BEETLE /iSCAN EASY eXpress
+
Self-Checkout System
Integration Guide (November 2018)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BEETLE/iSCAN EASY eXpress+ and is the answer not in the manual?

Questions and answers

Related Manuals for DIEBOLD NIXDORF BEETLE/iSCAN EASY eXpress+

Summary of Contents for DIEBOLD NIXDORF BEETLE/iSCAN EASY eXpress+

  • Page 1 BEETLE /iSCAN EASY eXpress Self-Checkout System Integration Guide (November 2018)
  • Page 2 All of the product names mentioned in this document are registered trademarks. Copyright © Diebold Nixdorf International GmbH, 2018 All rights, including rights to full or partial translation, reprinting and transmission or copying by any means, are reserved. Offenders are liable to payment of damages. All rights, including those granted by registration of a patent,...

  • Page 3: Table Of Contents

    Contents Remarks ........................... 1 Technical data ........................2 System ............................2 Environmental conditions ......................2 Dimensions ........................3 Rear of 15” and 19” version ......................3 15” version ..........................4 15“ version with tabletop display ....................5 19” version ..........................6 19“...

  • Page 5: Remarks

    You will find further important details in relation to installation in the Installation Guide for the BEETLE /iSCAN Express+ on the Diebold Nixdorf website. An angled power cable is required both for integration in the tabletop adapter and for wall...

  • Page 6: Technical Data

    Integration Guide BEETLE /iSCAN EASY eXpress Technical data System Mains input voltage 100-240 VAC / 60-50Hz Power consumption 1.4-0.7A Typical output approx. 55W Max. output approx. 87W Standby output approx. 1.5W Weight for 15” version 28 kg Weight for 19” version 30 kg Environmental conditions Operation...

  • Page 7: Dimensions

    BEETLE /iSCAN EASY eXpress Integration Guide Dimensions (all values in mm) Rear of 15” and 19” version...

  • Page 8: 15" Version

    Integration Guide BEETLE /iSCAN EASY eXpress 15” version...

  • Page 9: 15" Version With Tabletop Display

    BEETLE /iSCAN EASY eXpress Integration Guide 15“ version with tabletop display...

  • Page 10: 19" Version

    Integration Guide BEETLE /iSCAN EASY eXpress 19” version 19“ version with tabletop display...

  • Page 11: Openings On The Underside

    BEETLE /iSCAN EASY eXpress Integration Guide Openings on the underside Device with open door Service area Grip area of lock...

  • Page 12: Orientation And Vertical Mounting

    Integration Guide BEETLE /iSCAN EASY eXpress Orientation and vertical mounting The BEETLE /iSCAN EASY eXpress may be installed vertically or tilted at an angle of up to 23° from the vertical. Danger owing to ingress of liquids! In case of vertical assembly in a restaurant environment, a suitable mechanism must be used to ensure that no beverages can be placed on the device.

  • Page 13: Ventilating The System

    BEETLE /iSCAN EASY eXpress Integration Guide Ventilating the system Keep the device's ventilation openings uncovered to ensure adequate ventilation. This prevents the temperature increasing excessively. Even if you plan to integrate the device, make sure to maintain the minimum distances stated below and ensure reliable ventilation and air extraction.
  • Page 14 Integration Guide BEETLE /iSCAN EASY eXpress Observe the specified minimum distances to ensure proper ventilation. Always keep the ventilation slots free of obstruction to ensure adequate air circulation and avoid overheating. 15” version 19” version 150mm 60mm 50mm 50mm...

  • Page 15: Suspending The System

    BEETLE /iSCAN EASY eXpress Integration Guide Suspending the system 4 positions for securing with screws with a diameter of 6mm 4 positions for se- curing with hooks; additional fixing with screws is nec- essary!

  • Page 16: Cabling External Devices

    Integration Guide BEETLE /iSCAN EASY eXpress Cabling external devices Covers for cabling external devices There are openings on the underside of the device to the right and left, which are sealed by covers. One of the covers allows cable feed with edge protection. The covers are interchangeable. Fixing of cables is possi- ble (strain relief) Cable feedthrough...

  • Page 17: Mechanically Adapting Additional Peripherals

    BEETLE /iSCAN EASY eXpress Integration Guide Mechanically adapting additional peripherals The housing of the includes two M4 screw threads on either side BEETLE /iSCAN EASY eXpress of the body for attaching add-ons, such as brackets for handheld scanners, advertising media, etc.

  • Page 18: Pillar And Wall Mounting

    Integration Guide BEETLE /iSCAN EASY eXpress Pillar and wall mounting Dimensions (in mm) 9.1.1 Optional base plate 9.1.2 Pillar drill template...

  • Page 19: Pillar Mounting With 15" Beetle /Iscan Easy Express

    BEETLE /iSCAN EASY eXpress Integration Guide 9.1.3 Pillar mounting with 15” BEETLE /iScan EASY eXpress+ 9.1.4 Pillar mounting of 19” BEETLE /iScan EASY eXpress+ with optional basket shelf on both sides, status indicator, coupon box and base plate...

  • Page 20: Pillar Mounting Of 19" Beetle /Iscan Easy Express+ And Optional Scale Platform

    Integration Guide BEETLE /iSCAN EASY eXpress 9.1.5 Pillar mounting of 19” BEETLE /iScan EASY eXpress+ and optional scale platform 9.1.6 Wall mounting of 15” BEETLE /iScan EASY eXpress+...

  • Page 21: Wall Mounting Of 19" Beetle /Iscan Easy Express

    BEETLE /iSCAN EASY eXpress Integration Guide 9.1.7 Wall mounting of 19” BEETLE /iScan EASY eXpress+...

  • Page 22: Installation Instructions: Self-Checkout On Pillar

    Integration Guide BEETLE /iSCAN EASY eXpress Installation instructions: Self-Checkout on pillar 9.2.1 Self-Checkout with floor cabling Installation including floor mounting must be carried out by a trained engineer after assessing and evaluating the structural conditions on site. Materials required (depending on the substrate): 4x M10 anchor bolts 4x DIN 933 M10x60-8.8 hexagon bolts 4x 10.5x2.0 washers...
  • Page 23 BEETLE /iSCAN EASY eXpress Integration Guide 3. Position the pillar above the floor outlet so that the cables can pass through the hole in the center of the base plate. The pillar must always have a solid base. 4. Mark the four holes as drilling points. Do not mark any drilling points near the cable feed! Attention: The kiosk must be...
  • Page 24 Integration Guide BEETLE /iSCAN EASY eXpress 6. Leave the cable lying on the base plate. 7. Screw the two M6x10 screws in half- way. Attention: Two people are needed to position the kiosk on the pillar. 8. First insert the closed BEETLE /iS- CAN EASY eXpress below into the sheet metal tabs of the pillar...
  • Page 25 For more information about con- necting the cables, see the BEETLE /iSCAN EASY-eXpress Installation Guide on the Diebold Nixdorf website. 11. Mount the optional compo- 9.4 Basket shelf at front nents, such as basket shelf or 9.5 Basket shelf at side scale platform, in accordance 9.6 Security scale at front...
  • Page 26 Integration Guide BEETLE /iSCAN EASY eXpress 12. Insert the rear panel and secure by screwing in. 13. Unlock the BEETLE /iSCAN EASY eXpress and open the door. Now insert the front cover and close and lock the BEETLE /iSCAN EASY eXpress...

  • Page 27: Self-Checkout With Floor Cabling And Optional Base Plate

    BEETLE /iSCAN EASY eXpress Integration Guide 9.2.2 Self-Checkout with floor cabling and optional base plate Installation including floor mounting must be carried out by a trained engineer after assessing and evaluating the structural conditions on site. 1. Follow steps 1-2 in Section 9.2.1 2.

  • Page 28: Self-Checkout With Cabling "On The Floor

    Integration Guide BEETLE /iSCAN EASY eXpress Self-Checkout with cabling “on the floor” Follow steps 1-4 in Section 9.2.1 Pull all required cables through the opening into the interior of the pillar. Follow steps 6-13 in Section 9.2.1 Installing the basket shelf at front 1.
  • Page 29 BEETLE /iSCAN EASY eXpress Integration Guide 2. Insert the two safety plates from the inside as shown in the diagram along- side [1] and secure each of these from the outside using two M6x10 cheese head screws [2]. 3. Place the basket shelf on the angle brackets and push these toward the rear until the shoulder screw on the right-hand side submerges into the...

  • Page 30: Installing The Basket Shelf At Side

    Integration Guide BEETLE /iSCAN EASY eXpress Installing the basket shelf at side Installation of the basket shelf on the right is described here by way of example, the left basket shelf is secured accordingly on the left-hand side. 1. To install the side basket shelf at the standard height (535 mm), clip the shelf into the mounting grid so that the upper hook is located in the 12th...
  • Page 31 BEETLE /iSCAN EASY eXpress Integration Guide 2. Insert the two safety plates from the inside as shown in the diagram along- side [1] and secure each of these from the outside using two M6x10 cheese head screws [2]. 3. First place the scale on the angle brackets without load plate and push these to the rear until the shoulder screw on the right side submerges...
  • Page 32 Integration Guide BEETLE /iSCAN EASY eXpress 5. Run the cable for the scale controller upward in the rear area of the pillar and secure it from the outside in a free drill hole using cable ties. 6. Now feed the cable to the BEETLE /iS- CAN EASY eXpress in the top area.

  • Page 33: Installing The Security Scale At Side

    BEETLE /iSCAN EASY eXpress Integration Guide Installing the security scale at side The installation of the security scale on the right is described here by way of example, the left secu- rity scale is secured accordingly on the left-hand side. 1.
  • Page 34 Integration Guide BEETLE /iSCAN EASY eXpress 3. Now feed the cable to the BEETLE /iS- CAN EASY eXpress in the top area. 4. Place the load plate on the scale.

  • Page 35: Installing The Coupon Box

    BEETLE /iSCAN EASY eXpress Integration Guide Installing the coupon box 1. Insert the mounting frame into the pillar so that the lower fixing hole corresponds to the bottom drill hole in the perforated grid of the mount- ing pillar. 2. Now screw in the four M6x10 cheese head screws on both sides from the outside into the corresponding threaded drill holes.
  • Page 36 Integration Guide BEETLE /iSCAN EASY eXpress 3. Secure the cable in free drill holes us- ing cable ties and feed the cable to the BEETLE /iSCAN EASY eXpress 4. Insert the coupon box [1], close [2] and finish [3].

  • Page 37: Installing The Signal Indicator

    BEETLE /iSCAN EASY eXpress Integration Guide Installing the signal indicator 1. Screw in two M4x6 round head screws halfway into the lower two drill holes on the rear of the pillar. 2. Place the base plate on the two screws and slide the base down to the floor [1].
  • Page 38 Integration Guide BEETLE /iSCAN EASY eXpress 5. Remove the aluminum profile with- out drill holes (see markings) in the direction of the arrows. 6. Likewise separate the other alumi- num profiles (remove in the direction of the arrows). 7. Connect the aluminum profiles with- out gaps using four M4x6 round head screws.
  • Page 39 BEETLE /iSCAN EASY eXpress Integration Guide 10. Position the outer aluminum profile and lock in place. 11. Now secure the cable from the status indicator cable inside the pillar to a free drill hole in the perforated grid using cable ties and feed through to the BEETLE /iSCAN EASY eXpress...

  • Page 40: Installing The Coupon Printer Shelf

    Integration Guide BEETLE /iSCAN EASY eXpress 9.10 Installing the coupon printer shelf 1. Clip the coupon printer shelf with the upper hook into the top opening on the mounting pillar. 2. Insert the safety plate from the inside as shown in the diagram alongside [1] and secure from the outside using two M6x10 cheese head screws [2].

  • Page 41: Hole Pattern For Wall Mounting (Dimensions In Mm)

    BEETLE /iSCAN EASY eXpress Integration Guide 9.11.2 Hole pattern for wall mounting (dimensions in mm) Use four screws of max. 6mm in diameter and suitable dowels depending on the structural condi- tions on site. The 19” BEETLE /iScan EASY eXpress+ weighs approx. 30kg, while the 15” BEETLE /iScan EASY eXpress+ weighs approx.

  • Page 42: 9.11.3 Installing The Wall Mount

    Integration Guide BEETLE /iSCAN EASY eXpress 9.11.3 Installing the wall mount 1. Drill the holes for the appro- priate dowels as indicated in the hole pattern of the wall mount. Then screw the lower two screws approximately halfway into the dowels in the wall.
  • Page 43 BEETLE /iSCAN EASY eXpress Integration Guide Screw the upper two M6x10 cheese-head screws halfway into the wall mount. Attention: Two people are needed to position the kiosk on the pillar. First insert the closed BEETLE /iSCAN EASY eXpress below into the sheet metal tabs of the pillar adapter [1].

  • Page 44: Block Diagram

    Integration Guide BEETLE /iSCAN EASY eXpress Block diagram The optional components are highlighted in green.
  • Page 45 Diebold Nixdorf D-33094 Paderborn Order no.: 01750301911A...
