Fitting Instructions:

Tiger Explorer and Tiger Explorer XC

A9808089

Thank you for choosing this Triumph genuine accessory kit. This accessory kit is the product of Triumph's use of proven

engineering, exhaustive testing, and continuous striving for superior reliability, safety and performance.

Completely read all of these instructions before commencing the installation of the accessory kit in order to become

thoroughly familiar with the kit's features and the installation process.

These instructions should be considered a permanent part of your accessory kit, and should remain with it even if your

accessory-equipped motorcycle is subsequently sold.

cagi

Parts Supplied:

Alarm/immobiliser kit

Fitting kit

Publication part number A9900495 issue 2, ADC 12285

1 off

1 of 8

Retaining strap

Battery drainage label

1 off

Need help?

Do you have a question about the Tiger Explorer and is the answer not in the manual?

Questions and answers

Summary of Contents for Triumph Tiger Explorer

Page 1 Tiger Explorer and Tiger Explorer XC A9808089 Thank you for choosing this Triumph genuine accessory kit. This accessory kit is the product of Triumph's use of proven engineering, exhaustive testing, and continuous striving for superior reliability, safety and performance. Completely read all of these instructions before commencing the installation of the accessory kit in order to become thoroughly familiar with the kit’s features and the installation process.
Page 2 Tiger Explorer and Tiger Explorer XC motorcycles only will result in battery drain. Excessive battery drain will and should not be fitted to any other Triumph model or to cause permanent damage to the battery. The machine any other manufacturer's motorcycle. Fitting this accessory...
Page 3 Reed-Switch Fitment Note: • Read the warning notices printed on the cleaning Position the motorcycle on a paddock stand. wipe packet in the fitting kit. Remove the seats as described in the owner’s manual. • The surfaces to which the reed-switch and Disconnect the battery, negative (black) lead first.
Page 4 Locate the reed-switch on the tail panel, as shown 13. Route the reed-switch wiring along the left hand side below. of the battery tray, following the routing of the rear light harness. Secure the wiring to the rear light harness clip, and using the cable ties provided, secure it in two positions.
Page 5 Installation of the Alarm Unit Note: • The alarm connector is an unused black coloured Remove the left and right hand fuel tank infill panels. terminal block and is located on the frame Refer to the service manual. beneath the seat bridge of the motorcycle. The Remove the four fixings and then remove the seat shorting plug is the cover for this terminal block bridge.
Page 6 Locate the adhesive pads supplied in the kit, peel off Connect the alarm/immobiliser wiring to the main the backing strip and attach them to the lower surface wiring harness connector. of the alarm unit as shown below. 1. Alarm/immobiliser connector 1.
Page 7 Slide the supplied heat shrink over the alarm/ 12. Position the excess cable in a loop as shown below. immobiliser connector. Do not shrink the tubing at this time. 1. Reed-switch harness (tail panel removed for clarity) 2. Cable tie 1.
Page 8 Cable ties ........5 off Triumph/Datatool lanyard ......1 off Note: •...
