- Page 2 Cover Contents Pre-installation 1. Pre-installation 2. Pre-installation / water pressure. Installation 1. Installation 2. User Guide 1. User Guide 2. 10. User Guide 3. 11. Maintenance / Trouble shooting. 12. Warranty.
- Page 3 DIMENSIONS A 1390mm B 210mm C 640mm D 750mm E 485mm F 1305mm G 1700mm or 1500mm Floating Floors The definition covers a multitude of floor finishes. Typical examples below. It is imperative that before any work is carried out that an understanding of the floor composition is carried out. 1.
- Page 4 ¾” BSP Male hot water inlet, 30mm from the floor, against the wall, Picture for visual reference only 200mm from the left hand side of the front (tap end) of the bath. ¾” BSP Male cold water inlet, 30mm from the floor, against the wall, 250mm from the left hand side of the front of the bath.
- Page 5 Responsibility of the installer. It is the responsibility of the installer to inspect the product prior to installation to ensure the unit is free of defect or damage. In the event of a problem the unit must not be installed. This product complies with internationally recognised safety standards.
- Page 6 Do not use sharp knives or instruments to open this product. Remove the plastic film from all panels. Check with the site owner to confirm the exact installation position. Inspect the unit and panels thoroughly. Ensure all components are present inside the bath pack. (this should include : repair pot, Manual, Waste kit, SWL sticker, lap belt, floor fixing kit and shower unit assembly.
- Page 7 1. Prior to entry a carer should ensure that the pick up arm is in the fully lowered position outside of the bath. This can be achieved by pressing and holding down the “out of water” button on the handset. The arm will stop automatically when it is fully lowered.
- Page 8 ^ Z/ ^ To operate the seat in the Upwards direction, press and hold down the “out of water” button on the handset. The seat will cycle up and out of the bath, when it reaches the top of it’s stroke you must gently traverse out of the bath to 90° . When at 90°...
- Page 9 Intended use Fixed seat system. Supplied without the transfer trolley the seat is permanently fitted to the bath. All operation remains the same. A safety lap belt is supplied for added security whilst the user is seated on the chair and during bathing. It is the responsibility of the user/carer to ensure the lap belt is fitted while the product is in use.
- Page 10 To get the most out of your Windsor bath we recommend that the unit is cleaned and maintained on a daily basis. The chrome seat tube should be cleaned using a silicone based cleaning product (such as Mr Sheen) Spray a small amount on the tube when the seat is fully raised and wipe with a dry soft cloth. This will avoid any build up or soap, water or atmospherics.
- Page 11 This product is warranted as being free from defects during the period of warranty. This does not cover minor blemishes, etc. which may be part of normal manufacturing processes. The warranty covers manufacturing defects in the products, starting from the date of manufacture. Contact your Supplier to find out more about the warranty period.
