Ventamatic HVPF 30 WM Owner's Manual

VENTAMATIC, LTD.
30" OSCILLATING WALL MOUNT FAN
MODEL HVPF 30 OSCWM
30" NON-OSCILLATING WALL MOUNT FAN
MODEL HVPF 30 WM
OWNER'S MANUAL
READ & SAVE THESE INSTRUCTIONS

ASSEMBLY AND OPERATING INSTRUCTIONS

CAUTION: Read and follow all instructions before operating fan. Do not use fan if any part
is damaged or missing.
WARNING: To reduce the risk of fire or electrical shock, do not use this fan with any solid
state speed control device. This appliance has a 3-prong plug. To reduce the risk of electrical
shock, this plug is intended to fit in an outlet only one way. If this plug does not fit the outlet,
contact a qualified electrician.

RULES FOR SAFE OPERATION

• Use with grounded 120V, 60 Hz power supply.
To reduce the risk of personal injury and electric shock, the fan should not be played
•
with or placed where small children can reach it.
WARNING: Always unplug the power cord before servicing, or moving the fan.
•
• DO NOT use to exhaust hazardous or explosive materials or vapors.
DO NOT use the fan near a window or door where rain could create an electrical hazard.
•
• Where possible, avoid the use of extension cords. If they must be used, minimize the risk
of overheating by ensuring that they are UL listed. Never use a single extension cord to
operate more than one fan.
Do not operate any fan with a damaged cord or plug or after the fan malfunctions, has
•
been dropped or damaged in any manner.
Do not insert or allow fingers or foreign objects to enter any ventilation or exhaust
•
opening as it may cause an electric shock or fire, or damage the fan. Do not block or
tamper with the fan in any manner while it is in operation.
Locate the power cord so the fan or other objects are not resting on it. Do not run the
•
power cord under carpeting. Arrange power cord away from room traffic and where it
will not be tripped over.
This fan is not intended for use in wet or damp locations. Never locate a fan where it
•
may fall into a bathtub or other water container.
.
DO NOT use this fan outdoors.
•

INSTALLATION INSTRUCTIONS

NOTE: When selecting the mounting location you should ensure that the wall bracket will be
able to mount to a wall stud.

MOUNTING THE WALL BRACKET

1. Locate a wall stud near the selected mounting location and secure the WALL
BRACKET to the stud using (4) 5/16"x2" lag screws (NOT INCLUDED).

REAR GUARD AND BLADE ASSEMBLY

1. Attach the SWIVEL ARM to the MOTOR MOUNT FLANGE using the M12 and M6
fasteners.
2. Remove the (4) M5x15 screws and flat washers from the shaft side of the motor.
3. Align the REAR GUARD over the threaded holes in the MOTOR. Note: align the
REAR GUARD so that the one small hole in the outer ring is located to your lower
right when facing the fan.
HRD INSHVPF30WM REV. 2/11
Page 2
