- Page 1 SMART-KILL ™ Electronic Traps USER GUIDE...
-
Page 2: Latest Updates
This is a list of changes in this most recent version of the SMART-KILL™ Users Guide: Latest Updates Do NOT use a phone/t ablet hotspot for a Wi-Fi connection. Each new trap requires a set of brand new batteries. (4 “AA” for the mouse trap. -
Page 3: Getting Started
• A set of brand new batteries (4 • "AA" for the mouse trap, 4 "C" for the rat trap). Getting Started: Download the free Victor Pest ® App from the Apple App Store ® Android Google Play store. Check ™... -
Page 4: Trouble Shooting
Did You Know? Once a rodent is caught, a • noti cation is sent to your connected device if it is connected to the Victor Pest App. ® A noti cation is sent to your • mobile device when the batter y life of the trap is low. - Page 5 ® ™ will likely connect to your Wi-Fi network, but connection may be intermittent. No Wi-Fi signal: Try one of the following: • Move your router closer to your Victor ® Smart-Kill trap. ™ • Buy a Wi-Fi range extender...
- Page 6 Trouble Shooting: • A password error has occurred if the blue W i-Fi light and the red Victor “V” light blink for 5 ® seconds. Re-enter password. Note that passwords are case sensitive. Frequently Asked Questions Where should I place my trap? •...
- Page 7 Frequently Asked Questions • How much bait do I need? The trap has a bait cup that shows you exactly how much bait to use. Do not over ll the bait cup. Do not place bait on the met al plates. Doing so may interfere with the electrical functionalit y and your trap may not work unless you...
- Page 8 Press Power Button Press the power button to turn the trap on. The Victor “V” will blink ® green 3 times. Press and Hold Wi-Fi Button for 5...
- Page 9 Scan Trap Code Center the trap’s code in the window on the screen. The trap code is the QR code located on the bottom of the mouse trap and the back of the rat trap. See FAQ page for images of QR code locations.
- Page 10 Connect Mobile Device to Trap Go to W i-Fi settings on your device by pressing the red “GO TO SETTINGS” button. Select the trap, which is VICTOR followed by 15 alphanumeric digits. (Ex: VICTOR-WM170818BE0 0 004). Press “CONNECT” , then press the...
- Page 11 Connect Trap to Wi-Fi Select the Wi-Fi network to connect the trap to. Enter the net work password for the Wi-Fi net work, then press the red “CONNECT” button. It may take up to 1 minute to connect.
- Page 12 Connected. A noti cation appears when the trap successfully connects. Press the red “NEXT” button and continue to step number 8.
- Page 13 SMART-KILL ™ Electronic Traps www.victorpest.com/smart-kill FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 14 Unable to Connect If your trap did NOT successfully connect, go to the Settings menu of your mobile device, then select the W i-Fi option. Select more options (often can be found by pressing the options button in the top right corner) then select “Saved Net works.”...
- Page 15 Unable to Connect (Continued) Find the trap name (Ex: VICTOR-WM170818BE00004) and select it. Select “FORGET.” Power trap off, then repeat steps 1 through 7. If the trap still does not connect, visit the Trouble Shooting section or call 1-855-5-VICTOR for immediate assist ance.
- Page 16 Name Your Trap After successful connection, name the trap and press the red “NEXT” button. Bait and Place Trap Swipe through the three instruction screens on baiting and placing the trap, then press the red “DONE button. Visit the Frequently Asked Questions section for more information on baiting and placing the trap.
- Page 17 Press Power Button Press the power button to turn the trap on. The Victor “V” will blink ® green 3 times. Press and Hold Wi-Fi Button for 5...
- Page 18 Scan Trap Code Center the trap’s code in the window on the screen. The trap code is the QR code located on the bottom of the mouse trap and the back of the rat trap. See FAQ page for images of QR code locations.
- Page 19 Connect Mobile Device to Trap Go to W i-Fi settings on your device by pressing the red “GO TO SETTINGS” button. Select the trap, which is VICTOR followed by 15 alphanumeric digits. (Ex: VICTOR-WM170818BE0 0 004). Press the back button on the device’s top menu bar to return to...
- Page 20 Connect Trap to Wi-Fi Press the red “NEXT” button to go to Wi-Fi settings. Choose the Wi-Fi net work you would like your trap to connect to.
- Page 21 Connect Trap to Wi-Fi (Continued) Enter the net work password for the Wi-Fi network, then press the red “SUBMIT” button.
- Page 22 Most devices will automatically re-connect to the most recently selected W i-Fi network. If it does not, select it. Then press the back button on the phone’s top menu bar to return to the Victor Pest ® App. Victor Pest...
- Page 23 Reconnect Mobile Device to Wi-Fi (Continued) Press the red “NEXT” button. It may t ake up to 1 minute to connect.
- Page 24 Connected. A noti cation appears when the trap successfully connects. Press the red “NEXT” button and continue to step number 9. Connection Error If your trap did NOT successfully connect, visit the Trouble Shooting section of this manual or click “CONNECTION HELP”...
- Page 25 Name Your Trap After successful connection, name the trap and press the red “NEXT” button. Bait and Place Trap Swipe through the three instruction screens on baiting and placing the trap, then press the red “DONE” button. Visit the Frequently Asked Questions section for more information on baiting and placing the trap.
Need help?
Do you have a question about the SMART-KILL and is the answer not in the manual?
Questions and answers
I have misplaced the instructions and **** not sure I set it up correctly, but the mouse cam in, ate the bait and left. Why did it not work?
The Victor SMART-KILL may not have worked after setup for several reasons:
1. Wi-Fi Connection Issues – The trap may not have successfully connected to Wi-Fi. If the signal is weak or missing, the trap will still operate but may not communicate properly.
2. Incorrect Code Entry – If the 15-digit alphanumeric code was entered incorrectly, the connection might fail.
3. Browser Cache Issue – If integrating with Home Assistant, the integration might not appear due to a browser cache issue. Clearing the cache or performing a hard refresh may help.
4. Trap Provisioning – The trap must be provisioned using the VictorPest app. If not, it may not function correctly.
5. Battery Issues – If the batteries are not inserted properly or are low, the trap may not power on correctly.
6. Setup Errors – If the baiting and placement steps were not followed correctly, the trap may not function as expected.
If issues persist, checking logs in Home Assistant, reviewing the troubleshooting section of the manual, or resetting the device may help.
This answer is automatically generated
