drum module Clear any banknote jam in the collection cassette (see section "Jam in the collection cassette"). Banknote jams in the three drum modules are cleared in the same way. Therefore, how to clear a banknote jam is described for front drum module as an example.
Page 48: Jam In The Reject Unit
BEETLE /iSCAN EASY User Manual Push the service key (1) in the hole and turn it in the directions indicated by the arrow. This will cause jammed banknotes to be transported in the drum module or it lets you transport jammed banknotes out of the drum module to be removed.
Page 49 BEETLE /iSCAN EASY User Manual ... to transport them in the output tray (3) to be removed from there in the direction indicated by the arrow. Close the transport path cover (see chapter "Basic Operation", section "Removing / mounting the transport path cover").
Page 50: Other Problems
BEETLE /iSCAN EASY User Manual Other problems Error indications are made up of the error code and the process code. The error code provides information on what kind of an error and where it has occurred. The process codes indicates during which process the error has occurred.
Page 51 BEETLE /iSCAN EASY User Manual Error Section / error Cause and remedy code 3601 CPU board Connector on the CPU board is not properly attached. Notify Service. 3621- Power supply error Error in internal power supply error 3626 Notify Service.
Page 52 BEETLE /iSCAN EASY User Manual Error Section / error Cause and remedy code If the problem persists, notify Service. Ex12 Ex12 Ex12 Ex20 Engine error Motor rotation speed error Ex20 Switch the device off and on. Ex20 If the problem persists, notify Service.
Page 53 BEETLE /iSCAN EASY User Manual Ex90 Sensor error Switch the device off and on. Ex90 If the problem persists, notify Service. Ex90 ExA0 Drum module error Switch the device off and on. ExA0 If the problem persists, notify Service. ExA0...
Page 54: Cleaning, Service And Maintenance
BEETLE /iSCAN EASY User Manual Cleaning, Service and Maintenance The device must be switched off for service and maintenance work (see chapter "Basic Operation"). You should service and clean the parts of the device listed below at the specified intervals.
Page 55: Cleaning The Transport Paths
BEETLE /iSCAN EASY User Manual Cleaning the transport paths Any scraps of paper and dirt may cause banknote jams in the transport paths. If the transport paths are very dirty, clean them with high-pressure gas. Cleaning interval: as needed Cleaning material:...
Page 56: Coin Module Icash 15E
BEETLE /iSCAN EASY User Manual Coin Module iCASH 15E Switch off the device. Unlock the BEETLE /iSCAN EASY and open the front door. Grasp the iCASH 15E at the green lever… … and pull it out completely. Find all other relevant information in the User Manual iCASH15E on the Diebold...
Page 57: Cash Module Icash 20
BEETLE /iSCAN EASY User Manual Cash Module iCASH 20 Unlock and open the front door. Grasp the iCASH 20 (see white arrow) and pull it out completely. Text and graphics on the following pages 50-66 © 2009-2013 MEI. All rights reserved.
Page 58: Components
BEETLE /iSCAN EASY User Manual Components Front View Main Module Cash Box Chassis Loader Cassette Recycler 3 & 4 Recycler 5 & 6...
Page 59: Back View
BEETLE /iSCAN EASY User Manual Back View Positioner Door Recognition Sensor Door Spine USB Cable Power Cable...
Page 60: Main Module External Indicators
BEETLE /iSCAN EASY User Manual Main Module external Indicators External indicators are located on the Bezel. External indicators consist of two pairs of illuminated arrows, one pair pointing to the Inlet, the other pair pointing to the Outlet. Inlet arrows can be illuminated green or red. Outlet arrows can be illuminated green only.
Page 61: Modules Front Indicators
BEETLE /iSCAN EASY User Manual Modules Front Indicators Each iCASH 20 module has front located LED indicators giving its status. Each LED will illuminate green or red depending on the module status.
Page 62: Spine Indicator
BEETLE /iSCAN EASY User Manual Spine Indicator The Spine has a LED indicator that provides its status. This indicator will illuminate green or red.
Page 63: Locks And Security Principle
BEETLE /iSCAN EASY User Manual Locks and Security Principle The iCASH 20 can be secured with several locks to prevent unauthorised access to the stored money: Interlock System A lock and a lever which secures all cash modules. The picture shows the Interlock System correctly locked.
Page 64 BEETLE /iSCAN EASY User Manual Loader Cassette You need to release the Interlock System to remove the Loader Cassette. To open the Loader Cassette it must be removed and the module must be unlocked with a key. The key is required to open and close...
Page 65: Cash Box Handling And Arming
BEETLE /iSCAN EASY User Manual Cash Box Handling and Arming To remove the Cash-Box, you need to release the Interlock System with its key. To open and rearm the Cash-Box, you need the key of the Cash-Box. Warning, the Cash-Box is a module which needs to be rearmed once removed.
Page 66 BEETLE /iSCAN EASY User Manual Warning, the Cash-Box is a module which needs to be rearmed once removed. Make sure that you have the key or another empty Cash-Box before removing it. If you do not have the key, you will not be able to replace the same Cash-Box.
Page 67: Loader Cassette Handling, Using And Quality Banknote
BEETLE /iSCAN EASY User Manual Loader Cassette Handling, using and Quality Banknote The following instructions explain how to fill the Loader Cassette with banknotes. Banknotes that are placed in the Loader Cassette must meet the banknote criteria detailed in Table 1.
Page 68 BEETLE /iSCAN EASY User Manual Fully open the door until it stops. Release the little yellow latch and lift the “max level detection plate”. Push the pressure plate down to the stop. The pressure plate will lock at the bottom of the Loader Cassette.
Page 69 BEETLE /iSCAN EASY User Manual Lift (1) and flip (2) the lateral bill guide flap down. Ensure notes to be used in the loader meet all requirements of fitness in Table 1, then place a bundle of less than 250 banknotes into the loader.
Page 70 BEETLE /iSCAN EASY User Manual Reposition the “max level detection plate”. With the max level detection plate down, check that the bill level flag is green. If the flag shows red remove some banknotes until the flag turns green with the detection plate down.
Page 71 BEETLE /iSCAN EASY User Manual Capacity and banknote quality for the Loader Cassette Maximum number of banknotes 250 +/- 50 notes Varies depending on the currency, the state of the banknotes and the climatic conditions. Banknote width acceptance Min. 60 mm to max. 81 mm (nominal) (+1 / -2 mm) Banknote length acceptance Min.
Page 72: Jam Clearing
BEETLE /iSCAN EASY User Manual Jam Clearing It may happen that a banknote is jammed in the iCASH 20. The following cases of jammed banknotes are easy to clear. In the Spine Unlock and open the front door. Pull out the iCASH 20 completely. Open the spine door. Lift and hold up the yellow button and pull the door open.
Page 73: In The Recognition Sensor
BEETLE /iSCAN EASY User Manual In the Recognition Sensor Unlock and open the front door. Pull out the iCASH 20 completely. Push on the yellow buttons… …and open the recognition sensor door. Withdraw the banknote and close the sensor again.
Page 74: In The Recognition Sensor To Spine Interface
BEETLE /iSCAN EASY User Manual In the Recognition Sensor to Spine Interface Unlock and open the front door. Pull out the iCASH 20 completely. Open the spine door (see page XX) and the recognition sensor door (see page before). Remove the banknote carefully.
Page 75: In The Positioner, At The Inlet
BEETLE /iSCAN EASY User Manual In the Positioner, at the Inlet Unlock and open the front door. Pull out the iCASH 20 completely. Open the spine door (see page XX), then open the recognition sensor and finally open the positioner door.
Page 76: Coin Module Cineo C1010
Coin Module CINEO C1010 Unlock and open the front door. Grasp the CINEO C1010 on the green lever (see white arrow) and pull it out cmpletely. Find all relevant information in the User Manual CINEO C1010 on the Diebold Nixdorf Internet.
Page 77: Cash Module Cineo C6010
BEETLE /iSCAN EASY User Manual Cash Module Cineo C6010 Unlock and open the front door. Unlock the Cineo C6010 (see arrow) and pull it it out completely. Maintenance work can now be carried out.
Page 78: Head Unit
BEETLE /iSCAN EASY User Manual Head Unit Components 1 Head transport module A 5 Head transport module C3 2 Head transport module B 6 Cash input module with shutter 3 Head transport module C 7 Cash input/output module 4 Head transport module C5 The operation of the head unit is described on the following pages.
Page 79: Opening/Closing The Cash Input Module
BEETLE /iSCAN EASY User Manual Closing it Lower the head transport module A in the direction of the arrow (1) until it locks into position. Push the head unit into the head (see chapter "Basic Operation"). Opening/closing the cash input module Pull the head unit out of the head (see chapter "Basic Operation").
Page 80: Opening/Closing The Head Transport Module B
BEETLE /iSCAN EASY User Manual Opening/closing the head transport module B Open the head transport module A (see section "Opening/closing the head transport module A"). Open the cash input module (see section "Opening/closing the cash input module"). Opening it Push the green lever in the direction indicated by the arrow (1).
Page 81: Opening/Closing The Head Transport Module C3
BEETLE /iSCAN EASY User Manual Opening/closing the head transport module C3 Open the head transport module A (see section "Opening/closing the head transport module A"). Open the cash input module (see section "Opening/closing the cash input module"). Open the head transport module B (see section "Opening/closing the head transport module B").
Page 82: Troubleshooting
BEETLE /iSCAN EASY User Manual Troubleshooting Clearing a banknote jam in the cash input module Open the cash input module (see section "Opening/closing the cash input module"). To open the shutter, turn the green gearwheel (1) in the direction of the arrow.
Page 83: Clearing A Banknote Jam In The Head Transport Module A
BEETLE /iSCAN EASY User Manual Clearing a banknote jam in the head transport module A Open the head transport module A (see section "Opening/closing the head transport module A"). Open the cash input module (see section "Opening/closing the cash input module").
Page 84: Clearing A Banknote Jam In The Head Transport Module C3
BEETLE /iSCAN EASY User Manual Clearing a banknote jam in the head transport module C3 Open the head transport module C3 (see section "Opening/closing the head transport module C3"). Remove the banknotes from the head transport module C3 in the direction shown by the arrow (1).
Page 85 BEETLE /iSCAN EASY User Manual Alternatively, you may turn the green gearwheel in the direction of the arrow (1) to remove the banknotes in the direction of the arrow (2) (see illustration below). Close the head transport module C3.
Page 86: Clearing A Banknote Jam In The Head Transport Module C5
BEETLE /iSCAN EASY User Manual Clearing a banknote jam in the head transport module C5 Open the head transport module C5 (see section "Opening/closing the head transport module C5"). Remove the banknotes from the head transport module C5 in the direction shown by the arrow (1).
Page 87 Alternatively, you may turn the green gearwheel in the direction of the arrow (1) to remove the banknotes in the direction of the arrow (2) (see illustration below). Close the head transport module C5. Find all relevant information in the User Manual C6010 on the Diebold Nixdorf Internet.
Page 88: Printer Th230
BEETLE /iSCAN EASY User Manual Printer TH230+ Operator Panel Paper Output Printer Cover Safety Instructions Do not touch the cutter and tear bar of the printer. The print head is a thermal element and it is at high temperature during printing or just after operation, therefore please do not touch it and its peripherals for safety reasons.
Page 89: Operator Panel
BEETLE /iSCAN EASY User Manual Operator Panel 1 - OPEN Press this button to unlock and open the cover. Thereby, the switch sheet flaps into an upright cover position. Switch Sheet If an error occured do not open the cover with force.
Page 90: Red Error Led
Printer in idle mode ) The printer will run with the lowest power value (48W) if a non current power supply unit from Diebold Nixdorf or an external power supply unit without automatic current identification is used. With a suitable power supply unit type the maximal power value can be defined with the...
Page 91: Feed
BEETLE /iSCAN EASY User Manual LED Overview POWER PAPER ERROR Meaning green yellow No power Operation Power on blinking If necessary call for technical support flashing IDLE mode (power saving) Paper properly inserted Paper Paper near end Paper end Error...
Page 92: Print Head / Rubber Roller Cleaning
BEETLE /iSCAN EASY User Manual Print Head / Rubber Roller Cleaning Clean the print head and the rubber roller at least every three months. In case of an intensive use of the printer clean both items more often to guarantee a stable print quality.
Page 93 Clean print head and rubber roller with a soft lint-free cloth moistened with pure Isopropyl alcohol (e.g. ISOPADS which can be ordered from Diebold Nixdorf). Visually inspect the print head. If you can still see dirt, the cleaning procedure must be repeated.
Page 94: Paper Roll Exchange
Paper Roll Exchange For a paper roll exchange follow the steps below:  Open the BEETLE /iSCAN EASY (NON CASH only).  Open the printer cover with a thin tool (1).  Remove the (nearly) empty paper roll and any residual paper.
Page 95 BEETLE /iSCAN EASY User Manual Lay the unwinded paper over the front edge of the printer and close the printer cover. Press on the middle of the cover until it audibly and distinctly locks into place. Tear off residual paper at the tear-off edge.
Page 96: Paper Near End Sensor Adjustment
BEETLE /iSCAN EASY User Manual Paper Near End Sensor Adjustment The paper end premonition is a control function. It allows to adjust a predefined amount of remaining paper on the roll. The paper end premonition depends on the core diameter and the paper thickness of the paper roll in use.
Page 97: Connector Variants
BEETLE /iSCAN EASY User Manual Connector Variants USB/CASH DRAW/DC24V Energy-saving Mode If the TH230+ is switched on but without a print job it stays in standby mode, which means, that all functions of the printer are powered with low voltage to be ready for operation.
Page 98: Technical Data
BEETLE /iSCAN EASY User Manual Technical Data Technology High-speed thermal print Resolution 8 dots/mm (203 dpi) Printing speed One colour: 220 mm/s, Two colours: 110 mm/s TH230+ draft mode up to 300 mm/s (reduced density) Cash Drawer Interface 6pin RJ12, 1A@24V max.
Page 99: Paper Specification
BEETLE /iSCAN EASY User Manual Statistical Data Total number of dots Total line feeds Total number of cuts Max. head temperature Paper jam counter Cutter error counter Thermistor error counter High voltage/low voltage error counter Number of firmware updates Power on time in hours...
Page 100: Print Area
BEETLE /iSCAN EASY User Manual Print Area For optional paper width 57,5mm, print width =51mm = 408 dot...
Page 101: Beetle /M-Ii Plus (G41 Motherboard)
BEETLE /iSCAN EASY User Manual BEETLE /M-II plus (G41 Motherboard) The BEETLE /M-II plus controls several devices in the BEETLE /iSCAN EASY, such as printer and scanner. Interfaces BEETLE /M-II Find more information about BEETLE /M-II on the Diebold Nixdorf Internet.
Page 102: Beetle M-Iii
BEETLE /iSCAN EASY User Manual BEETLE M-III The BEETLE M-III controls several devices in the BEETLE /iSCAN EASY, such as printer and scanner. Interfaces BEETLE M-III Find more information about BEETLE /M-III on the Diebold Nixdorf Internet.
Page 103: Scanner
BEETLE /iSCAN EASY User Manual Scanner Cleaning the Bin Clean up the scanner bin as needed. If liquid runs into the device, the bin under the scanner will absorb it. To clean it up, remove the bin as shown in the following pictures.
Page 104 BEETLE /iSCAN EASY User Manual Grasp the lever at the scanner and lift it out of the housing. Take care of the cables. Open the front door and remove the bin forwards. Clean it up and mount the device in reverse order.
Page 105: Scanner Maintenance
BEETLE /iSCAN EASY User Manual Scanner Maintenance Keep scanner window clean. This will improve productivity and reduce rescans. Scanning Items To scan items, slide or push them through the scan zone. The scanner will work equally well with either a left-to-right or right-to-left motion through the scan zone.
Page 106: Scanner (Beetle /Iscan Easy Hybrid)
Clean up the scanner bin as needed. Grasp the cover at the lever and remove it. Lift up the scanner at the blue levers and place it on the BEETLE /iSCAN EASY housing. Clean the bin. Mount the device in reverse order.
Page 107: Ba92/93 (With Resistive Touch Screen)
BEETLE /iSCAN EASY User Manual BA92/93 (with resistive Touch Screen) General The resistive TFT Touch Screen is constructed of a hard-coated polyester top sheet that is overlaid on a conductively coated glass layer. Voltage is applied to the top sheet. As the user touches the screen, the top sheet compresses into contact with the glass layer, and current flows to the four corners in proportion to the distance from the edge.
Page 108: Operator Panel
BEETLE /iSCAN EASY User Manual Operator Panel USB Interface A Plug and Play interface (type A) for connecting peripherals during operation, e.g. USB sticks or a keyboard. On Screen Display (OSD) Menu Via the menu you can set the loudness, brightness, contrast and colour.
Page 109: Construction Of The Resistive Touch Screen
BEETLE /iSCAN EASY User Manual Construction of the resistive Touch Screen Hard-coated polyester topsheet Adhesive Glass substrate with spacer dots How to Operate Touching the touch screen has the same effect as clicking the left mouse button. You only need to apply a little pressure with the fingertip. In this resistive process not only fingertip contact is recognized.
Page 110: Cleaning Instructions
 Clean the housing of the K-one with a vacuum cleaner or soft cloth. Wrong maintenance may cause damages to the screen, which are not covered by warranty. Approved Cleaning Materials The items listed below can be ordered from Diebold Nixdorf branch office or your Diebold Nixdorf sales partner. Product Name Order Number...
Page 111: Appendix
BEETLE /iSCAN EASY User Manual Appendix Technical Data General Dimensions (H x W x 0} in mm • 1,793 x 750 x 760 (with status light) Weight • Approx. 150 kg (depending on configuration) Currencies • Euro, US Dollar, GB Pound •...
Page 112 BEETLE /iSCAN EASY User Manual iCASH 15e - Coin Recycling • Recycling of up to 8 denominations • Euro capacity - 220 x 2 euro - 250 x 1euro - 220 x SO cent - 290 x 20 cent - 360x 10 cent...
Page 113 BEETLE /iSCAN EASY User Manual Scanning/Printing Functionalities Integration of various scanners Integrated fruit scale (optional} Handheld scanner (optional} Printer (receipt,MF,coupon) Customer interaction 15" TnLCD touch;wide screen and 2nd customer dispfay (optional} Speaker integrated Proximity sensor (optional) Illumination for input and outputslots...
Page 114 BEETLE /iSCAN EASY User Manual Three Security Layers • First: access to system housing • Second: access to cash cassettes • Third: access to cash Attendant Logon • Via dallas key or barcode • Alternatives possible Status Lights EAS deactivation (optional}...
Page 115: Environmental Requirements
BEETLE /iSCAN EASY User Manual Environmental Requirements Operating Temperature Ambient Temperature: 5 °C – 35 °C Humidity: 5% r.h. (1 g/m3 ) – 85% r.h. (25 g/m3 ) Temperature change: 0.5 K/min (max. 7.5K/30 min) Storage Conditions Ambient temperature: 5 °C – 40 °C Humidity: 5% r.h.
Page 116: Cleaning Instructions
BEETLE /iSCAN EASY User Manual Cleaning Instructions  Always turn off the system before cleaning.  The glass surface of your touch screen and the scanner should be cleaned with a mild, abrasive free, commercially available glass cleaning product.  All pH neutral materials (pH 6 to 8) are good for cleaning. Cleaners with pH values 9 to 10 are not recommended.
Page 117: Cleaning Materials: Order Numbers
BEETLE /iSCAN EASY User Manual Cleaning Materials: Order Numbers The items listed below can be ordered from Diebold Nixdorf branch office or your Diebold Nixdorf sales partner. Product Name Order Number Explanation Cleaning set for EDP devices: 01750097335 For cleaning and maintaining...
Page 118: Certificates
BEETLE /iSCAN EASY User Manual Certificates This device meets the requirements of the EU directives 2014/30/EU with regard to “Electromagnetic compatibility” and, if applicable, 2014/35/EU “Low Voltage Directive” and 2011/65/EU “Restriction of Hazardous Substances”. The device therefore bears the CE label on the rear. Alternatively, the label may be found on the packaging.
Page 119: Recycling
For recycling purposes do not attach any additional adhesive labels to the device. Diebold Nixdorf disposes of old devices in an environmentally responsible manner at a recycling center that is ISO 9001 and ISO 14001 certified, as is the entire company.
Page 120 Diebold Nixdorf D-33094 Paderborn Order No.: 01750276430B...

DIEBOLD NIXDORF BEETLE /iSCAN EASY User Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DIEBOLD NIXDORF BEETLE /iSCAN EASY

Summary of Contents for DIEBOLD NIXDORF BEETLE /iSCAN EASY

Table of Contents
