Summary of Contents for Bolt CYCLONE DR Series
- Page 1 CYCLONE|DR PP-500DR Dual-Outlet Power Pack with Removable Battery User Manual...
- Page 2 Thank you for choosing Bolt. The Bolt PP-500DR Power Pack is a rechargeable, large-capacity lithium-ion battery pack that supplies up to 2700 flashes and fast recycling times for up to two flashes. It’s compatible with most on-camera flashes, including Nikon, Canon, Sony, Bolt, Sunpak, Vivitar, and Metz.
- Page 3 Do not disassemble or attempt to service this product • To avoid overheating and damaging your flash unit, yourself. Doing so will void the warranty, and Bolt will not please wait at least 10 minutes after 40 continuous full- be responsible for any damage. There are high-voltage power flashes.
- Page 4 Overview Socket cover Cable locking mechanism Sockets Belt clip Charging port USB terminal Battery gauge Battery pack Battery pack lock Control unit Shoulder strap LED battery level indicator Status indicator for Socket #1 Power button Status indicator for Socket #2 AC battery charger Overview...
- Page 5 Overview...
- Page 6 Charging the Cyclone DR The Cyclone DR comes with the PP-5800BP battery pack. It’s also compatible with Bolt’s PP-400BP battery pack. To charge your Cyclone DR with the included charger: 1. Plug the charger unit into an AC outlet. 2. Plug the charging cable into the battery’s charging port.
- Page 7 To get the maximum capacity from your Cyclone DR: Charge your Cyclone DR shortly before use to ensure that the pack retains the maximum charge. Charge your Cyclone DR at a moderate room temperature, and avoid storing it in hot or cold environments between charging and use.
- Page 8 Checking the Cyclone DR’s charge level: When the Cyclone DR is not charging and is not connected to a flash unit, its level of charge can be checked by pressing the power button. The battery LEDs will illuminate to indicate the level of charge, as follows: Battery LED 1 on: 25% or lower charge level Battery LEDs 1-2 on: 25%-50% charge level Battery LEDs 1-3 on: 50%-75% charge level...
- Page 9 You can use the Cyclone DR to power a wide range of flash units. Cables sold by some flash and battery pack manufacturers are interchangeable with Bolt cables, but other flash brands use a different connector type. Make sure you select the right one.
- Page 10 3. Plug the other end of the connection cable securely into the compatible power port on your flash unit. 4. Press the power button on the Cyclone DR and wait for the Status and battery LEDs to turn on, then power on your flash. To disconnect your Cyclone DR from your flash unit: 1.
- Page 11 Using Your Flash with Your Cyclone DR Your Cyclone DR can recycle in just 1 second with many popular flash units to keep you shooting and ensure that you don’t miss important moments. With your flash firing at full-power, it can power up to 2700 flashes, depending on the specific unit you’re using.
- Page 12 Reading the indicator lights while using the Cyclone DR: When you’re using your Cyclone DR, its Red Status LED will remain on to indicate that the flash is ready to fire. Its four blue battery LEDs will indicate the level of charge as follows: Battery LED 1 on: 25% or lower charge level Battery LEDs 1-2 on: 25%-50% charge level Battery LEDs 1-3 on: 50%-75% charge level...
- Page 13 Carrying and wearing the Cyclone DR: The Cyclone DR is designed to be easy to carry and inconspicuous. Its light weight and compact design make it easy to wear for long periods, and its black finish and clean design make it unobtrusive. It also offers these convenient features: Padded feet.
- Page 14 Shoulder strap. Thread the shoulder strap through the built-in lugs on the Cyclone DR and through the strap clips and buckles, as shown here. After threading it, pull it tight to take up any slack. Always make sure that your strap is attached securely;...
-
Page 15: Troubleshooting
Troubleshooting Problem Solution The Cyclone DR is charged and connected to a flash with a The cable is damaged or you are using the wrong cable. cable, but no indicator lights illuminate when you turn it on. The Status indicator light is flashing. The pack is overheated. -
Page 16: Compatible Accessories
The Cyclone DR is compatible with a wide range of hot-shoe and handle-mount flash units. Make sure you select a connection cable that is compatible with your flash unit. Many compatible accessories are also available from Bolt and other brands. Bolt connection cables are interchangeable with some other manufacturers’ battery pack connection cables. - Page 17 These optional accessories are available from Bolt: BO-1007 CKE Nikon Flash Cable BO-1006 CZ Canon Flash Cable With Locking Mechanism With Locking Mechanism BO-1012 Sony Flash Cable Bolt PP-5800BP Battery Pack Compatible Accessories...
-
Page 18: Specifications
Specifications Power Pack Cyclone DR Battery type: Lithium-ion Dimensions (W × H × D): Voltage: 11.1 V DC 4.33 × 6.29 × 1.57 in. Capacity: 5800 mAh (110 × 160 × 40 mm) including belt clip Recycle time with hot-shoe flash units: Weight: 19.4 oz. -
Page 19: One-Year Limited Warranty
To obtain warranty coverage, contact the BOLT Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to BOLT along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
