- Page 1 SDC-EC25N HARDWARE INTEGRATION GUIDE VERSION 2.1 Americas: +1-800-492-2320 Option 2 Europe: +44-1628-858-940 Hong Kong: +852-2923-0600 www.lairdtech.com/wireless...
- Page 2 Added/revised antenna patterns Ron Seide 11/08/12 Updated formatting (Laird). Ron Seide 01/31/13 Updated Channel and Frequency data. Ron Seide Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved...
-
Page 3: Table Of Contents
Pin Definitions .............................. 10 Mechanical Specifications ..........................11 Regulatory ..............................12 Antenna Characteristics ........................... 12 Documentation Requirements ........................13 Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved... -
Page 4: Scope
The frequency stability for both 2.4 GHz (802.11b and 802.11g) and 5 GHz (802.11a) operation is +/- 20 ppm. The SDC-EC25N has its own RF shielding and does not require shielding provided by the host device into which it is installed in order to maintain compliance with applicable regulatory standards. As such, the device may be tested in a standalone configuration via an extender card. -
Page 5: Block Diagram
10 to 90% (non-condensing) Operating Humidity -40° to 80°C (-40° to 176°F) Storage Temperature 10 to 90% (non-condensing) Storage Humidity Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved... -
Page 6: Www.lairdtech.com/Bluetooth
2.4 GHz to 2.483 GHz 2.4 GHz to 2.473 GHz MIC (formerly TELEC) 2.4 GHz to 2.495 GHz Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved... -
Page 7: Www.lairdtech.com/Bluetooth
802.11n (20 MHz wide 5 GHz channel operation): 15 dBm (30 mW) 802.11n (40 MHz wide 5 GHz channel operation): 14 dBm (25 mW) Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved... -
Page 8: Www.lairdtech.com/Bluetooth
TBD dBm 216 Mbps TBD dBm 243 Mbps TBD dBm 270 Mbps TBD dBm (PER <= 10%) Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved... -
Page 9: Www.lairdtech.com/Bluetooth
EN 60950-1 EU 2011/65/EU (RoHS) FCC Regulatory Domain Part 15.247 Subpart C Part 15.407 Subpart E Industry Canada Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved... -
Page 10: Pin Definitions
Primary 3.3 V Module Power CLKREQ_L Reference clock request signal No Connect Not Used. Leave Open (Float) REFCLK_N Differential reference clock Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved... -
Page 11: Mechanical Specifications
Ground ECHANICAL PECIFICATIONS The SDC-EC25N is fully compliant with the PCI Express Card Type 1 mechanical standard. It can therefore be inserted in any Express Card hardware interface and typically does not require any additional mounting hardware. Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com... -
Page 12: Regulatory
Note: Operation in the 5150-5250 MHz band is limited to indoor use only in some regulatory domains. Antenna Characteristics The SDC-EC25N incorporates an integrated dual band antenna consisting of two separate antenna elements to support transmit and receive diversity and 2 x 2 MIMO. The patterns for two separate antenna elements... -
Page 13: Documentation Requirements
Antenna 2 Patterns Documentation Requirements In order to maintain regulatory compliance, when integrating the SDC-EC25N into a host device and leveraging Summit’s grants and certifications, it is necessary to meet the documentation requirements set forth by the applicable regulatory agencies. The following sections (FCC, Industry Canada, and European Union) outline the information that may be included in the user’s guide and external labels for the host... -
Page 14: Www.lairdtech.com/Bluetooth
(including the transmitter) and obtaining a separate FCC authorization. When using Summit’s FCC grant for the SDC-EC25N, the integrator must include specific information in the user’s guide for the device into which the SDC-EC25N is integrated. The integrator must not provide information to the end user regarding how to install or remove this RF module in the user’s manual of the... -
Page 15: Www.lairdtech.com/Bluetooth
European Union User’s Guide Requirements The integrator must include specific information in the user’s guide for the device into which the SDC-EC25N is integrated. In addition to the required FCC and IC statements outlined above, the following R&TTE statements must be added in their entirety and without modification into a prominent place in the user’s guide for the device into which the SDC-EC25N is integrated: This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. -
Page 16: Www.lairdtech.com/Bluetooth
[Spanish] exigibles de la Directiva 1999/5/CE. Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved... -
Page 17: Www.lairdtech.com/Bluetooth
Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse med de Svenska väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv [Swedish] 1999/5/EG. Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/bluetooth Hong Kong: +852 2923 0600 © Copyright 2015 Laird. All Rights Reserved...
